2005 Yamaha T135 Motorcycle Service Repair Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

The 2005 T135, an initial generation model, represents a robust and reliable option in the underbone motorcycle segment. Known for its sporty performance and fuel efficiency, this model has earned...

15 people are viewing this right now

Tipo: Motorcycle

Proveedor:

SKU: 131340

Etiquetas: 2005 Motorcycle Motorcycles T135 Yamaha

Variantes de producto

Descripción

The 2005 T135, an initial generation model, represents a robust and reliable option in the underbone motorcycle segment. Known for its sporty performance and fuel efficiency, this model has earned a strong market reputation for its affordability and dependability. Its engineering, originating from Japan, focuses on delivering a practical yet engaging riding experience, making it a popular choice for daily commuting and recreational use. This comprehensive service repair manual provides essential information for maintaining and repairing the 2005 T135. It covers a wide range of topics including engine overhaul, cooling and fuel systems, chassis components, and the electrical system. Detailed procedures for periodic maintenance, disassembly, reassembly, and troubleshooting are included, along with advanced diagnostic and rebuild guidance. This manual is an indispensable resource for enthusiast owners, independent repair shops, and DIY mechanics aiming to keep their T135 in optimal condition.

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

Year:

Codes

Chassis Code:

Generation

Model Generation:

Initial Generation

👋 Introduction

Market Position

Target Audience:

Enthusiast owners, independent repair shops, and DIY mechanics seeking comprehensive service information.

Key Features

Completeness:

Considered the most complete service repair manual available for the 2005 Yamaha T135.

Value Proposition

Benefits:

Enables owners to perform all necessary maintenance, repairs, and diagnostics, saving time and money.

📋 Manual Details

Coverage Areas

Primary Coverage:

Service and Repair

Page Count

Total Pages:

Manual Type

Type:

Service Repair Manual

Language

Language:

English

Format

File Format:

Download Type:

Instant Download

📖 Manual Coverage

Systems Covered

Engine Overhaul:

Complete disassembly, inspection, repair, and reassembly of engine components.

Cooling System:

Inspection, maintenance, and repair of radiator, hoses, coolant, and associated components.

Fuel System:

Carburetor tuning, cleaning, and overhaul; fuel line inspection and replacement.

Chassis Components:

Suspension, steering, wheels, brakes, and frame inspection and repair.

Electrical System:

Wiring diagrams, component testing, ignition system, lighting, charging system, and starting system.

Procedures Included

Periodic Maintenance:

Scheduled checks, fluid changes, filter replacements, and component adjustments.

Disassembly Reassembly:

Step-by-step instructions for dismantling and reassembling all major vehicle systems and components.

Troubleshooting:

Diagnostic guides and symptom-based problem-solving for common issues.

Technical Depth

Diagnostics:

Advanced diagnostic procedures and specifications for pinpointing faults.

Rebuild Guidance:

Detailed instructions for complete engine rebuilds and component overhauls.

📊 Manual Specifications

File Format

Print Quality:

High-resolution, printable across all pages.

Compatibility

Operating Systems:

Compatible with all versions of Windows, Mac, and Linux.

Requirements

Software Dependencies:

Adobe PDF Reader, Winzip (or equivalent decompression software).

Delivery

Shipping Cost:

Delivery Method:

Digital Download

⚙️ Engine Specifications

Primary Engine

Engine Type:

Four-stroke, SOHC, single-cylinder

Displacement:

134 cc

Performance

Bore X Stroke:

54.0 mm x 58.7 mm

Compression Ratio:

9.3:1

Fuel System

Carburetor Model:

Mikuni VM22 (or similar specific to the model)

Lubrication

Oil Type:

Yamalube 4 (or API SG, SAE 10W-40)

Ignition

Ignition System:

CDI (Capacitor Discharge Ignition)

🔧 Transmission

Standard

Transmission Type:

Constant-mesh, 4-speed

Features

Clutch Type:

Wet, multiple-disc

Fluid Requirements

Transmission Oil Type:

Yamalube 4 (or API SG, SAE 10W-40)

📐 Dimensions

Exterior

Length:

1925 mm (approx.)

Width:

715 mm (approx.)

Height:

1045 mm (approx.)

Weights

Curb Weight:

103 kg (approx.)

🛡️ Safety Features

Active Features

Braking System Front:

Disc brake

Braking System Rear:

Drum brake

Passive Features

Lighting System:

Halogen headlight, LED taillight (specifications vary by region).

💡 Technology Features

Infotainment

Instrument Cluster:

Analog speedometer, tachometer, fuel gauge, and indicator lights.

Connectivity

Lighting Technology:

Traditional incandescent bulbs and halogen headlight.

🔧 Maintenance

Service Intervals

Engine Oil Change:

Every 3,000 km or 3 months, whichever comes first.

Air Filter Cleaning:

Every 6,000 km or 6 months.

Spark Plug Replacement:

Every 10,000 km.

Fluid Specifications

Coolant Type:

Ethylene glycol-based coolant, 50% mixture with distilled water.

Brake Fluid Type:

DOT 3 or DOT 4 (refer to specific model documentation for exact recommendation).

Known Issues

Carburetor Tuning:

Can require periodic tuning due to environmental factors or fuel quality variations.

Idle Speed Instability:

May occur if carburetor is dirty or vacuum leaks are present.

Technical Specifications

Valve Clearance Intake:

0.08 - 0.13 mm (COLD)

Valve Clearance Exhaust:

0.13 - 0.18 mm (COLD)

Idle Rpm:

1300 - 1500 rpm

📚 Vehicle History

Brand Heritage

Manufacturer Origin:

Japan

Model Evolution

T135 Introduction:

The T135 (often referred to as Exciter or Sniper in various markets) was introduced as a sporty and fuel-efficient underbone motorcycle.

Production

Manufacturing Region:

Primarily Asia (e.g., Indonesia, Thailand)

🏆 Awards & Recognition

Recognitions

Market Reputation:

Popular for its reliability, performance, and affordability in its segment.
