Vehicle Segment:
Entry-level motorcycle (underbone/cub style)
Key Competitors:
Honda Wave series, Suzuki Smash series, Kawasaki ZX series (entry-level models)
Target Audience:
Commuters, budget-conscious riders, emerging markets
Manual Value Proposition:
Enables owners and independent workshops to perform dealership-level maintenance and repairs, saving costs and ensuring vehicle longevity.
Engine:
Internal components, lubrication, cooling, fuel system, ignition system, starting system, charging system
Transmission:
Clutch system, gearbox, internal components, lubrication
Chassis:
Frame, suspension (front and rear), steering, wheels, tires
Brakes:
Front and rear brake systems (hydraulic, disc), bleeding, component replacement
Electrical System:
Wiring diagrams, lighting, battery, charging system, ignition, indicators, starter motor, ECU
Fuel System:
Carburetor (if applicable), fuel tank, fuel lines, fuel pump
Body And Frame:
Body panels, seats, fairings, luggage carrying systems
Maintenance:
Oil changes, filter replacements, chain adjustment, spark plug replacement, valve clearance adjustment, general inspections
Diagnostics:
Troubleshooting guides, common fault identification, electrical system diagnostics
Repair:
Engine rebuild, transmission overhaul, suspension repair, brake system repair, electrical component replacement
Disassembly Reassembly:
Step-by-step instructions for component removal and installation
Depth:
Expert-level, suitable for dealership technicians and advanced DIY mechanics
Diagnostic Tools:
References diagnostic procedures and potential tool requirements
Specifications:
Detailed torque specifications, clearances, fluid capacities, electrical values
PDF Quality:
High resolution, clear text and images
Searchable:
Likely (standard for professionally produced PDFs)
Print Recommendation:
Printable on standard office printers
Binding Type:
Digital Download (PDF)
Paper Type For Printing:
Standard paper (A4 or Letter)
Engine Type:
Four-stroke, SOHC, single-cylinder
Bore X Stroke:
54.0 mm x 58.7 mm
Cooling System:
Liquid-cooled
Compression Ratio:
10.4:1 (typical)
Horsepower:
Approx. 10-12 HP (varies by market and specific tune)
Torque:
Approx. 9-10 Nm (varies by market and specific tune)
Fuel Delivery:
Carburetor (specific model may vary, e.g., Mikuni VM25)
Fuel Type:
Unleaded gasoline
Oil Type:
API SG or higher, SAE 10W-40 or 20W-40 motorcycle oil (check manual for specific Yamaha recommendations)
Oil Capacity:
Approx. 1.0 - 1.2 Liters (check manual for exact figure with filter change)
Transmission Type:
Constant mesh, 4-speed rotary or manual clutch
Clutch Type:
Wet, multiple-disc (for models with manual clutch)
Transmission Variants:
Some markets may have automatic clutch (semi-automatic) variants
Gear Shifting Pattern:
Rotary type (e.g., N-1-2-3-4, foot shifts up or down for gears, downshift for neutral)
Length:
Approx. 1900-1950 mm (varies by specific model variant)
Width:
Approx. 700-750 mm (varies by specific model variant)
Height:
Approx. 1050-1080 mm (varies by specific model variant)
Dry Weight:
Approx. 105-115 kg (varies by specific model variant)
Fuel Tank Capacity:
Approx. 4.0 - 4.5 Liters
Safety Standards:
Adheres to regional motorcycle safety regulations
Braking System:
Hydraulic front disc brake, rear drum brake (or disc depending on variant)
Lighting:
Headlight, taillight, brake light, turn signals
Frame Construction:
Steel backbone frame for rigidity
Tires:
Tubed or tubeless tires (specific sizes documented in manual)
Instrument Cluster:
Analog speedometer, fuel gauge, odometer, indicator lights
Safety Systems:
Basic lighting and signaling systems
Connectivity Features:
Not applicable for this model year; focused on mechanical and basic electrical systems.
Oil Change Interval:
Every 3,000-4,000 km or 3-6 months (refer to manual for exact interval based on usage)
Air Filter Cleaning:
Every 3,000 km or as needed, depending on environmental conditions
Valve Adjustment:
Every 6,000-10,000 km (critical for performance and engine longevity)
Brake Fluid:
DOT 3 or DOT 4 (check manual for specific recommendation)
Coolant Type:
Ethylene glycol-based coolant (50% mixture with distilled water)
Common Wear Items:
Clutch plates, spark plugs, brake pads/linings, chain and sprockets, battery.
Potential Electrical Issues:
Corrosion on electrical connectors, charging system issues (rectifier/stator) under high mileage.
Manufacturer:
Yamaha Motor Company, Japan
Yamaha Cub Heritage:
Part of Yamaha's long lineage of popular underbone and cub-style motorcycles known for reliability and efficiency.
Production Region:
Primarily manufactured in Southeast Asia (e.g., Indonesia, Thailand, Vietnam)
