Market Segment:
Entry-level to mid-range trail/off-road motorcycle
Target Audience:
Beginner to intermediate off-road riders, recreational trail riders, DIY mechanics
Competitors:
Honda CRF230F, Kawasaki KLX230, Suzuki DR-Z230 (if available)
Vehicle Key Features:
Reliable air-cooled engine, user-friendly handling, electric start, durable construction for off-road use
Manual Key Features:
Comprehensive coverage, detailed illustrations, technician-grade information, instant download, lifetime use
Coverage Countries:
Global (as manuals are typically translated for various markets, though this product description implies a general English version)
Coverage Regions:
North America, Europe, Asia, Oceania
Estimated Page Count:
Large (specific number not provided, but described as 'detailed' and 'comprehensive')
Manual Type:
Workshop Service Repair Manual
Additional Manual Types:
Factory Service Manual, Repair Guide
Digital Format:
PDF Download
File Compression:
ZIP or RAR (may require WinZip/WinRAR for extraction)
Engine Systems:
Engine inspection, disassembly, reassembly, troubleshooting, performance tuning, general maintenance, component breakdowns
Fuel System:
Carburetion, fuel tank, fuel lines, fuel pump (if applicable), fuel filter
Electrical System:
Ignition system, lighting, charging system, battery, starter, wiring diagrams, troubleshooting electrical faults
Frame And Suspension:
Frame inspection, front fork (telescopic), rear shock absorber, swingarm, steering system, wheel bearings
Braking System:
Front and rear brake systems (likely disc brakes for this model), brake fluid, caliper service, master cylinder
Drivetrain:
Transmission (likely 5-speed), clutch system, chain drive, sprockets, gearbox inspection and service
Cooling System:
Air-cooled engine specifics
Exhaust System:
Muffler, exhaust pipe inspection and replacement
Bodywork And Trim:
Fairings, seat, fenders, fuel tank cover, graphics
Maintenance Procedures:
Periodic inspections, adjustments (valve clearance, chain tension, clutch lever), lubrication, filter replacement, spark plug service
Repair Procedures:
Engine rebuild, transmission overhaul, suspension repair, brake system service, electrical component replacement
Troubleshooting Guidance:
Step-by-step diagnostic procedures for common and uncommon problems, symptom-based troubleshooting charts
Restoration Guidance:
Detailed information to guide complete restoration of the motorcycle
Diagnostics:
Comprehensive diagnostic information to identify and rectify issues
Depth Of Coverage:
Complete workshop level, suitable for professional technicians and advanced DIY enthusiasts
Illustration Quality:
Highly illustrated with clear step-by-step instructions, zoomable illustrations, exploded views, detailed component breakdowns
Accessibility:
Readable, savable, and printable on any computer (Windows, Linux, Mac)
File Size:
Up to 2550 MB (dependent on content, user advised to check)
Printability:
Printable on any computer and printer, no printing restrictions
Binding:
Not Applicable (Digital Download)
Paper Quality:
Not Applicable (Digital Download)
Engine Manufacturer:
Yamaha
Engine Displacement:
229.6 cc
Engine Type:
4-stroke, SOHC, 2-valve
Bore X Stroke:
66.0 mm x 66.0 mm
Cooling Method:
Air-cooled
Engine Oil Type:
Yamaha Yamalube 4 (or equivalent API SG or higher, SAE 20W-40 recommended)
Engine Oil Capacity:
1.80 L (with oil filter change)
Horsepower:
Approximately 16-18 HP (actual figures vary slightly by year and tuning, manual will have precise specs)
Torque:
Approximately 14-16 lb-ft (actual figures vary slightly, manual will have precise specs)
Carburetor:
Mikuni VM26 (34 mm, single)
Fuel Type:
Unleaded gasoline (minimum 87 octane)
Fuel Tank Capacity:
2.6 US gal (9.8 L)
Transmission Type:
5-speed constant mesh
Clutch Type:
Wet, multiple disc
Transmission Features:
Clutch operation (lever-actuated), gearbox disassembly and assembly, gear inspection, shift drum and fork service
Transmission Oil Type:
Same as engine oil (Yamaha Yamalube 4 or equivalent SAE 20W-40)
Transmission Oil Capacity:
Included in overall engine oil capacity
Overall Length:
Approx. 79.5 inches (2020 mm)
Overall Width:
Approx. 31.5 inches (800 mm)
Overall Height:
Approx. 45.3 inches (1150 mm)
Seat Height:
Approx. 31.9 inches (810 mm)
Wheelbase:
Approx. 54.1 inches (1375 mm)
Dry Weight:
Approx. 236 lbs (107 kg)
Wet Weight:
Approx. 250 lbs (113.5 kg) (with all fluids)
Maximum Payload:
Not explicitly specified, but designed for single rider operation
Safety Ratings:
N/A (Motorcycles are not typically subject to standardized crash test ratings like cars)
Active Safety Features:
Responsive braking system, predictable handling characteristics, throttle control
Passive Safety Features:
Durable frame, protective body panels, rider ergonomics designed for control
Oil Change Interval:
Every 2,000 km (1,200 miles) or 6 months, whichever comes first.
Air Filter Cleaning Interval:
Every 1,000 km (600 miles) or more frequently in dusty conditions.
Spark Plug Replacement Interval:
Every 6,000 km (3,700 miles) or as needed based on inspection.
Valve Clearance Check Interval:
First check at 1,000 km (600 miles), then every 4,000 km (2,500 miles).
Engine Oil Specification:
API SG or higher, SAE 20W-40 Yamalube 4 (or equivalent)
Brake Fluid Specification:
DOT 3 or DOT 4 Hydraulic Brake Fluid
Common Issues:
While generally reliable, common trail bike issues like chain wear, brake pad wear, suspension seal leaks, and carburetor adjustments due to fuel variability can arise. The manual provides solutions for these.
Troubleshooting Focus:
The manual is crucial for diagnosing starting problems, performance degradation, and electrical faults, which are common learning points for new owners.
Brand Heritage:
Yamaha has a long and successful history in motorcycle manufacturing, particularly in off-road and competition models, known for reliability and innovation.
Model Evolution:
The TT-R230 was introduced as an evolution of Yamaha's popular trail bike line, offering a blend of performance and ease of use for recreational riders. It built upon the legacy of models like the TT-350 and XT series.
Production Period:
2005 - Present (with updates and variations over the years)
Manufacturing Location:
Likely assembled in Japan or other Yamaha global manufacturing facilities.
