Yamaha XVS1100L V-Star 1999 Workshop Repair Service Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

20 people are viewing this right now

Tipo: Motorcycle

Proveedor:

SKU: 76033

Etiquetas: 1999 Motorcycle Motorcycles Royal Star Venture XVS1100L V-Star Yamaha

Variantes de producto

Descripción

The 1999 XVS1100L V-Star is a cruiser motorcycle renowned for its classic styling, comfortable ergonomics, and the robust character of its air-cooled, 4-stroke, SOHC V-twin engine. This model offers a shaft drive for reduced maintenance and features a timeless design with a teardrop fuel tank and pullback handlebars, making it ideal for riders who appreciate traditional cruiser aesthetics and a relaxed riding experience. Its 1063 cc displacement and well-balanced chassis contribute to its appeal for both leisurely rides and longer journeys. This comprehensive workshop service manual provides detailed guidance for the repair and overhaul of the 1999 XVS1100L V-Star. It covers essential maintenance procedures, including oil changes, filter replacements, and spark plug servicing, alongside in-depth technical information on engine disassembly, transmission and clutch systems, fuel delivery, and electrical diagnostics. The manual also includes troubleshooting guidance, technical specifications, and safety information, serving as an indispensable resource for owners and technicians to ensure the optimal performance and longevity of the vehicle.

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

XVS1100L V-Star

Year:

Codes

Chassis Code:

XVS1100L

👋 Introduction

Market Position

Segment:

Cruiser Motorcycle

Target Audience:

Riders seeking classic styling, comfortable cruising, and V-twin character.

Competitive Analysis

Key Competitors:

Honda Shadow series, Suzuki Intruder series, Kawasaki Vulcan series.

Key Features

Engine Type:

Air-cooled, 4-stroke, SOHC, 4-valve V-twin engine.

Drivetrain:

Shaft drive for low maintenance.

Styling:

Classic cruiser aesthetics with ample chrome, teardrop fuel tank, and pullback handlebars.

Ergonomics:

Comfortable riding position suitable for long-distance cruising.

📋 Manual Details

Coverage Areas

Primary Coverage:

Workshop Repair and Overhaul

Page Count

Total Pages:

Manual Type

Type:

Workshop Service Manual

Language

Language:

English

Format

Format:

PDF Download

📖 Manual Coverage

Systems Covered

Engine System:

Detailed engine repair, disassembly, inspection, and reassembly procedures for the V-twin engine.

Transmission Clutch:

Comprehensive coverage of the transmission gears, shifting mechanisms, and clutch assembly.

Fuel System:

Carburetor tuning, maintenance, fuel pump operation, and fuel tank servicing.

Electrical System:

Wiring diagrams, ignition system, lighting, starter motor, charging system, and troubleshooting.

Suspension Steering:

Front fork (telescopic) and rear shock absorber servicing, steering head bearing maintenance.

Braking System:

Front and rear brake caliper maintenance, hydraulic system bleeding, pad replacement, and master cylinder servicing.

Frame Bodywork:

Chassis inspection, frame integrity, body panel removal and installation, and seat servicing.

Exhaust System:

Exhaust pipe and muffler servicing, gasket replacement.

Wheels Tires:

Wheel bearing maintenance, tire pressure, and wheel removal/installation.

Procedures Included

Routine Maintenance:

Oil changes, filter replacements, chain adjustment, lubrication points, and spark plug replacement.

Troubleshooting:

Diagnostic flowcharts and common problem identification for various systems.

Engine Rebuild:

Complete engine disassembly, inspection of internal components (pistons, rings, valves, crankshaft), and reassembly.

Carburetor Overhaul:

Detailed steps for disassembling, cleaning, inspecting, and reassembling the Mikuni carburetors.

Electrical Diagnostics:

Using multimeters and specific test procedures to diagnose electrical faults.

Brake Bleeding:

Proper procedure for bleeding air from the hydraulic brake lines.

Technical Depth

Depth Level:

Comprehensive, suitable for professional technicians and experienced DIY mechanics.

📊 Manual Specifications

File Format

Format:

PDF (Portable Document Format)

Print Quality

Quality:

High-resolution scans, ensuring clarity of diagrams and text.

Binding Type

Binding:

N/A (Digital Download)

Paper Type

Paper:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Type:

Air-cooled, four-stroke, SOHC, V-twin

Displacement:

1063 cc (64.8 cubic inches)

Bore X Stroke:

95.0 mm x 75.0 mm

Compression Ratio:

8.5:1

Valvetrain:

SOHC, 4 valves per cylinder (2 per cylinder)

Cooling System:

Air-cooled

Starter:

Electric

Performance

Horsepower:

Approximately 61 hp @ 5750 rpm (Manufacturer's claim, may vary)

Torque:

Approximately 65.5 lb-ft @ 3750 rpm (Manufacturer's claim, may vary)

Fuel System

Carburetors:

Dual Mikuni BSR37 carburetors

Fuel Capacity:

4.2 US gallons (16 Liters)

Fuel Type:

Unleaded gasoline, 87 octane minimum

Lubrication

Oil Type:

Yamalube 4 (or equivalent) SAE 20W-40 motorcycle oil

Oil Capacity:

3.2 US qt (3.0 L) with filter change

🔧 Transmission

Standard

Transmission Type:

Constant mesh 5-speed

Clutch:

Wet, multiple-disc

Final Drive:

Shaft drive

Features

Gear Ratios:

Specific ratios are detailed within the manual (e.g., 1st: 2.438, 2nd: 1.750, 3rd: 1.322, 4th: 1.071, 5th: 0.870)

Transmission Oil Type:

Yamalube Gear Oil (or equivalent) SAE 80 API GL-4

Transmission Oil Capacity:

0.65 L (0.69 US qt)

📐 Dimensions

Exterior

Overall Length:

2365 mm (93.1 in)

Overall Width:

895 mm (35.2 in)

Overall Height:

1150 mm (45.3 in)

Wheelbase:

1610 mm (63.4 in)

Ground Clearance:

140 mm (5.5 in)

Seat Height:

710 mm (28.0 in)

Weights

Dry Weight:

232 kg (511 lbs)

Wet Weight:

246 kg (542 lbs) (approximate with fluids)

🛡️ Safety Features

Ratings

Crash Test Ratings:

N/A (Motorcycle safety ratings vary significantly by region and testing body; not typically comparable to automotive ratings.)

Active Features

Braking System:

Hydraulic disc brakes front and rear for reliable stopping power.

Passive Features

Frame Construction:

Steel tubular frame for rigidity and rider safety.

💡 Technology Features

Infotainment

Audio System:

N/A (This model is not typically equipped with integrated infotainment or audio systems.)

Driver Assistance

N/A (Anti-lock Braking System was not a standard or widely available option for this model year.)

Connectivity

Charging Port:

N/A (No factory-installed USB or charging ports are standard.)

🔧 Maintenance

Service Intervals

Engine Oil Filter Change:

Every 4,000 km (2,500 miles) or 6 months, whichever comes first.

Spark Plug Replacement:

Every 8,000 km (5,000 miles)

Air Filter Cleaning Replacement:

Inspect every 4,000 km (2,500 miles), clean/replace as needed.

Transmission Oil Change:

Every 8,000 km (5,000 miles) or annually.

Brake Fluid Flush:

Every 2 years or as per manual recommendations for optimal performance.

Fluid Specifications

Engine Oil Viscosity:

20W-40

Transmission Oil Type:

SAE 80 API GL-4 gear oil

Brake Fluid Type:

DOT 4 hydraulic brake fluid (for both front and rear systems)

Known Issues

Carburetor Performance:

Can be prone to clogging if fuel is not fresh or tank is dirty; proper synchronization and cleaning are crucial.

Starter Clutch Wear:

Some owners have reported premature wear on the starter clutch mechanism; attention to battery health and starter usage is recommended.

Rear Drive Shaft Boot:

Inspection and replacement of the shaft drive boot to prevent contamination of U-joints and bearings.

📚 Vehicle History

Brand Heritage

Manufacturer:

Yamaha Motor Company, a division of Yamaha Corporation, known for musical instruments and powersports vehicles.

Model Evolution

V Star Lineage:

The V-Star line represents Yamaha's commitment to the cruiser segment, evolving from smaller displacement models to larger V-twins like the XVS1100.

Production

Production Years:

The XVS1100 V-Star was produced from 1999 through 2009, with variations like the Classic and Custom.

🏆 Awards & Recognition

Recognitions

Industry Awards:

While specific awards for the 1999 model are not widely publicized, the V-Star line consistently received positive reviews for its styling, comfort, and reliable V-twin performance within the cruiser market segment.
