Market Segment:
Utility/Recreational Side-by-Side (SxS) market, targeting farm, ranch, and recreational users.
Key Competitors:
Polaris Ranger, Kawasaki Mule, Arctic Cat Prowler, Can-Am Commander.
Vehicle Strengths:
Renowned for its reliability, robust engine, and excellent off-road capability. The Rhino 700FI was a popular choice for its performance and durability.
Manual Value Proposition:
Provides comprehensive, factory-authorized information for DIY maintenance and repair, saving owners time and money compared to dealership service.
Manual Benefits:
Empowers owners to perform their own maintenance and repairs with confidence, understand their vehicle better, and maintain its optimal performance and lifespan.
Engine Service:
Complete engine overhaul, diagnosis, repair, and troubleshooting for the 686cc liquid-cooled, SOHC, 4-valve, single-cylinder engine.
Fuel System:
Fuel injection system (FI), fuel pump, injectors, fuel tank, fuel lines, and EVAP system.
Transmission And Drivetrain:
CVT (Continuously Variable Transmission) system, drive belts, clutches (primary and secondary), torque converter, drive shafts, differentials (front and rear), and wheel hubs.
Braking System:
Hydraulic disc brakes (front and rear), brake calipers, master cylinder, brake lines, brake fluid specifications, and bleeding procedures.
Suspension And Steering:
Independent front and rear suspension, shock absorbers, springs, control arms, bushings, steering wheel, steering column, tie rods, and steering rack.
Electrical System:
Complete electrical system diagnosis and repair, including battery, charging system (stator, rectifier/regulator), ignition system, lighting (headlights, taillights, brake lights), starter motor, and wiring diagrams.
Cooling System:
Radiator, cooling fan, coolant hoses, water pump, thermostat, and coolant type specifications.
Exhaust System:
Exhaust pipes, muffler, catalytic converter, and mounting hardware.
Frame And Body:
Chassis, frame components, body panels, seats, steering wheel, dashboard, cargo bed, and trim.
Routine Maintenance:
Oil changes, filter replacements, spark plug checks, air filter cleaning/replacement, lubrication points, and general inspection.
Troubleshooting:
Detailed diagnostic procedures for common and uncommon issues, symptom-based troubleshooting guides.
Repair Procedures:
Step-by-step instructions for all mechanical and electrical repairs, from minor adjustments to major component overhauls.
Rebuild Instructions:
Comprehensive instructions for rebuilding major components like the engine, transmission, and differentials.
Wiring Diagrams:
Detailed electrical wiring diagrams with component identification and color coding for accurate diagnosis and repair.
Depth Of Coverage:
A-Z coverage, from basic maintenance to advanced diagnostics and complete factory-level repairs.
Engine Type:
4-stroke, Liquid-cooled, SOHC, 4-valve, Single-cylinder
Bore X Stroke:
100.0 mm x 83.9 mm
Fuel Induction:
Fuel Injection (Mikuni 41mm throttle body)
Ignition:
TCI (Transistor Controlled Ignition)
Horsepower Estimate:
Approximately 45-50 HP (exact figures often not publicly disclosed by Yamaha for this model).
Torque Estimate:
Approximately 40-45 lb-ft (exact figures often not publicly disclosed by Yamaha for this model).
Fuel Type:
Unleaded gasoline, 87 octane (minimum)
Transmission Type:
Constant Velocity Transmission (CVT) with Hi/Lo range and Reverse
Drive System:
Shaft Drive, On-Command 4WD (with 2WD/4WD/4WD+Differential Lock selection)
Clutch Type:
Automatic centrifugal clutch (primary), adjustable secondary clutch
Gear Ratios:
Specific ratios for Hi, Lo, and Reverse are detailed within the manual.
Transmission Fluid Type:
Yamaha's recommended CVT fluid or equivalent API GL-4, SAE 80W-90 hypoid gear oil for differential and final drive.
Length:
Approx. 107.9 in (2,740 mm)
Width:
Approx. 64.2 in (1,630 mm)
Height:
Approx. 75.2 in (1,910 mm)
Wheelbase:
Approx. 79.7 in (2,025 mm)
Cargo Bed Capacity:
Approx. 26.9 gal (102 L) / 198.4 lbs (90 kg)
Dry Weight:
Approx. 1,025 lbs (465 kg)
Towing Capacity:
Not officially rated for towing, but commonly used for light trailering.
Payload Capacity:
Approx. 950 lbs (431 kg)
Infotainment System:
Basic instrumentation including speedometer, odometer, trip meter, fuel gauge, and indicator lights. No advanced infotainment features typical of modern vehicles.
Driver Assistance Features:
On-Command 4WD system with differential lock provides enhanced traction control. No electronic driver-assistance systems.
Connectivity Features:
N/A. Primarily designed for off-road utility.
Engine Oil Change:
Every 100 hours or 6 months (whichever comes first), under normal use. More frequently under severe use.
Air Filter Inspection:
Every 20 hours or 1 month. Clean or replace as needed.
Spark Plug Check:
Every 100 hours or 6 months.
Cvt Belt Inspection:
Every 20 hours or 1 month. Replace if wear exceeds specifications.
Engine Oil Type:
Yamalube 4 (or equivalent) SAE 10W-40 API SG or higher, JASO MA certified 4-stroke motorcycle oil.
Engine Oil Capacity:
Approx. 3.0 US qt (2.8 L) with filter change.
Cooling System Coolant:
High-quality ethylene glycol-based antifreeze mixed with distilled water (50/50 ratio).
Brake Fluid Type:
DOT 3 or DOT 4 hydraulic brake fluid.
Common Problems:
CVT belt wear, water pump seal leaks, front differential seal leaks, occasional electrical connector issues due to environmental exposure.
Preventative Maintenance:
Regularly cleaning and inspecting the CVT, checking seals, and ensuring electrical connections are clean and protected can mitigate common issues.
Brand History:
Yamaha Motor Company, established in 1955, has a long-standing reputation for manufacturing high-quality motorcycles, ATVs, watercraft, and other recreational vehicles.
Rhino Lineage:
The YXR700FI Rhino was an evolution of Yamaha's utility SxS line, building on the success of earlier models. The 700FI model introduced fuel injection for improved performance and efficiency.
Production Period:
The YXR700FI was produced from 2008 to 2009, succeeding the carbureted YXR660F model and preceding the introduction of the Viking line.
