Description

🏷️ Basic Information

Identification

Make:

Plymouth

Model:

Fury, Satellite, Barracuda, Valiant, Signet

Year:

1964, 1965

👋 Introduction

Market Position

Target Audience:

Professional mechanics, auto repair shops, and dedicated Mopar enthusiasts.

Value Proposition:

Provides comprehensive, factory-authorized information for the repair and maintenance of a wide range of 1964-1965 Plymouth models.

Competitive Analysis

Advantage:

Covers multiple popular Plymouth models and trim levels within a single, extensive volume.

Key Features

Comprehensiveness:

Details nearly every mechanical and electrical system on the specified vehicles.

Accuracy:

Based on original Chrysler Corporation engineering data.

📋 Manual Details

Coverage Areas

Manual Type:

Factory Service Manual

Page Count:

Language:

English

Format:

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Disassembly, inspection, assembly, tuning, diagnosis for all applicable engines.

Fuel System:

Carburetor systems (Holley, Carter, Stromberg), fuel pumps, lines, tanks, and emission controls.

Ignition System:

Distributor service, coil, points, condenser, spark plug specifications, troubleshooting.

Cooling System:

Radiator, water pump, thermostat, hoses, fan, coolant specifications.

Exhaust System:

Mufflers, pipes, catalytic converter (if applicable), mounting.

Transmission Manual:

3-speed, 4-speed manual transmission overhaul, adjustment, fluid specifications.

Transmission Automatic:

TorqueFlite A727 and A904 automatic transmission diagnosis, overhaul, fluid specifications, band adjustments.

Drive Axles:

Rear axle assembly, differential service, axle shafts, lubrication.

Suspension Front:

Ball joints, tie rods, control arms, torsion bars (on some models), kingpins, steering knuckle service.

Suspension Rear:

Leaf springs, shock absorbers, U-bolts, control arms (on some models).

Brakes Hydraulic:

Master cylinder, wheel cylinders, brake lines, brake fluid specifications, bleeding procedures.

Brakes Drum:

Brake shoe adjustment, relining, drum machining specifications.

Steering System:

Steering column, steering gear (worm and sector, recirculating ball), power steering system (if equipped).

Electrical System:

Wiring diagrams, battery, generator/alternator, voltage regulator, starter motor, lighting, instrumentation.

Body And Trim:

Panel removal, interior components, upholstery, weatherstripping, exterior trim.

Heating And Air Conditioning:

Heater core, blower motor, ventilation system, A/C system components and servicing (if equipped).

Chassis And Frame:

Frame construction, body mounting, lubrication points.

Procedures Included

General Maintenance:

Oil changes, lubrication, filter replacements, tire rotations, tune-ups.

Engine Rebuilding:

Complete engine overhaul procedures, including piston ring installation, bearing replacement, cylinder head rebuilding.

Transmission Overhaul:

Detailed step-by-step instructions for rebuilding both manual and automatic transmissions.

Brake Service:

Drum brake shoe replacement, adjustment, master cylinder and wheel cylinder service, bleeding.

Steering Repair:

Steering gear adjustment, tie rod end replacement, power steering pump and gearbox service.

Electrical Troubleshooting:

Diagnostic procedures for common electrical faults using wiring diagrams.

Suspension Alignment:

Specifications and procedures for front-end alignment (caster, camber, toe).

Carburetor Tuning:

Adjustment procedures for various carburetor models to ensure optimal engine performance.

Body Panel Replacement:

Instructions for removing and installing fenders, hoods, doors, and other body panels.

Technical Depth

Diagnostic Charts:

Includes comprehensive diagnostic flowcharts for identifying and resolving common issues.

Torque Specifications:

Precise torque values for all critical fasteners across all systems.

Clearances And Tolerances:

Detailed specifications for engine and transmission component clearances and wear tolerances.

Troubleshooting Guides:

Systematic troubleshooting for electrical, mechanical, and performance issues.

Wiring Diagrams:

Complete, easy-to-read wiring diagrams for all electrical systems.

Special Tools:

Lists and descriptions of special tools required for specific repair procedures.

📊 Manual Specifications

File Format

Binding Type:

Staple-bound or perfect-bound (typical for factory manuals of this era).

Paper Type:

Durable, coated paper designed for workshop use.

Print Quality:

High-quality, clear printing with legible diagrams and text.

⚙️ Engine Specifications

Primary Engine

Plymouth Fury 1964 1965:

361 CID V8 (Poly), 383 CID V8 (B-series), 426 CID V8 (Ramcharger/Super Commando), 413 CID V8 (Wedge - limited)

Plymouth Satellite 1965:

273 CID V8 (LA-series), 318 CID V8 (Poly), 361 CID V8 (Poly)

Plymouth Barracuda 1964 1965:

273 CID V8 (LA-series, optional Hi-Po), 225 CID Slant Six (G-series)

Plymouth Valiant Signet 1964 1965:

170 CID Slant Six (G-series), 225 CID Slant Six (G-series), 273 CID V8 (LA-series - 1965)

Performance

Horsepower Ranges:

Approximately 145 HP (Slant Six) to over 400 HP (426 Ramcharger).

Torque Ranges:

Approximately 245 lb-ft (Slant Six) to over 480 lb-ft (426 Ramcharger).

Fuel System

Carburetion Types:

Single-barrel (e.g., Carter BBD on Slant Six), Two-barrel (e.g., Carter AVS on V8s), Four-barrel (e.g., Holley on performance V8s).

🔧 Transmission

Standard

Manual Transmissions:

3-speed manual, 4-speed manual (e.g., Chrysler A833).

Optional

Automatic Transmissions:

TorqueFlite A727 (heavy duty), TorqueFlite A904 (light duty).

Features

Shifter Types:

Column-mounted shifters, floor-mounted shifters for performance models.

📐 Dimensions

Exterior

Wheelbase Range:

Approx. 106 inches (Valiant/Barracuda) to 119 inches (Fury).

Overall Length Range:

Approx. 177 inches (Valiant) to 213 inches (Fury).

Weights

Curb Weight Range:

Approx. 2,900 lbs (Valiant Six) to 4,000+ lbs (Fury V8).

🛡️ Safety Features

Ratings

Crash Test Data:

No standardized crash testing as performed today. Safety features focused on basic occupant protection.

Active Features

Brakes:

Front and rear drum brakes. Power assist brakes optional on some models. Heavy-duty brake options available.

Passive Features

Seat Belts:

Front seat belts often optional, rear seat belts uncommon. Lap belts standard on some models.

Steering Column:

Collapsible steering column was a developing safety feature of the era.

💡 Technology Features

Infotainment

Radio:

AM radio standard, FM radio optional. Push-button tuning common.

Speakers:

Typically one or two speakers (dash-mounted).

Driver Assistance

Cruise Control:

Optional on higher trim models and larger engines.

Connectivity

Phone Integration:

Not applicable. No integrated phone connectivity.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Recommended every 3,000-4,000 miles or 3-6 months, depending on usage and oil quality of the era.

Tune Up Interval:

Points and condenser service typically every 10,000-15,000 miles. Spark plugs every 20,000-30,000 miles.

Transmission Service:

Automatic transmission fluid and filter change recommended every 20,000-30,000 miles. Manual transmission fluid inspection/change at similar intervals.

Fluid Specifications

Engine Oil:

SAE 10W-30 or 10W-40 (depending on climate and original recommendations, often straight 30W was also common). Consult manual for specific viscosity.

Transmission Fluid Auto:

Dexron-II or equivalent (Chrysler fluid Type A Sufix A).

Transmission Fluid Manual:

GL-4 gear oil, SAE 90.

Brake Fluid:

DOT 3 Heavy Duty Hydraulic Brake Fluid.

Coolant:

Ethylene glycol antifreeze mixed with water (50/50 ratio). Consult manual for specific type and capacity.

Known Issues

Engine Sludge:

Older engines prone to sludge buildup due to shorter oil change intervals and lower quality oils used historically. Regular maintenance is key.

Carburetor Wear:

Diaphragms and gaskets in original carburetors can degrade over time, leading to fuel leaks or poor running conditions.

Electrical Component Failure:

Generators, voltage regulators, and wiring insulation can degrade, leading to charging system issues or intermittent electrical faults.

Suspension Wear:

Ball joints, tie rod ends, and bushings can wear out, affecting steering and alignment.

Rust And Corrosion:

Common for vehicles of this era, particularly in areas exposed to road salt and moisture.

📚 Vehicle History

Brand Heritage

Plymouth Positioning:

Plymouth was Chrysler Corporation's entry-level brand, offering reliable and competitively priced vehicles.

Model Evolution

Fury:

Evolved from the Plymouth Belvedere line, becoming a distinct full-size model. Known for its styling and performance options.

Satellite:

Introduced in 1965 as a higher-trim version of the Belvedere, offered in various body styles.

Barracuda:

Plymouth's first compact muscle car, based on the Valiant platform. A competitor to the Ford Mustang.

Valiant Signet:

The Valiant was Chrysler's compact offering. The Signet was the top trim level, often featuring more amenities and distinct styling.

Production

Manufacturing Location:

Primarily Detroit, Michigan, and other Chrysler assembly plants in the USA.

🏆 Awards & Recognition

Recognitions

Collectible Status:

These models are highly collectible, particularly performance variants like the Barracuda and Fury models with larger V8 engines. Strong enthusiast communities exist.

Ratings

Reliability Perception:

Generally considered robust and well-built for their era, though specific issues like rust and electrical components require attention.
