Yamaha XV750 Virago 1981-1983 Workshop Service Repair Manual

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

Welcome to the comprehensive service and repair manual for the XV750 Virago, covering model years 1981, 1982, and 1983. Introduced in 1981, the XV750 Virago was a pioneering entry into...

23 people are viewing this right now

类型: Motorcycle

斯库: 51071

标签: 1981 1982 1983 Motorcycle Motorcycles Virago XV750 Virago Yamaha

产品多属性

Description

Welcome to the comprehensive service and repair manual for the XV750 Virago, covering model years 1981, 1982, and 1983. Introduced in 1981, the XV750 Virago was a pioneering entry into the cruiser market, blending classic American styling with reliable Japanese engineering. This V-twin motorcycle, featuring a 748cc engine and shaft drive, offered a distinctive aesthetic that competed with other mid-size cruisers of its era, appealing to riders seeking a blend of style and dependable performance. Its design philosophy centered on providing a comfortable riding experience and a strong visual presence, establishing the Virago line as a significant offering in the motorcycle portfolio. This workshop service repair manual provides complete factory-level guidance for the XV750 Virago. It encompasses detailed procedures for engine maintenance and rebuilds, fuel system servicing, transmission and clutch operations, and comprehensive electrical system diagnostics, including wiring diagrams. Additionally, the manual covers brake system maintenance, suspension and steering adjustments, frame and bodywork, wheels, tires, and exhaust system care. With systematic troubleshooting guides and repair instructions, this manual is an essential resource for owners, mechanics, and technicians aiming to maintain, repair, and restore their XV750 Virago to optimal working condition.

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

XV750 Virago

Years Covered:

1981, 1982, 1983

Codes

Vin Prefix:

👋 Introduction

Market Position

Category:

Cruiser Motorcycle

Target Audience:

Owners and technicians performing maintenance, repair, and restoration

Competitive Analysis

Comparison To Competitors:

The Virago line competed with other mid-size cruisers like the Honda Shadow and Kawasaki Vulcan, offering a distinct Japanese take on the American cruiser styling.

Key Features

Design Philosophy:

Yamaha's Virago series aimed to blend classic American cruiser aesthetics with Japanese engineering reliability and innovation.

📋 Manual Details

Coverage Areas

Primary Coverage:

Complete factory service and repair

Diagnostic Coverage:

Troubleshooting and repair procedures

Page Count

Estimated Pages:

Hundreds (specific count not provided, implies comprehensive)

Manual Type

Type:

Workshop Service Repair Manual

Language

Language:

English

Format

Format:

PDF Download

📖 Manual Coverage

Systems Covered

Engine:

Comprehensive coverage including disassembly, inspection, assembly, timing, cooling, and lubrication

Fuel System:

Carburetor tuning, cleaning, and repair; fuel tank, fuel pump, and fuel lines

Transmission:

Clutch operation, gearbox disassembly and assembly, shift mechanism

Electrical System:

Ignition system, charging system (stator, regulator/rectifier), lighting, starting system, battery service, wiring diagrams

Brakes:

Front and rear brake system maintenance, hydraulic system bleeding, pad replacement, caliper service

Suspension And Steering:

Front fork service, rear shock absorber replacement, steering head bearing adjustment, wheel bearing service

Frame And Bodywork:

Frame inspection, body panel removal and installation, fairing repair (if applicable), seat maintenance

Wheels And Tires:

Tire pressure checks, wheel removal and installation, spoke tensioning (if applicable)

Exhaust System:

Muffler and pipe inspection and replacement

Procedures Included

Maintenance:

Regular service checks, lubrication points, filter replacement, spark plug replacement

Troubleshooting:

Systematic diagnostic procedures for common and uncommon faults

Repair:

Step-by-step repair instructions for all major and minor components

Rebuilds:

Complete engine and transmission rebuild procedures

Technical Depth

Depth:

Comprehensive; suitable for both DIY enthusiasts and professional mechanics

Diagnostics Detail:

Detailed fault finding charts, symptom-to-cause analysis, and electrical diagnostic flowcharts

📊 Manual Specifications

File Format

Format:

Print Quality

Quality:

High-resolution, designed for clear printing of text and diagrams

Binding Type

Binding:

N/A (Digital Download)

Paper Type

Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Type:

748cc, V-twin, 4-stroke, SOHC, 2 valves per cylinder

Bore X Stroke:

74.0 mm x 85.0 mm

Cooling System:

Air-cooled

Compression Ratio:

8.7:1

Performance

Horsepower Est:

Approx. 55-60 HP @ 6500 RPM (Varies by market and tuning)

Torque Est:

Approx. 60-65 Nm @ 4000 RPM (Varies by market and tuning)

Fuel System

Carburetor Type:

Dual Mikuni BS34 carburetors

Fuel Capacity:

13.0 Liters (3.4 US gallons)

🔧 Transmission

Standard

Type:

5-speed constant mesh

Features

Clutch Type:

Wet, multiple disc

Final Drive:

Shaft drive

📐 Dimensions

Exterior

Length Est:

2250 mm (88.6 in)

Width Est:

840 mm (33.1 in)

Height Est:

1170 mm (46.1 in)

Weights

Dry Weight Est:

202 kg (445 lbs)

Wet Weight Est:

217 kg (478 lbs)

🛡️ Safety Features

Ratings

Crash Safety Motorcycle:

N/A (Motorcycle safety is primarily based on design and rider skill, not standardized crash ratings)

Active Features

Braking System:

Front: Single disc brake; Rear: Drum brake (Early models may vary)

Passive Features

Lighting:

Halogen headlamp, taillight, turn signals

💡 Technology Features

Infotainment

Infotainment Features:

N/A (Vintage motorcycle; basic instrumentation)

Driver Assistance

Assistance Features:

Connectivity

Connectivity Features:

🔧 Maintenance

Service Intervals

Oil Change:

Every 3,000-5,000 km (1,800-3,000 miles) or annually, whichever comes first

Air Filter Cleaning:

Every 6,000 km (3,700 miles)

Spark Plug Replacement:

Every 10,000-12,000 km (6,000-7,500 miles)

Valve Clearance Check:

Every 10,000-12,000 km (6,000-7,500 miles)

Fluid Specifications

Engine Oil Type:

Yamalube 4 (or equivalent) SAE 20W-40 API SE, SF or SG

Engine Oil Capacity:

2.2 L (2.3 US qt) without filter change; 2.4 L (2.5 US qt) with filter change

Brake Fluid Type:

DOT 3 or DOT 4

Final Drive Oil Type:

Yamalube Gear Oil (or equivalent) SAE 80 API GL-4

Known Issues

Common Problems:

Carburetor gumming if not run regularly, potential for stator failure, worn steering head bearings, oil leaks from engine seals.

Electrical Issues:

Aging wiring harnesses can lead to intermittent electrical faults; regulator/rectifier failure can cause charging issues.

📚 Vehicle History

Brand Heritage

Yamaha Motorcycles:

Yamaha Motor Company, founded in 1955, has a rich history in motorcycle manufacturing, leveraging its expertise from musical instrument production in its early days.

Model Evolution

Virago Introduction:

The XV750 Virago was introduced in 1981 as Yamaha's first true cruiser, designed to capture a segment of the growing American market for retro-styled motorcycles.

Virago Series:

The Virago line expanded over the years with different engine sizes (e.g., XV500, XV1100), but the core styling and engineering principles remained consistent.

Production

Manufacturing Location:

Primarily Japan

🏆 Awards & Recognition

Recognitions

Motorcycle Awards:

While specific awards are not readily documented for this model year, the Virago line was generally well-received for its styling and market segment entry.
