Positioning:
Luxury Sedan
Competitors:
Cadillac DeVille, Lincoln Continental, Buick Electra/Park Avenue
Brand Image:
American luxury, comfort, spaciousness, value for money
Model Highlights:
Flagship sedan, plush ride, quiet interior, distinctive styling
Powertrain:
Engine, Fuel System, Exhaust System, Transmission, Drivetrain
Chassis:
Suspension, Steering, Brakes, Wheels, Tires
Electrical:
Starting and Charging System, Ignition System, Lighting, Instrumentation, Power Accessories, Climate Control Electrical, Anti-theft Systems (if applicable)
Body:
Body and Frame, Exterior Trim, Interior Trim, Doors, Windows, Seats, HVAC System (Mechanical)
General Maintenance:
Oil Changes, Filter Replacements, Fluid Checks and Replacements, Tune-ups
Engine Repair:
Engine Disassembly and Reassembly, Head Gasket Replacement, Piston and Ring Service, Valve Train Service
Transmission Repair:
Automatic Transmission Overhaul, Fluid and Filter Changes, Torque Converter Service
Brake Service:
Brake Pad Replacement, Rotor Resurfacing/Replacement, Brake Caliper Service, Brake Fluid Flush
Suspension Steering:
Shock Absorber/Strut Replacement, Ball Joint Service, Tie Rod End Replacement, Power Steering System Service
Electrical Diagnostics:
Wiring Diagrams, Component Testing, Fault Diagnosis
Troubleshooting:
Diagnostic Flowcharts, Symptom-Based Troubleshooting
Depth:
Comprehensive: Covers basic maintenance to complete overhaul and diagnostics.
Engine 1 Displacement:
5.2 L (318 cubic inches)
Engine 1 Configuration:
V8 OHV
Engine 1 Bore X Stroke:
3.91 x 3.31 in (99.3 x 84.2 mm)
Engine 1 Compression Ratio:
8.5:1
Engine 1 Horsepower:
140-145 hp @ 3200-3600 rpm (approx.)
Engine 1 Torque:
260-265 lb-ft @ 1600-2000 rpm (approx.)
Engine 2 Displacement:
3.3 L (201 cubic inches)
Engine 2 Configuration:
V6 OHV
Engine 2 Bore X Stroke:
3.66 x 3.31 in (93.0 x 84.2 mm)
Engine 2 Compression Ratio:
8.4:1
Engine 2 Horsepower:
147 hp @ 4500 rpm (approx.)
Engine 2 Torque:
180 lb-ft @ 2800 rpm (approx.)
Fuel Delivery Engine 1:
Throttle Body Injection (TBI) - Single point
Fuel Delivery Engine 2:
Multi-Port Fuel Injection (MPI)
Fuel Type:
Unleaded Gasoline (87 Octane Minimum)
NHTSA Side Impact Rating:
Not explicitly rated by NHTSA for this era in modern standards, but designed to meet contemporary safety regulations.
ABS:
Optional Anti-lock Braking System (ABS) on front wheels, optional on rear.
Airbags:
Driver-side airbag standard from 1990 onwards. Passenger airbag not available.
Seatbelts:
3-point front seat belts with shoulder belt adjusters, rear lap belts.
Body Construction:
Unibody construction with front and rear crumple zones.
Audio System:
Optional premium sound systems, cassette player standard, CD player optional.
Climate Control:
Manual or optional automatic climate control with electronic features.
Phone Integration:
Not available in the modern sense; provisions for aftermarket installations.
Oil Change Interval:
Every 3,000 miles or 3 months (using conventional oil).
Transmission Fluid Change Interval:
Every 30,000-40,000 miles or 24 months.
Coolant Flush Interval:
Every 30,000 miles or 24 months.
Spark Plug Replacement Interval V8:
Approximately 30,000 miles (V8).
Spark Plug Replacement Interval V6:
Approximately 60,000-100,000 miles (V6 - platinum plugs).
Engine Oil Spec:
API SG, SAE 5W-30 or 10W-30 (check owner's manual for ambient temperature ranges)
Coolant Spec:
Chrysler Long Life (Green) Antifreeze/Coolant (50/50 mix)
Common Complaints:
Transmission issues (especially the 3-speed auto), electronic sensor failures, water pump leaks, AC system component degradation, dashboard cracks.
Typical Repairs:
Replacement of fuel pumps, alternator, radiator, heater core, suspension components (ball joints, tie rods), brake system components.
Brand Focus:
Chrysler Corporation's long history of producing large, comfortable sedans.
Previous Generation:
Based on the Chrysler New Yorker Fifth Avenue (1988-1989).
Platform Sharing:
Shared the Y-body platform with other Chrysler luxury models like the New Yorker, Imperial, and Dodge Dynasty.
Design Era:
Fifth generation of the 'K-car' derivative, emphasizing a larger, more substantial presence compared to earlier models.
Production Years Model:
1990-1993
Manufacturing Location:
USA (Belvidere, Illinois)
