This workshop service repair manual covers the Magna, Verada, and Sigma V3000 R and S Series models produced between 1991 and 1996. Built on the LH platform, these vehicles offered a range of configurations, including sedan and wagon body styles, and were powered by the 6G7x V6 engine family, typically around 3.0 liters, with potential for earlier 2.6-liter Sigma variants. Known for their comfort, performance, and value, these models were primarily manufactured in Australia and Japan. The engineering quality and reliability of vehicles from this era are well-regarded, making them a strong choice for those seeking dependable transportation.
This comprehensive manual is designed for both do-it-yourself enthusiasts and professional mechanics, providing the detailed technical information necessary to maintain and repair these vehicles. It covers a vast array of systems, including engine mechanicals, engine management, brakes, suspension, steering, drivetrain, electrical systems, HVAC, and body/chassis components. Within its extensive pages, you will find step-by-step repair procedures, advanced diagnostic information with trouble codes and diagnostic charts, factory maintenance schedules, and complete technical specifications. The manual's structure, subdivided into group categories with clear, illustrated instructions, ensures that owners and technicians can effectively keep their Magna, Verada, or Sigma V3000 R and S Series in optimal working condition.
Model:
Magna, Verada, Sigma V3000 R And S Series
Platform:
Mitsubishi LH platform
Target Audience:
Do-it-yourself enthusiasts and experienced professional mechanics.
Value Proposition:
Provides the technical information necessary to maintain and restore the vehicle's performance and reliability, serving as an inexpensive way to keep the vehicle working properly.
Manual Structure:
Subdivided into various group categories with detailed diagnostic, disassembly, repair, and installation procedures, accompanied by complete specifications and tightening references.
Instructional Style:
Step-by-step instructions based on complete disassembly, guided by hundreds of photos and illustrations, with numbered instructions, bold figure numbers, and enlarged insets for clarity.
Covered Models:
Mitsubishi Magna, Verada, Sigma V3000 R And S Series (1991-1996)
Estimated Page Count:
Extensive (typically 1000+ pages for comprehensive factory manuals)
Manual Type:
Workshop Service Repair Manual
Format:
Adobe Acrobat Document (.pdf) / WinRAR ZIP archive (.zip)
Engine Mechanical:
Overhaul, Rebuilding, Timing Belt Service, Engine Performance
Engine Management:
Trouble Codes, Computer Diagnostic Trouble Tree Charts, Computer Diagnostic Codes, Firing Orders
Brakes:
Brake Servicing Procedures, Front End And Alignment Procedures And Specifications
Suspension Steering:
Suspension, Front End And Alignment Procedures And Specifications
Drivetrain:
Transmission Removal And Installation, Transmission In Car Servicing, U-Joint And CV-Joint Service Procedures
Electrical:
Wiring Diagrams, Complete Wiring Diagrams
HVAC:
Air Conditioning Service And Capacities
Diagnostic Procedures:
Diagnostic, Troubleshooting And Diagnostics, Computer Diagnostic Trouble Tree Charts
Repair Procedures:
Disassembly, Repair, Installation, Engine Overhaul And Rebuilding, Timing Belt Replacement, Brake Servicing Procedures, U-Joint And CV-Joint Service Procedures, Repair Procedures
Maintenance Procedures:
Factory Maintenance Schedules And Charts, Serpentine Belt Routings With Diagrams, Timing Belt Service Procedures
Diagnostic Depth:
Advanced diagnostics including computer diagnostic codes and trouble trees.
Rebuild Depth:
Comprehensive engine overhaul and rebuilding procedures.
Specification Detail:
Complete specifications and tightening references for all covered systems and components.
File Format Details:
Digital download (PDF/ZIP), providing instant access and portability. Compatible with all versions of Windows & Mac.
Print Quality Description:
Designed for clear printing of individual pages or the entire manual, with high-quality illustrations and diagrams.
Binding Type:
N/A (Digital Format)
Paper Type:
N/A (Digital Format)
Engine Family:
Mitsubishi 6G7x V6 family (likely 6G72 SOHC, 6G72 DOHC, or 6G73 SOHC depending on specific variant).
Typical Displacement:
3.0L (182 ci) and potentially 2.6L (158 ci) for earlier Sigma variants.
Power Output Range:
Approximately 100-125 kW (134-168 hp) for 3.0L V6 models, varying by specific engine and configuration.
Torque Output Range:
Approximately 230-260 Nm (170-192 lb-ft) for 3.0L V6 models.
Fuel Delivery:
Electronic Fuel Injection (EFI)
Ignition System:
Distributorless Ignition System (DIS) or Distributor-based system, depending on specific model year and engine.
Timing Belt Material:
Reinforced rubber composite
Timing Belt Replacement Interval:
Typically 90,000 km (56,000 miles) or 5 years, whichever comes first (refer to manual for precise interval).
Automatic Transmission:
Likely the F4AEL or F5A51 automatic transmission depending on engine and model.
Manual Transmission:
Possible availability of a 5-speed manual transmission for certain trims/engine variants.
Transmission Fluid Type:
Diamond SP-III or equivalent ATF (Automatic Transmission Fluid) - refer to manual for exact specification and capacity.
Body Styles:
Sedan and Wagon (Estate/Station Wagon).
Wheelbase Range:
Approximately 2735 mm (107.7 inches).
Curb Weight Range:
Approximately 1450-1600 kg (3197-3527 lbs) depending on configuration.
Crash Test Data:
Limited publicly available official crash test ratings for this specific era and region. Manual provides guidance on safety system repair.
Braking System:
Front ventilated discs, rear solid discs or drums (depending on model). ABS (Anti-lock Braking System) available on higher trims.
Restraint System:
Front airbags for driver and passenger (standard on later models), three-point seat belts with pretensioners.
Audio System:
Factory fitted radio/cassette player with optional CD changer. Speaker configurations varied by trim level.
ABS:
Anti-lock Braking System (ABS) was an option on higher trims and standard on later models.
Cruise Control:
Electronic cruise control typically available on higher-spec models.
Oil Change Interval:
Typically 10,000 km (6,000 miles) or 6 months. Refer to manual for exact interval and oil type.
Air Filter Replacement Interval:
Approximately 20,000 km (12,000 miles) or 12 months.
Engine Oil Specification:
API SJ or higher, SAE 10W-30 or 10W-40 viscosity (check manual for exact recommendation).
Coolant Type:
Ethylene glycol-based coolant with anti-corrosion additives (Mitsubishi Super Long Life Coolant or equivalent).
Brake Fluid Type:
DOT 3 or DOT 4 brake fluid.
Common Wear Items:
Timing belt, water pump, CV joints, suspension components (bushings, ball joints), and radiator can be common wear items.
Electrical Concerns:
Potential for minor electrical gremlins, faulty sensors, or wiring harness issues over time. Manual's wiring diagrams are crucial for diagnosis.
Engine Specific Issues:
V6 engines generally robust, but head gasket leaks on some variants and oil consumption on higher mileage units can occur. Timing belt tensioner failure can cause catastrophic engine damage.
Mitsubishi Motors:
Mitsubishi Motors Corporation, a Japanese multinational automotive manufacturer with a history of producing reliable and innovative vehicles.
Magna Verada Sigma:
These models represented Mitsubishi's mid-size and executive offerings in various markets, known for their comfort, performance, and value.
Manufacturing Locations:
Primarily produced in Australia (for the Australian market) and Japan.
Industry Awards:
While specific awards for this model range are not readily cited, Mitsubishi vehicles of this era were generally recognized for their reliability and value proposition in their respective market segments.
