Mercury Mariner (outboard) 135-150-150 XR6-150 Magnum III-150 EFI- 175 EFI-200 EFI 150-200-225 (1992 & Newer) (Super Magnum-ProMax) Service Manual

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Mercury Mariner Model: Outboard Year: 1992 & Newer Generation: Super Magnum-ProMax Series 📋 Manual Details Publication Manual Type: Service and Repair Manual Language: English Format:...

23 people are viewing this right now

类型: Outboard

斯库: 24656

标签: 135 150 150 EFI 150 Magnum III 150 XR6 175 EFI 1992 200 EFI 225 Beta Marine Magnum Models Marine Mercury Mercury Mariner Outboard Outboard Engines ProMax Super Magnum

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Mercury Mariner

Model:

Outboard

Year:

1992 & Newer

Generation:

Super Magnum-ProMax Series

📋 Manual Details

Publication

Manual Type:

Service and Repair Manual

Language:

English

Format:

PDF Download

Content

Target Audience:

Do-it-yourselfer and Experienced Mechanic

Coverage:

Step-by-step instructions, hundreds of photos and illustrations, detailed substeps, notes, cautions, warnings

⚙️ Engine Specifications

Engine 135

Engine Type:

2-Stroke

Displacement:

Approx. 2.0L (122 cu in)

Power:

135 HP

Engine 150

Engine Type:

2-Stroke

Displacement:

Approx. 2.0L (122 cu in)

Power:

150 HP

Engine 175 Efi

Engine Type:

2-Stroke (EFI)

Displacement:

Approx. 2.5L (153 cu in)

Power:

175 HP

Engine 200 Efi

Engine Type:

2-Stroke (EFI)

Displacement:

Approx. 2.5L (153 cu in)

Power:

200 HP

Engine 225

Engine Type:

2-Stroke

Displacement:

Approx. 3.0L (183 cu in)

Power:

225 HP

Engine Promax

Engine Type:

2-Stroke (High Performance)

Displacement:

Power:

Up to 225 HP (depending on specific ProMax model)

🔧 Transmission

Gearcase

Type:

Outboard Gearcase

Gear Ratio:

Varies by specific model and application (refer to manual for details)

🔧 Maintenance

Lubrication

Recommended Oil Type:

Mercury Outboard 2-Stroke Oil (TCW3 certified)

Oil Capacity Gearcase:

Varies by model, typically around 16-20 oz (refer to manual for exact capacity)

Cooling System

Cooling System Type:

Water Cooled

Water Pump Impeller Replacement Interval:

Recommended every 2-3 years or as needed based on operating conditions

Ignition

Spark Plug Type:

Specific Mercury or Champion spark plugs (refer to manual for exact part number)

Spark Plug Gap:

Refer to specific engine model specifications in the manual

📄 Electrical

Charging System

Charging System Type:

Alternator

Output Amperage:

Typically 10-20 Amps (Varies by model)

📄 Fuel System

Fuel Delivery

Fuel Type:

Unleaded gasoline

Fuel Octane Rating:

90-92 Octane Recommended (refer to manual for specific requirements)

Fuel Filter Replacement:

Recommended annually or as needed
