Segment:
Sportbike, Hyperbike
Target Audience:
Owners, technicians, enthusiasts seeking in-depth repair and maintenance knowledge.
Key Competitors:
Kawasaki ZZR1100, Honda CBR1000F, Yamaha FJ1200
Manual Value:
Provides factory-level diagnostic and repair procedures, saving significant costs on professional servicing.
Content Advantage:
Comprehensive diagrams, clear instructions, and accurate specifications for DIY repair and restoration.
Engine:
Detailed disassembly, assembly, inspection, tuning, and repair procedures for the 4-cylinder liquid-cooled engine.
Fuel System:
Carburetor identification, adjustment, cleaning, overhaul, and fuel pump operation.
Ignition System:
Ignition timing, coil testing, spark plug specifications, CDI unit diagnostics.
Cooling System:
Radiator, fan, thermostat, coolant specifications, and troubleshooting.
Transmission:
Clutch operation, gear inspection, shift mechanism, transmission oil specifications and replacement.
Suspension:
Front fork (telescopic) disassembly, seal replacement, oil type and level, rear shock absorber adjustment and service.
Brakes:
Front and rear brake caliper service, master cylinder overhaul, brake fluid specifications, bleeding procedures.
Electrical System:
Wiring diagrams, starter motor, alternator, battery specifications, lighting, fuse identification, switch testing.
Chassis Frame:
Frame inspection, steering head bearing service, swingarm removal and lubrication.
Bodywork:
Fairing removal and installation, seat service, fuel tank removal and installation.
Maintenance:
Regular scheduled maintenance, oil changes, filter replacements, chain adjustment, tire pressure checks.
Troubleshooting:
Diagnostic charts and step-by-step guides for common problems, symptom-based troubleshooting.
Repair:
Detailed instructions for component repair, replacement, and reassembly of major systems.
Diagnostics:
Procedures for testing electrical components, ignition system, fuel delivery, and mechanical systems.
Overhaul:
Complete rebuild procedures for the engine, transmission, and major sub-assemblies.
Depth:
Comprehensive coverage from basic rider maintenance to advanced engine rebuilds and electrical diagnostics.
Detail Level:
Includes torque specifications, clearance measurements, tolerances, and step-by-step instructions with diagrams.
Engine Type:
Inline 4-cylinder, 4-stroke, DOHC, 16-valve
Displacement:
937 cc (57.1 cu in)
Bore X Stroke:
73.0 mm x 55.5 mm (2.87 in x 2.19 in)
Compression Ratio:
11.3:1
Horsepower:
Approx. 125 hp @ 10,000 rpm (claimed)
Torque:
Approx. 65 lb-ft @ 7,500 rpm (claimed)
Carburetors:
4 x Mikuni BST36 constant-velocity carburetors
Fuel Capacity:
19 Liters (5.0 US gal)
Fuel Type:
Unleaded gasoline, 91 octane or higher
Oil Capacity With Filter:
3.6 Liters (3.8 US qt)
Engine Oil Type:
SAE 10W-40 API SG or SH
Engine Oil Change:
Every 3,000 miles (5,000 km) or 6 months.
Spark Plug Replacement:
Every 6,000 miles (10,000 km).
Air Filter Cleaning:
Every 3,000 miles (5,000 km), replace every 6,000 miles (10,000 km).
Chain Lubrication Adjustment:
Every 1,000 miles (1,600 km).
Valve Clearance Check:
Every 12,000 miles (20,000 km).
Coolant Type:
Ethylene glycol-based antifreeze, 50/50 mix with distilled water.
Common Wear Item:
Stalling at low RPMs due to carburetor jetting or vacuum leaks; clutch wear; front fork seal leaks.
Electrical Quirks:
Occasional stator or rectifier failures; corroded electrical connectors.
Performance Considerations:
Carburetor synchronization is critical for smooth running; airbox modifications can affect mixture.
