Target Audience:
Professional automotive technicians, Jaguar enthusiasts, DIY mechanics, and Jaguar owners seeking to understand and maintain their vehicles.
Value Proposition:
Offers a cost-effective and convenient alternative to expensive OEM paper manuals, providing detailed information in a digital format for easy access and printing.
Searchability:
PDF format allows for text search, enabling quick location of specific topics or parts.
Modularity:
Organized into over 70 separate PDF sections for modular access to information.
Engine Systems:
Engine mechanical (4.0L AJ6 and 5.3L V12), fuel injection (Lucas/Bosch), ignition, cooling, exhaust, lubrication, emissions.
Transmission Systems:
ZF 4HP24 automatic transmission, clutch (if applicable to specific variants), gearbox diagnostics and repair.
Brake Systems:
Hydraulic systems, ABS (Teves/Lucas Girling), disc brake service, parking brake.
Electrical Systems:
Full wiring diagrams, lighting, instrumentation, power accessories, engine management electronics, starter, charging system.
Suspension Steering:
Front and rear suspension geometry, components (bushings, ball joints, shock absorbers), power steering system.
Body Chassis:
Body construction, panels, doors, windows, seals, convertible top mechanisms, interior trim.
HVAC System:
Air conditioning, heating, ventilation system diagnosis and repair.
Maintenance Procedures:
Oil changes, filter replacements, coolant service, brake fluid flush, spark plug replacement, tune-ups.
Repair Procedures:
Engine rebuild, transmission overhaul, brake caliper replacement, suspension component repair, electrical diagnostics, fuel injector replacement.
Troubleshooting:
Diagnostic procedures for common and uncommon faults, fault codes interpretation (where applicable).
Wiring Diagrams:
Detailed and component-level wiring schematics for all electrical systems.
Part Layouts:
Illustrated diagrams showing component placement and identification.
Depth Of Coverage:
Comprehensive, covering everything from basic fluid checks to complete engine and transmission overhauls, suitable for professional mechanics and advanced DIYers.
Engine Options:
4.0L (3980cc) AJ6 Inline-6 and 5.3L (5343cc) V12 (HE/Shooter configurations).
Inline 6 Horsepower:
Approx. 223 bhp (166 kW) @ 4750 rpm
Inline 6 Torque:
Approx. 278 lb-ft (377 Nm) @ 3750 rpm
V12 Horsepower:
Approx. 275 bhp (205 kW) @ 5500 rpm (HE configuration)
V12 Torque:
Approx. 316 lb-ft (428 Nm) @ 3250 rpm (HE configuration)
Fuel Injection Type:
Lucas/Bosch Electronic Fuel Injection (EFI) with sequential or multi-point injection.
Ignition Type:
Distributorless Ignition System (DIS) for 4.0L, Lucas electronic ignition for V12.
Coupe Length:
Approx. 194.2 inches (4933 mm)
Convertible Length:
Approx. 196.1 inches (4981 mm)
Width:
Approx. 70.6 inches (1793 mm)
Height:
Approx. 49.6 inches (1260 mm)
Wheelbase:
Approx. 107.9 inches (2741 mm)
Curb Weight Inline 6:
Approx. 3950 lbs (1792 kg)
Curb Weight V12:
Approx. 4250 lbs (1928 kg)
Crash Test Information:
No specific NHTSA or Euro NCAP ratings available for this model year; rely on inherent Jaguar safety design and available features.
ABS:
Standard Anti-lock Braking System (ABS).
Airbags:
Driver airbag standard. Passenger airbag may be optional or not present on all models.
Seatbelts:
Three-point inertia-reel seatbelts front and rear.
Oil Change Interval:
Typically every 6,000 miles (9,600 km) or 12 months, whichever comes first (refer to manual for precise Jaguar recommendation).
Transmission Fluid Interval:
Recommended service every 30,000 miles (48,000 km) or 24 months.
Coolant Replacement:
Every 24,000 miles (38,400 km) or 24 months.
Engine Oil:
Refer to manual; typically a 10W-40 or 10W-50 synthetic or semi-synthetic oil meeting API SG/SH specifications. V12 may have specific requirements.
Power Steering Fluid:
Jaguar specified fluid (often Dexron II/III compatible).
Common Wear Items:
Fuel hoses (potential degradation), suspension bushings, cooling system components (radiator, hoses), ABS sensor failures, electrical connectors corrosion.
V12 Specifics:
V12 engines require meticulous maintenance; potential issues include HE injector failures and ignition system complexities. Thermal insulation in the engine bay requires attention.
Example Oil Filter:
Part number examples may vary by supplier, e.g., Fram PH5793, Mann W940/23, or OEM Jaguar C24547 (verify for specific engine).
Example Spark Plugs:
4.0L AJ6: NGK BCPR5ES-11 or Champion RC10LYC; V12: Champion XC12LYC or NGK BCPR7ES-11 (check manual for specific heat ranges and types).
Brand Legacy:
Jaguar, a marque synonymous with luxury, performance, and classic British motoring design.
Xjs Development:
Successor to the iconic E-Type, the XJS was initially launched in 1975 with a V12 engine. The 1994 model represents a significantly updated version following major facelifts and the introduction of the more efficient AJ6 inline-6 engine.
Production Period:
1975-1996. 1994 models are part of the later, facelifted series.
Manufacturing Location:
Coventry, England.
