🏷️ Basic Information

Make:

Ford

Model:

Bronco

Year:

1995

Generation:

Fifth Generation (1992-1996)

Body Style:

Full-size SUV (2-door removable hardtop and 4-door wagon)

👋 Introduction

Vehicle Segment:

Full-size, body-on-frame SUV, positioned as a capable off-road and utility vehicle.

Key Competitors 1995:

Chevrolet Tahoe/Suburban, GMC Yukon/Yukon XL, Jeep Grand Cherokee, Toyota Land Cruiser, Nissan Pathfinder.

Manual Usability:

Digital format allows for easy searching, printing of specific pages, and scalability of diagrams. Eliminates the wear and tear of physical manuals.

Technical Accuracy:

Based on factory documentation, ensuring the highest level of accuracy for all repair and maintenance procedures.

Digital Convenience:

All pages printable, easy to zoom in on images and diagrams.

📋 Manual Details

Coverage Scope:

All models and all repairs A-Z

Estimated Page Count:

Difficult to ascertain precisely without the manual itself, but typical factory service manuals for this era are extensive, often exceeding 1500 pages.

Manual Type:

Factory Service and Repair Manual

Accuracy Claim:

Exact same manual used by technicians at dealerships.

Language:

English

Format:

PDF (digital download)

Operating Systems:

Compatible with all versions of Windows and Mac.

📖 Manual Coverage

Engine Service:

Complete overhaul, diagnostics, fuel system, ignition, cooling, lubrication, emission controls, intake/exhaust systems.

Drivetrain Service:

Automatic transmission, manual transmission, transfer case, propeller shaft, drive shaft, differentials, axles.

Suspension Steering Brakes:

Front and rear suspension, steering column, power steering, brake systems (including parking brake), tire and wheel service.

Electrical Systems:

Ignition, starting, charging systems, lighting, instruments, audio, horn, wiper/washer, door locks, interior/exterior lighting, multiplex/CAN communication (where applicable).

Comfort And Convenience:

Air conditioning, supplemental restraint system (SRS), seat belts, cruise control, windshield/glass/mirrors, instrument panel, seats, engine hood/doors, exterior/interior trim.

Engine Immobilizer:

Coverage included, indicating system operation and potential troubleshooting.

Supplemental Restraint System:

Detailed information on the driver's airbag system, including diagnosis and replacement procedures.

Maintenance Procedures:

Scheduled maintenance, fluid changes, filter replacements, component inspection and lubrication.

Diagnostic Procedures:

Troubleshooting guides, symptom-based diagnostics, diagnostic trouble codes (DTCs), electrical circuit testing.

Repair Procedures:

Step-by-step instructions for component removal, installation, and adjustment for all major vehicle systems.

Schematics And Diagrams:

Complete wiring schematics, component diagrams, and exploded views for assembly and disassembly.

Body And Trim Repair:

Procedures for interior and exterior trim, body panels, doors, hood, and glass.

Depth Of Information:

Factory-level detail, encompassing everything from basic maintenance to complex engine and transmission rebuilds, including diagnostics and troubleshooting.

Diagnostic Tools:

Manual will cover the use of diagnostic tools and procedures relevant to the EEC-IV system for troubleshooting.

📊 Manual Specifications

File Type:

Portable Document Format (PDF)

Searchability:

Likely searchable text, allowing users to quickly find specific topics or components within the PDF.

Printability:

High-resolution, printable pages allowing for specific section printing and enlargement of diagrams.

Binding Method:

Digital (PDF), implies no physical binding. User prints and binds as needed.

Recommended Paper Type:

Standard copier paper for printing. Quality of printed diagrams may benefit from glossier paper.

⚙️ Engine Specifications

Engine Options 1995:

4.9L (302 cu in) V8 EFI; 5.8L (351 cu in) V8 EFI

4.9L V8 Horsepower:

Approx. 205 hp @ 4000 rpm (subject to variation)

4.9L V8 Torque:

Approx. 275 lb-ft @ 2400 rpm (subject to variation)

5.8L V8 Horsepower:

Approx. 245 hp @ 4200 rpm (subject to variation)

5.8L V8 Torque:

Approx. 375 lb-ft @ 2800 rpm (subject to variation)

Fuel Delivery:

Electronic Fuel Injection (EFI)

Engine Management System:

Ford EEC-IV (Electronic Engine Control) or later iteration, managing fuel and ignition timing.

🔧 Transmission

Standard Transmission:

4-speed Automatic Overdrive (E4OD/4R70W depending on engine/configuration)

Optional Transmission:

5-speed Manual Transmission (M5OD-R2)

Transfer Case:

Electronic Shift-On-The-Fly (ESOF) or manual transfer case options.

📐 Dimensions

Wheelbase Short Body:

104.7 inches (2659 mm)

Wheelbase Long Body:

118.7 inches (3015 mm) (4-door models)

Overall Length Short Body:

177.7 inches (4513 mm)

Overall Length Long Body:

191.5 inches (4864 mm) (4-door models)

Curb Weight Range:

Approx. 4,500 - 5,000 lbs (2041 - 2268 kg), depending on configuration.

Max Towing Capacity:

Varies significantly by engine, axle ratio, and configuration, but generally rated up to 7,000-8,000 lbs for properly equipped models.

🛡️ Safety Features

NHTSA Crash Ratings 1995:

Specific ratings for 1995 are not readily available in a consolidated format; earlier generations had mixed results. Ford emphasized frame strength and passive safety features for this generation.

Braking System:

Front disc, rear drum brakes. Optional rear disc brakes available on some trims. Anti-lock Braking System (ABS) typically on rear wheels only for 1995.

Airbags:

Driver-side airbag standard.

Seat Belts:

Front and rear seat belts, with shoulder belts for front occupants.

💡 Technology Features

Audio System:

Factory AM/FM stereo with cassette player, optional CD player. Basic speaker configurations.

Cruise Control:

Factory cruise control system available.

Vehicle Network:

Limited to basic diagnostic protocols; advanced CAN bus systems were not prevalent in this model year, though the manual mentions 'Multiplex/CAN Communication' likely referring to localized multiplexed systems for specific functions rather than a full OBD-II CAN network.

🔧 Maintenance

Oil Change Interval:

Typically every 3,000-5,000 miles or 3-6 months, depending on driving conditions. Refer to manual for specific recommendations.

Tune Up Interval:

Spark plugs and filters usually at 30,000-60,000 mile intervals, depending on specific components used.

Engine Oil Spec:

API Service SG or SH. Viscosity: 5W-30 or 10W-30 depending on ambient temperature. Check manual for precise recommendations.

Transmission Fluid Spec Auto:

Mercon (or equivalent Mercon V after updates).

Coolant Spec:

Ford Premium Engine Coolant (green) or equivalent ethylene glycol based coolant with corrosion inhibitors. 50/50 mix with distilled water.

Brake Fluid Spec:

DOT 3.

Power Steering Fluid Spec:

Mercon (or equivalent).

Common 1995 Bronco Issues:

Interior component wear (dashboard, seats), potential for ABS sensor failure, exhaust manifold leaks, transmission cooling line leaks, and rust in common Ford truck/SUV areas (wheel wells, rocker panels).

📚 Vehicle History

Ford SUV Legacy:

The Bronco nameplate has a long history of being Ford's flagship SUV, known for its ruggedness and off-road capability since its introduction in 1966.

Fifth Gen Development:

The fifth generation marked a significant shift to a more refined and modern SUV, transitioning from the compact Bronco II and sharing a platform with the Ford F-150 pickup truck.

Platform Sharing:

Shared platform with the 10th generation Ford F-150 (1992-1996), contributing to its robust build and capability.

Production Years:

1966-1996 (This specific manual covers the final production year of the fifth generation).

🏆 Awards & Recognition

Vehicle Awards 1995:

No specific major awards are widely cited for the 1995 Bronco itself, but the model line consistently received accolades for its off-road capability and utility.
