Model Years Covered:
1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005
Engine Variants Covered:
4.0L, 4.0L Supercharged, 4.2L, 4.2L Supercharged
Type:
Factory Workshop Service Repair Manual
Platform Compatibility:
Windows (XP, Vista, 7, 8, 10), Mac, Tablet, Phone (32/64-bit)
Powertrain:
Engine (cooling, supercharger cooling, fuel charging/controls, accessory drive, ignition, emission control, intake air, evaporative emissions, electronic controls), Automatic Transmission/Transaxle (cooling, external controls), Exhaust System, Fuel System (tank, lines, acceleration control, speed control)
Chassis:
Suspension (front, rear, wheels, tires, vehicle dynamic), Driveline (driveshaft, rear axle/differential)
Brakes Steering:
Brake System (front/rear disc, parking brake, hydraulic actuation, power brake, ABS, stability assist), Steering System (power steering, linkage, column, column switches)
Electrical:
Climate Control (air distribution/filtering, heating, ventilation, AC, control components), Instrumentation (cluster, horn, clock, message center, parking aid), Battery/Charging System, Information/Entertainment (audio, antenna, speakers), Lighting (exterior, interior, DRLs), Electrical Distribution, Module Communications Network, Wiring Harnesses, Electronic Feature Group (anti-theft, navigation, phone, multifunction modules)
Body Paint:
Body System (front end panels, closures, interior trim, exterior trim, mirrors, seating, glass/mechanisms, instrument panel/console, handles/locks/latches, wipers/washers, convertible top, bumpers, safety belts, SRS, body repairs, frame/mounting, uni-body/subframe)
Wiring Diagrams:
Power Distribution, Ground Distribution, Battery/Starter/Generator, Engine Management, Transmission, ABS/Traction Control, Climate Control, Instrumentation/Audible Warnings, Exterior/Interior Lighting, Steering/Mirrors/Suspension, Seat Systems, Door Locking/Security, Wash/Wipe, Window Lifts/Convertible Top, In-Car Entertainment/Telephone, SRS, Ancillaries, Vehicle Multiplex System
Ancillaries:
Covers various ancillary systems including wipers, washers, horns, and external/internal lighting systems.
Body Repairs:
Includes detailed procedures for body repairs, frame and mounting systems, and uni-body structure.
Restraint Systems:
Detailed coverage of the Safety Belt System and Supplemental Restraint System (SRS), including airbag system diagnostics and replacement procedures.
Repair Procedures:
Complete step-by-step instructions for all workshop procedures, including disassembly, inspection, repair, assembly, and adjustment of all vehicle systems.
Maintenance:
Routine maintenance procedures, fluid level checks, filter changes, belt replacements, and lubrication schedules.
Diagnostics:
Troubleshooting guides, fault code interpretation, symptom-based diagnostics for various systems.
Depth:
Comprehensive coverage from basic maintenance to advanced engine and transmission rebuilds, electrical system diagnostics, and body repair.
Illustrations:
Hi-Resolution illustrations, photos, and diagrams for clarity and ease of understanding.
Parts Guide Coverage:
Includes a parts guide for model years 1997-2005, detailing various components and their locations.
Manual Type Specificity:
This is a comprehensive 'Workshop Manual', equivalent to what a Jaguar dealership technician would use for repairs and diagnostics.
Engine Code 4.0L:
AJ-V8 (4.0L Naturally Aspirated and Supercharged)
Engine Code 4.2L:
AJ-V8 Gen III (4.2L Naturally Aspirated and Supercharged)
4.0L Na Horsepower:
Approximately 290 hp @ 6000 rpm (varies by model year)
4.0L Supercharged Horsepower:
Approximately 370 hp @ 6100 rpm (varies by model year)
4.2L Na Horsepower:
Approximately 300 hp @ 6000 rpm (varies by model year)
4.2L Supercharged Horsepower:
Approximately 400 hp @ 6000 rpm (varies by model year)
4.0L Na Torque:
Approximately 284 lb-ft @ 4250 rpm (varies)
4.0L Supercharged Torque:
Approximately 395 lb-ft @ 3600 rpm (varies)
4.2L Na Torque:
Approximately 290 lb-ft @ 4250 rpm (varies)
4.2L Supercharged Torque:
Approximately 413 lb-ft @ 3500 rpm (varies)
Fuel Delivery:
Sequential Multi-Port Fuel Injection (SPI)
Fuel Type:
Premium Unleaded Gasoline (91 octane or higher recommended)
Oil Change Interval:
Typically every 10,000 miles or 1 year, whichever comes first (refer to specific year/manual section for exact recommendation).
Transmission Fluid Service:
Recommended at 60,000-100,000 miles, or as per manual recommendations, especially for the ZF automatic transmissions.
Engine Oil Specification:
Synthetic 5W-30 or 5W-40 API certified (refer to manual for precise specification and capacity, e.g., Jaguar M2C153-E or similar).
Coolant Type:
Jaguar specific coolant or equivalent long-life coolant (e.g., GYS12024).
Brake Fluid Type:
DOT 4 Synthetic Brake Fluid.
Power Steering Fluid:
Jaguar specified power steering fluid (refer to manual for exact type and capacity).
Common Issues 4.0L:
Timing chain tensioner wear (especially early 4.0L models), Nikasil cylinder liner degradation (early 4.0L models), occasional gearbox issues, XK8 specific gearbox oil cooler leaks causing transmission failure.
Common Issues 4.2L:
Less prone to Nikasil issues; general wear and tear, potential water pump leaks, occasional ignition coil failures.
Body Paint Corrosion:
Check for potential corrosion, especially around wheel arches and sills on older models.
Suspension Wear:
Bushings and shock absorbers may require replacement due to age and mileage.
