Target Audience:
Owners of 1996 Oldsmobile LSS seeking to perform maintenance, repairs, and diagnostics.
Advantage:
Digital format offers convenience, searchability, and instant access compared to traditional printed manuals.
Feature 1:
Officially licensed and factory-derived information.
Feature 2:
Comprehensive coverage of all major vehicle systems.
Feature 3:
Step-by-step instructions with diagrams and schematics.
Feature 4:
Troubleshooting guides and diagnostic procedures.
Engine Mechanical:
Complete engine overhaul, disassembly, inspection, assembly for 3.8L V6 engines.
Engine Electrical:
Ignition system, fuel injection system (MPFI), starting and charging systems, sensor diagnostics, ECU troubleshooting.
Transmission:
Automatic transmission (4T60-E) overhaul, diagnostics, fluid service, control systems.
Brakes:
Hydraulic brake system, ABS (Anti-lock Braking System) diagnostics and repair, brake pad/rotor replacement, bleeding procedures.
Suspension:
Front and rear suspension components, struts, shocks, ball joints, control arms, alignment specifications.
Steering:
Power steering system, steering column, tie rods, steering gear diagnostics and repair.
HVAC:
Heating, ventilation, and air conditioning system diagnosis, refrigerant handling, component replacement (compressor, evaporator, condenser), blower motor.
Electrical Chassis:
Interior and exterior lighting, power windows, power locks, power seats, mirrors, wipers, horn, instrument cluster.
Body And Frame:
Body panel alignment, door mechanisms, interior trim removal, structural components.
Wiring Diagrams:
Comprehensive electrical wiring diagrams for all vehicle systems.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, fluid checks and changes, spark plug replacement, belt inspection/replacement.
Diagnostics:
Troubleshooting guides, symptom-based diagnostics, OBD-II (On-Board Diagnostics) codes and interpretations.
Repair:
Step-by-step repair instructions for all major mechanical and electrical components.
Rebuilds:
Engine and transmission rebuild procedures, including parts lists and specifications.
Depth:
Factory-level diagnostic and repair procedures, suitable for professional technicians and experienced DIYers.
Format:
Proprietary web-based application with HTML, JavaScript, and CSS elements.
Devices:
Compatible with any PC, laptop, smartphone, or tablet with an internet connection and web browser.
Source:
Licensed information derived from OE (Original Equipment) materials.
Engine Type:
3.8L V6 (L36 - naturally aspirated)
Horsepower:
205 hp @ 5200 rpm
Torque:
230 lb-ft @ 3200 rpm
Injection Type:
Multi-Port Fuel Injection (MPFI)
Fuel Type:
Unleaded Gasoline (87 octane recommended)
Coolant Type:
Dex-Cool (Orange) Extended Life Antifreeze/Coolant (GMC/GM P/N 12378524 or equivalent)
Oil Type:
SAE 5W-30 (API Service SG or SH)
Oil Capacity:
4.5 quarts (4.3 L) with filter
Transmission Type:
4-Speed Automatic (4T60-E)
Features:
Electronic controls, overdrive, torque converter clutch (TCC).
Fluid Type:
Dexron III Automatic Transmission Fluid (ATF) (GM P/N 88861135 or equivalent)
Capacity:
Approximately 9.5 quarts (9.0 L) for a dry fill, 4.5-5.5 quarts (4.3-5.2 L) for a fluid change.
Airbags:
Driver and front passenger airbags.
Seatbelts:
Three-point seatbelts with front pretensioners.
ABS:
Standard Anti-lock Braking System (ABS).
NHTSA Driver Front Impact:
4 Stars
NHTSA Passenger Front Impact:
4 Stars
Audio System:
Factory AM/FM stereo with cassette player, optional CD player, and premium sound system with amplifier.
Climate Control:
Automatic Climate Control (ACC) system with digital display and dual-zone temperature control.
Cruise Control:
Standard electronic cruise control.
Tire Pressure:
No standard Tire Pressure Monitoring System (TPMS) in 1996.
Oil Change Interval:
Every 3,000 - 5,000 miles or 3-6 months, whichever comes first, depending on driving conditions. Check manual for specific recommendations.
Transmission Fluid Change:
Every 30,000 - 60,000 miles, or as per severe service schedule. Recommended to change filter at the same time.
Coolant Flush Interval:
Initial change at 100,000 miles (5 years), then every 50,000 miles (5 years) thereafter with Dex-Cool coolant.
Brake Fluid Type:
DOT 3 (GM P/N 12378384 or equivalent)
Power Steering Fluid:
Dexron III ATF or GM Power Steering Fluid (P/N 1050017 or equivalent)
Intake Manifold Gasket:
Common issue with the 3800 V6 engine, leading to coolant leaks (internal or external).
Transmission Solenoids:
Potential failure of shift solenoids in the 4T60-E transmission can cause harsh shifting or no-shift conditions.
Idler Arm And Bushings:
Wear in the steering system's idler arm and bushings can lead to looseness and play in steering.
Oil Filter Example:
AC Delco PF1218 or equivalent
Air Filter Example:
AC Delco A3020C or equivalent
Spark Plug Example:
AC Delco Rapidfire Platinum 41-980 or equivalent
Brand Focus:
Oldsmobile was a pioneer in American automotive innovation, known for its comfortable and well-equipped vehicles.
Model Lineage:
The LSS was the top-tier trim of the Oldsmobile Eighty-Eight, a long-standing model in the Oldsmobile lineup, representing the evolution towards larger, more luxurious sedans.
Production Period:
The Eighty-Eight (including LSS) was produced from 1949 to 1991. The LSS trim specifically debuted in the early 1990s as a luxury variant.
