Target Audience:
DIY Enthusiasts, Independent Repair Shops
Value Proposition:
Cost-effective alternative to dealership service, instant access to factory data
Comparison To Print:
More convenient, searchable, up-to-date than older printed manuals
Feature 1:
Licensed OE Information
Feature 2:
Comprehensive System Coverage
Feature 3:
User-Friendly Digital Interface
Feature 4:
Accessible on Multiple Devices
Engine:
Complete repair, overhaul, diagnostics, tuning
Drivetrain:
Manual & Automatic Transmissions, Clutch, Axles, Differential
Suspension:
Front & Rear Suspension, Springs, Shocks, Control Arms, Bushings
Steering:
Power Steering System, Steering Column, Tie Rods
Brakes:
Hydraulic System, ABS (if equipped), Disc/Drum Brakes, Parking Brake
Electrical:
Complete Wiring Diagrams, Fuses, Relays, Ignition, Charging, Starting, Lighting
Heating And Ac:
HVAC System Components, Refrigerant, Controls, Blower Motor
Bodywork:
Body Panels, Doors, Bumpers, Glass, Interior Trim
Body Electrical:
Power Windows, Locks, Mirrors, Wipers, Horn
Maintenance:
Oil Change, Filter Replacement, Tune-ups, Fluid Checks/Changes, Belt Replacement
Repair:
Engine Component Replacement, Transmission Service, Brake System Overhaul, Suspension Bushing Replacement
Diagnostics:
Troubleshooting Symptom-Based Guides, Diagnostic Trouble Codes (DTCs) interpretation
Installation:
Component Replacement Procedures, Accessory Installation
Depth Level:
Factory-Level Detail, OE Data Derived
Accuracy:
Licensed from OE Materials
Digital Format:
Web-based, Browser-accessible
Compatibility:
PC, Laptop, Smartphone, Tablet
Print Option:
Printable Pages (user dependent)
Binding:
Not Applicable (Online)
Paper Quality:
Not Applicable (Online)
Engine Type:
Inline 4-Cylinder, DOHC
Displacement:
1998 cc (122 cubic inches)
Bore X Stroke:
86.0 mm x 86.0 mm (3.39 in x 3.39 in)
Fuel Delivery:
Multi-Port Fuel Injection (MPFI)
Horsepower:
124 hp @ 5600 rpm
Torque:
135 lb-ft @ 4000 rpm
Fuel Type:
Unleaded Gasoline
Recommended Octane:
87 Octane
Ignition System:
Distributorless Ignition System (DIS), Coil-on-Plug
Transmission Type Std:
5-Speed Manual
Transmission Type Opt:
4-Speed Automatic
Automatic Features:
Electronically Controlled
Manual Transmission Fluid:
SAE 75W-90 GL-4 Gear Oil (e.g., GM P/N 12345906 or equivalent)
Automatic Transmission Fluid:
Dexron III (e.g., GM P/N 12377011 or equivalent)
NHTSA Driver Front Impact:
Not Rated/Not Available
NHTSA Passenger Front Impact:
Not Rated/Not Available
ABS:
Optional (Anti-lock Braking System)
Airbags:
Driver and Passenger Airbags
Seatbelts:
Frontal and Side-Impact Restraint Systems
Body Structure:
Dent-resistant Polymer Body Panels on Spaceframe
Oil Change Interval:
Every 7,500 miles or 6 months (whichever comes first)
Engine Air Filter Replacement:
Every 30,000 miles or 24 months
Spark Plug Replacement:
Every 100,000 miles (Platinum/Iridium plugs)
Timing Belt Replacement:
Not Applicable (Engine uses a timing chain)
Engine Oil Capacity:
4.5 US Quarts (with filter) - SAE 5W-30 Synthetic
Coolant Capacity:
6.2 US Quarts (Pre-mixed 50/50 Dex-Cool/Water or equivalent)
Brake Fluid:
DOT 3 Hydraulic Brake Fluid
Issue 1:
Intake Manifold Gasket Leaks (can lead to coolant/oil leaks)
Issue 2:
Oil Pan Gasket Leaks
Issue 3:
Rear Main Seal Leaks
Issue 4:
Evaporative Emission Control (EVAP) System Issues (e.g., charcoal canister, vent solenoid)
Issue 5:
Power Window Motor Failures
Brand Introduction:
Saturn Corporation, a subsidiary of General Motors, introduced in 1985 as a response to Japanese imports.
Sc2 Introduction:
The SC coupe model debuted in 1990, with the SC2 being a higher-performance variant.
1996 Updates:
Minor styling revisions, potential feature updates, consistent with the second generation of the SC model.
Production Location:
Spring Hill, Tennessee, USA
Production Years Sc2:
1991-2002
