BMW R1150GS R 1150 GS 1999-2005 Factory Service Repair Manua

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

This manual covers the R 1150 GS, an Adventure Touring Motorcycle produced from 1999 through 2005. Renowned for its robust engineering and versatility, the R 1150 GS features an air/oil-cooled,...

16 people are viewing this right now

类型: Motorcycle

斯库: 52236

标签: 1150 K 1999 2000 2001 2002 2003 2004 2005 BMW CASE Construction Crawler Dozers Motorcycle R 1150 GS R1150GS

产品多属性

Description

This manual covers the R 1150 GS, an Adventure Touring Motorcycle produced from 1999 through 2005. Renowned for its robust engineering and versatility, the R 1150 GS features an air/oil-cooled, 1130 cc Boxer engine, a 5-speed manual transmission with shaft drive, and a tubular steel spaceframe. It offers a comfortable riding experience suitable for long-distance touring while also possessing capabilities for off-road exploration, embodying a commitment to durable and capable motorcycles. The model is distinguished by its dual headlights on some variants for enhanced visibility and the availability of an optional ABS II system. This comprehensive factory service repair manual provides complete information for the maintenance, diagnosis, and repair of the R 1150 GS. It details engine mechanicals, fuel and cooling systems, transmission and drivetrain, chassis, suspension, and the electrical system. Covered procedures include scheduled maintenance, fluid changes, component repair, and advanced troubleshooting, supported by detailed substeps, cautions, and wiring diagrams. This manual is designed to assist owners, DIY mechanics, and professional technicians in effectively servicing and maintaining their vehicle, ensuring optimal performance and longevity.

🏷️ Basic Information

Identification

Make:

Model:

R 1150 GS

Model Years Covered:

1999, 2000, 2001, 2002, 2003, 2004, 2005

Vehicle Type:

Adventure Touring Motorcycle
