🏷️ Basic Information

Make:

Alfa Romeo

Model:

147

Model Generation:

First Generation (937)

Chassis Code:

937

👋 Introduction

Target Audience:

Alfa Romeo 147 owners, independent repair shops, automotive technicians, DIY enthusiasts

Manual Value Proposition:

Comprehensive, official, and complete digital workshop manual offering detailed procedures, troubleshooting, and electrical information across multiple languages, delivered via instant download.

Content Completeness:

100% complete and intact, with no missing or corrupt pages/sections, ensuring all necessary information is available for repair and maintenance.

Information Accuracy:

Official service information you can count on, guaranteeing accuracy and reliability for all repair and diagnostic procedures.

📋 Manual Details

Applicable Model Years:

2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010

Covered Engine Variants:

1.6 TS (Twin Spark), 2.0 TS (Twin Spark), 3.2 V6 (Busso), 1.9 JTD (8-valve Common Rail Diesel), 1.9 JTD (16-valve Common Rail Diesel)

Covered Body Styles:

All styles covered (implied by 'all models')

Total Pages Estimated:

Large (over 720MB, indicative of extensive content)

Manual Classification:

Workshop Repair and Service Manual

Supported Languages:

English (EN), German (DE), Spanish (ES), French (FR), Italian (IT), Dutch (NL), Polish (PL), Greek (GK), Portuguese (PT), Turkish (TR)

Digital Format:

ISO Image (CD-ROM simulation)

📖 Manual Coverage

Powertrain:

Engine (all variants), Transmission (manual and automatic where applicable), Drivetrain (front-wheel drive components including driveshafts, differentials)

Chassis:

Suspension (front and rear), Steering, Brakes (hydraulic and pneumatic systems, ABS, EBD), Wheels and Tires

Electrical System:

Battery, Starting system, Charging system, Lighting, Instrumentation, Body electronics, Engine management sensors and actuators, Infotainment wiring

Body And Interior:

Body panels, Doors, Windows, Seats, Airbags, HVAC (Heating, Ventilation, and Air Conditioning)

Routine Maintenance:

Oil and filter changes, Fluid checks and top-ups, Spark plug replacement, Air filter replacement, Brake pad and disc inspection

Repair And Rebuild:

Engine overhaul (e.g., piston replacement, bearing services), Cylinder head removal and installation, Transmission overhaul, Driveshaft repair/replacement, Suspension component replacement, Brake system component overhaul

Diagnostics And Troubleshooting:

Fault finding procedures for engine, transmission, brakes, and electrical systems; diagnostic trouble codes (DTCs) interpretation; wiring diagrams for electrical system diagnosis

Diagnostic Capability:

Advanced diagnostic procedures, including information on electrical systems and troubleshooting, supported by detailed wiring diagrams

Repair Detail Level:

Detailed sub-steps, numbered instructions, critical notes, cautions, and warnings for each repair procedure, facilitating both basic and advanced repairs.

Illustrations And Diagrams:

Extensive use of detailed illustrations, drawings, photos, and enlarged insets to aid in part identification and procedural understanding. Includes detailed wiring diagrams.

📊 Manual Specifications

Digital Container:

ISO image (.iso)

Searchability:

Searchable (CD-ROM style search functionality)

Print Capability:

Printable (allows users to print specific sections or the entire manual)

Physical Format Equivalent:

N/A (Digital product)

Digital Medium Equivalent:

N/A (Digital product)

Digital Rights Management:

DRM-free (no restrictions on usage or printing)

⚙️ Engine Specifications

Engine Family 1:

Twin Spark (TS)

Engine Displacement 1:

1.6 Liters (approx. 1598cc) and 2.0 Liters (approx. 1970cc)

Engine Configuration 1:

Inline-4 Cylinder, DOHC (Double Overhead Camshaft)

Engine Material 1:

Cast Iron Block (as per excerpt), Aluminium Cylinder Head

Performance 1 6 Ts Approx:

Horsepower: ~105-120 hp, Torque: ~140-150 Nm

Performance 2 0 Ts Approx:

Horsepower: ~150-155 hp, Torque: ~185-190 Nm

Engine Family 2:

V6 'Busso'

Engine Displacement 2:

3.2 Liters (approx. 3179cc)

Engine Configuration 2:

V6, DOHC

Engine Material 2:

Aluminum Block and Heads

Performance 3 2 V6 Approx:

Horsepower: ~240-250 hp, Torque: ~300-310 Nm

Engine Family 3:

JTD (Common Rail Diesel)

Engine Displacement 3:

1.9 Liters (approx. 1910cc)

Engine Configuration 3:

Inline-4 Cylinder, DOHC, Common Rail Direct Injection

Performance 1 9 Jtd 8V Approx:

Horsepower: ~100-115 hp, Torque: ~200-220 Nm

Performance 1 9 Jtd 16V Approx:

Horsepower: ~140-150 hp, Torque: ~280-320 Nm

Fuel Delivery Ts Engines:

Multi-point fuel injection (MPI)

Fuel Delivery V6 Engine:

Multi-point fuel injection (MPI)

Fuel Delivery Jtd Engines:

Common Rail Direct Injection (CRDI)

Lubrication Principle:

Pressurized lubrication system with wet sump, oil pump drawing from the sump, and oil jets for piston cooling (as per excerpt). Features a pressure relief valve.

🔧 Transmission

Standard Transmission Type:

5-speed Manual Transmission (for most variants)

Optional Transmission Type:

6-speed Manual Transmission (on some performance variants), Selespeed (Automated Manual Transmission) for 2.0 TS, Q-System (Torque Converter Automatic) for 2.0 TS and 3.2 V6

Drivetrain Layout:

Front-Wheel Drive (FWD)

Differential Type:

Open differential (typically)

Manual Transmission Fluid:

Refer to manual for specific API GL-4 or GL-5 gear oil specifications and capacity for each transmission type (e.g., Tutela Geartech 75W-85)

Automatic Transmission Fluid:

Refer to manual for specific ATF specifications and capacity (e.g., Tutela Transaxle 75W-85 for Q-System, specific Selespeed fluid for Selespeed)

📐 Dimensions

Length:

~4253 mm

Width:

~1765 mm

Height:

~1468 mm

Curb Weight Approx:

~1300-1450 kg (depending on engine and specification)

🛡️ Safety Features

Euro Ncap Rating:

4 Stars (for original Euro NCAP test, later models may vary slightly)

Braking Systems:

ABS (Anti-lock Braking System), EBD (Electronic Brakeforce Distribution), Brake Assist (BA)

Airbags:

Front airbags (driver and passenger), Side airbags, Window airbags (curtain airbags on some models)

Structural Safety:

High-strength steel chassis and body structure, crumple zones

💡 Technology Features

Head Unit Features:

Factory fitted radio/CD player with RDS, potentially steering wheel audio controls. Some later models may have integrated navigation systems.

Active Safety Systems:

ABS, EBD, Brake Assist are standard. Traction control (ASR) and Vehicle Dynamic Control (VDC) are available on many models.

Connectivity Options:

Pre-wiring for optional hands-free phone systems (Blue&Me system introduced later in production for some models, but not comprehensively covered in the earlier part of this generation's lifecycle).

🔧 Maintenance

Oil Change Interval Petrol:

Typically every 15,000 km or 1 year, whichever comes first (consult manual for specific engine variants and oil types).

Oil Change Interval Diesel:

Typically every 20,000 km or 1 year, whichever comes first (consult manual for specific engine variants and oil types).

Timing Belt Replacement Ts Engines:

Critical: Typically every 105,000 km or 5 years (whichever comes first). Incorrect replacement can cause severe engine damage. The 2.0 TS also has a chain for the second camshaft.

Timing Belt Replacement V6 Busso:

Critical: Typically every 105,000 km or 5 years (whichever comes first). This engine has two timing belts. Incorrect replacement can cause severe engine damage.

Timing Belt Replacement Jtd Engines:

Critical: Typically every 100,000 km or 5 years (whichever comes first). Incorrect replacement can cause severe engine damage.

Engine Oil Specification Petrol:

Refer to manual. Common specifications include Selenia K Pure Energy 5W-40 or similar ACEA A3/B4, API SN/CF. Check oil level and condition regularly.

Engine Oil Specification Diesel:

Refer to manual. Common specifications include Selenia WR Forward 5W-30 or similar ACEA C3, API SN/CF. Check oil level and condition regularly.

Coolant Specification:

Paraflu UP (OAT - Organic Acid Technology) antifreeze concentrate diluted with distilled water, typically a 50/50 mix. Total capacity around 7-8 liters.

Brake Fluid Specification:

DOT 4 (High Performance DOT 4 recommended). Fluid should be replaced every 2 years.

Common Issues Petrol:

Timing belt wear (critical), Coil pack failures (Twin Spark ignition system), MAF sensor issues, Catalyst converter failures, ABS sensor issues, Minor electrical gremlins, Wear on suspension bushings.

Common Issues Diesel:

Diesel particulate filter (DPF) clogging (on later models with DPF), EGR valve issues, Turbocharger problems (if not maintained), Glow plug failures, Injector issues (less common than petrol ignition).

Common Issues General:

Water ingress into ECU/fuse box, Climate control actuator failures, Door lock actuator issues, Wear on interior trim, Selespeed gearbox hydraulic unit issues (if equipped).

📚 Vehicle History

Alfa Romeo Legacy:

Renowned Italian manufacturer with a history of sporting sedans and coupes, known for distinctive styling and engaging driving dynamics.

147 Introduction:

Launched in 2000 as a successor to the Alfa Romeo 145/146 hatchback range. Featured a distinctive styling inspired by the larger 156 sedan. Available initially with Twin Spark engines.

147 Updates:

Received a significant facelift in 2004, introducing updated styling (especially the front fascia), improved interior materials, and revised suspension. The 3.2 V6 'GTA' model was also introduced.

Production Period:

2000 - 2010

Manufacturing Plant:

Polemica, Italy

🏆 Awards & Recognition

European Car Of The Year:

Awarded 'Most Beautiful Car' by Italian magazine Automobilismo. While not the overall European Car of the Year, it received significant positive reviews for its design and driving dynamics.
