🏷️ Basic Information

Make:

Suzuki

Model:

Liana (Aerio)

Production Years:

2001-2007

Chassis Codes:

RH413, RH414D, RH416, RH418

Alternative Names:

Aerio

👋 Introduction

Market Segment:

Compact car segment, often appealing to budget-conscious buyers seeking practicality and reliability.

Competitors:

Toyota Corolla, Honda Civic, Ford Focus, Mazda3, Nissan Sentra, Hyundai Elantra.

Vehicle Strengths:

Spacious interior for its class, good fuel economy, comfortable ride, practical hatchback or sedan body styles.

Value For Buyers:

Provides comprehensive DIY repair and maintenance guidance, saving owners significant costs on dealership service. Ensures proper upkeep and prolongs vehicle lifespan.

📋 Manual Details

Page Count:

25,000+

File Size Mb:

700

Manual Type:

Workshop Service Repair Manual

Languages:

English, French, German, Spanish

File Format:

PDF

Searchable:

Yes

Bookmarked:

Yes

Ipad Ready:

Yes

Delivery Method:

Instant Download

Drm Free:

Yes

Printable:

Yes

📖 Manual Coverage

Engine Mechanical:

Complete overhaul, assembly, disassembly, lubrication system, cooling system, fuel system, exhaust system, engine control system.

Engine Management:

Ignition system, emission control systems, sensors (camshaft position, knock sensor, etc.), ECU diagnostics and repair.

Transmission:

Manual transaxle system (assembly, disassembly, overhaul, fluid specifications), automatic transaxle (if applicable, specific models), clutch system (master cylinder, slave cylinder, pedal, clutch unit).

Drivetrain:

Drive shaft, drive belt, differential case assembly, rear axle beam, rear axle hub.

Suspension Steering:

Front and rear suspension systems, steering system (steering column, power steering, steering sensor), wheel alignment (front and rear).

Brakes:

Brake system (master cylinder, booster, brake fluid specifications, brake actuator), front and rear brakes, parking brake system (cable, lever).

Electrical Systems:

Charging system, starting system (starter assembly, starter switch), lighting system (headlights, taillights, interior lights), combination meter, instrument panel, power window control system, power door lock control system, power mirror control system.

Body And Interior:

Body repair, exterior components (bumpers, doors, glass, moldings), interior components (seats, headlining, instrument panel, door panels), sun roof system, wiper and washer system (motors, blades, nozzles), rear wiper system.

Safety Systems:

Supplemental Restraint System (SRS) - airbags (driver, passenger, side, curtain shield), seat belt warning system, seat belts, shift lock system, yaw rate sensor.

Chassis And Frame:

Frame construction, chassis components, body mounting.

Exhaust And Emissions:

Exhaust system components, emission control systems, charcoal canister.

Maintenance:

Scheduled maintenance, fluid changes (oil, coolant, brake fluid, transmission fluid), filter replacement, spark plug replacement, belt inspection and replacement.

Troubleshooting:

Diagnostic procedures for all major systems, common fault identification, symptom-based troubleshooting guides.

Repair Overhaul:

Detailed step-by-step instructions for component disassembly, repair, and reassembly of engine, transmission, brakes, suspension, steering, electrical components, and body panels.

Diagnostics:

Electrical system diagnostics, wiring diagrams, component testing, sensor calibration.

Installation:

Procedures for installing genuine Suzuki parts and approved accessories.

Wiring Diagrams:

Comprehensive wiring diagrams for all electrical systems, including color coding and connector pinouts.

Depth:

Covers everything from basic maintenance to complete engine and transmission overhauls. Includes detailed diagnostic procedures and wiring information for experienced mechanics and DIY enthusiasts.

📊 Manual Specifications

File Format:

PDF

Print Quality:

High resolution, suitable for printing all pages.

Text Searchability:

Fully searchable text allows for quick information retrieval.

Platform Compatibility:

Compatible with Windows, Mac, and Linux operating systems.

Binding:

Digital (PDF) - Not applicable for physical binding.

Paper Type:

Digital (PDF) - Not applicable for physical paper type.

⚙️ Engine Specifications

Engine Code 1:

M13A (1.3L I4)

Engine Code 2:

M15A (1.5L I4)

Engine Code 3:

M16A (1.6L I4)

Engine Code 4:

J20A (2.0L I4) - Used in some markets for Aerio

Horsepower Range:

Approximately 85 hp to 140 hp, depending on engine and market.

Torque Range:

Approximately 114 Nm to 180 Nm, depending on engine and market.

Fuel Injection:

Electronic Multi-Point Fuel Injection (MPI).

Block Material:

Aluminum Alloy

Head Material:

Aluminum Alloy

Valvetrain:

DOHC, 4 valves per cylinder

🔧 Transmission

Type 1:

5-speed Manual Transaxle

Type 2:

4-speed Automatic Transmission (with overdrive)

Torque Converter:

Used in automatic transmissions.

Manual Transmission Fluid:

API GL-4, SAE 75W-85 or 75W-90 (Refer to manual for exact specification).

Automatic Transmission Fluid:

Dexron II/III or equivalent (Refer to manual for exact specification).

📐 Dimensions

Body Styles:

4-door Sedan, 5-door Hatchback/Wagon.

Curb Weight Range:

Approximately 1050 kg - 1250 kg, depending on body style and equipment.

🛡️ Safety Features

Crash Test Ratings:

Varies by market and testing agency. Often received 'Acceptable' to 'Good' ratings in frontal and side impact tests from organizations like IIHS or Euro NCAP in its era.

Active Safety:

Anti-lock Braking System (ABS), Electronic Brakeforce Distribution (EBD) (often optional or standard on higher trims), Traction Control System (TCS) (often optional).

Passive Safety:

Front airbags, optional side airbags, optional curtain airbags, three-point seatbelts with pretensioners, collapsible steering column.

💡 Technology Features

Audio System:

AM/FM stereo with CD player, optional premium sound system. Basic display for radio and CD information.

Driver Assistance Features:

Limited by modern standards. Primarily focused on ABS and basic stability control if equipped.

Connectivity Options:

No integrated Bluetooth or smartphone connectivity in most models. Auxiliary input for audio playback may be available on some units.

🔧 Maintenance

Oil Change Interval:

Every 5,000 - 7,500 miles (8,000 - 12,000 km) or 6-12 months, depending on driving conditions (Refer to manual for exact recommendation).

Air Filter Replacement:

Every 15,000 - 30,000 miles (24,000 - 48,000 km).

Spark Plug Replacement:

Every 30,000 - 60,000 miles (48,000 - 96,000 km), depending on plug type (standard vs. iridium).

Coolant Replacement:

Every 30,000 - 50,000 miles (48,000 - 80,000 km) or 2-4 years.

Engine Oil Type:

API SL or SM, ILSAC GF-3 or GF-4, SAE 5W-30 or 10W-30 (Refer to manual for exact viscosity and API rating).

Engine Oil Capacity:

Approximately 3.5 - 4.0 liters (3.7 - 4.2 US quarts), depending on engine.

Coolant Type:

Ethylene glycol-based, long-life coolant (Japanese automotive specific or equivalent).

Brake Fluid Type:

DOT 3 or DOT 4 (Refer to manual).

Common Problems:

Occasional reports of minor electrical gremlins, some suspension wear components (e.g., bushings), and potential for interior trim rattles over time. Early models might have catalytic converter issues or transmission control module problems.

📚 Vehicle History

Suzuki Automotive:

Suzuki has a long history of producing small, fuel-efficient vehicles, motorcycles, and marine engines, known for their value and practicality.

Liana Aerio Development:

Developed as a successor to models like the Esteem, it aimed to offer a more modern and spacious compact car with a focus on versatility (hatchback option).

Manufacturing Locations:

Primarily manufactured in Japan, with some production potentially occurring in other Suzuki global facilities.

🏆 Awards & Recognition

Model Awards:

While specific major awards are not widely publicized for the Liana/Aerio, it was generally regarded as a competent and practical compact car in its segment during its production run.
