Target Audience:
Designed for professional mechanics and experienced DIY enthusiasts working on Harley-Davidson motorcycles.
Manual Advantage:
Offers comprehensive, step-by-step procedures with detailed illustrations and technical data, covering the entire scope of repair and maintenance.
Comprehensiveness:
Covers all aspects of the motorcycle, from basic maintenance to complete engine and transmission overhauls.
Visual Aid:
Includes numerous detailed illustrations, exploded diagrams, and photographs to simplify complex procedures.
Accessibility:
Instant PDF download provides immediate access to critical service information.
Engine:
Detailed coverage of the Harley-Davidson Evolution (1450cc) V-twin engine, including disassembly, assembly, inspection, and component replacement.
Transmission:
Complete procedures for the 5-speed constant mesh transmission, including clutch, primary drive, and secondary drive maintenance.
Fuel System:
Carburetor (likely Keihin CV) tuning, disassembly, and rebuilding; fuel tank and lines.
Ignition System:
Ignition timing, spark plugs, ignition module, and related components.
Electrical System:
Wiring diagrams, battery, charging system (alternator, regulator), lighting, starting system, and accessory circuits.
Brakes:
Front and rear brake systems, including hydraulic components, calipers, rotors, brake lines, and bleeding procedures.
Suspension:
Front fork (telescopic) and rear shock absorber service, including fluid replacement and adjustments.
Frame And Body:
Frame inspection, body panel removal and installation, fenders, fuel tank, seat, handlebars, and controls.
Maintenance:
Routine maintenance, oil changes, filter replacements, lubrication, and periodic inspections.
Troubleshooting:
Systematic diagnostic procedures for common and complex issues, including symptoms, causes, and corrective actions.
Repair:
Detailed step-by-step repair instructions for all major vehicle systems and components.
Removal Installation:
Comprehensive guidance on removing and installing all parts and assemblies.
Adjustment:
Precise instructions for adjusting various components, such as clutch, throttle, brakes, and suspension.
Diagnostic Capabilities:
Advanced diagnostic procedures, including symptom-based troubleshooting and specific testing methods.
Rebuild Procedures:
Complete engine and transmission rebuild procedures with detailed diagrams and specifications.
Special Tools:
Identification and usage instructions for all required special service tools (SSTs).
Torque Specifications:
Precise tightening torque values for all fasteners and critical components.
Wear Limits:
Allowable wear limits and inspection criteria for all replaceable parts.
Quality:
High-resolution PDF, ensuring clear text and readable diagrams.
Printability:
Fully printable, allowing users to print specific sections or the entire manual.
Binding Type Digital:
N/A (Digital PDF)
Paper Type Digital:
N/A (Digital PDF)
Operating Systems:
Compatible with Windows, Mac, and Linux operating systems.
Software Requirement:
Adobe Reader or compatible PDF viewer.
Engine Type:
Air-cooled, Evolution V-twin
Displacement:
1450cc (88 cubic inches)
Bore X Stroke:
3.4375 in. x 3.8125 in. (87.3 mm x 96.8 mm)
Compression Ratio:
8.8:1 (typical for this era)
Horsepower:
Approx. 65-70 HP (Varies by specific tuning and exhaust)
Torque:
Approx. 70-75 ft-lbs (Varies by specific tuning and exhaust)
Carburetor:
Keihin CV (Constant Velocity) 40mm
Fuel Requirement:
Unleaded gasoline, 91 octane (or higher) recommended.
Oil Type:
Harley-Davidson Genuine V-Twin Oil or equivalent SAE 20W-50 motorcycle oil.
Oil Capacity:
Approx. 3.0 US quarts (2.8 liters) with filter change.
Crash Test Ratings:
N/A (Motorcycle safety ratings are not standardized like automotive; manual focuses on repair safety)
Braking System:
Dual front disc brakes, single rear disc brake. Hydraulic actuation.
Lighting:
Halogen headlamp, LED tail lamp, turn signals.
Initial Service:
Typically at 1,000 miles (1,600 km) for oil change, filter replacement, and inspection.
Routine Maintenance:
Every 5,000 miles (8,000 km) or annually, including engine oil and filter, primary chaincase oil, and general inspection. Refer to manual for specific interval details.
Engine Oil Grade:
SAE 20W-50 motorcycle specific
Transmission Oil Grade:
SAE 80W-90 gear oil
Primary Chaincase Oil:
Harley-Davidson Primary Chaincase Lubricant or equivalent formula
Brake Fluid:
DOT 4 hydraulic fluid
Primary Drive Tensioner:
Early models (pre-2007) often used a plastic primary chain tensioner shoe which could wear out, leading to noise and potential chain damage. Manual will cover inspection and replacement.
Carburetor Tuning:
CV carburetors can require periodic tuning for optimal performance and fuel economy. Manual provides detailed tuning procedures.
Oil Leaks:
Potential for oil leaks from various seals and gaskets over time. Manual guides on identifying and replacing these components.
Brand Essence:
Harley-Davidson is an iconic American motorcycle manufacturer with a rich history dating back to 1903, known for its V-twin engines and distinctive styling.
Dyna Lineage:
The Dyna line, introduced in 1991, featured a distinctive frame with the engine rubber-mounted to reduce vibration, differentiating it from the Big Twin models.
Fxdx Positioning:
The FXDX (Dyna Super Glide Sport) was positioned as a sportier variant within the Dyna lineup, often featuring better suspension components and a more aggressive riding posture.
Manufacturing Location:
United States
Model Recognition:
While specific awards for the 2001 FXDX are not widely documented, the Dyna platform was generally well-regarded for its blend of performance and classic Harley-Davidson styling.
Manual Quality Rating:
High (based on description: detailed, comprehensive, step-by-step, pictorial diagrams)
Manual Certification:
N/A (As a third-party publication, not officially certified by manufacturer, but designed to meet professional repair standards)
