2001 Yamaha TTR 125 Motorcycle Owner‘s Service Repair Manual

常规价格
$17.99
促销价
$17.99
常规价格
🏷️ Basic Information Identification Make: Yamaha Model: TTR125 Year: 2001 Vehicle Type: Dual-Sport Motorcycle Generation Generation Code: TTR125 (First Generation) 👋 Introduction Market Position Target Audience: Enthusiast riders, aspiring mechanics,...
25 people are viewing this right now
类型: Motorcycle
厂商:
斯库: 605496
2001 Yamaha TTR 125 Motorcycle Owner‘s Service Repair Manual2001 Yamaha TTR 125 Motorcycle Owner‘s Service Repair Manual2001 Yamaha TTR 125 Motorcycle Owner‘s Service Repair Manual2001 Yamaha TTR 125 Motorcycle Owner‘s Service Repair Manual
🏷️ Basic Information
Identification
Make:
Yamaha
Model:
TTR125
Year:
2001
Vehicle Type:
Dual-Sport Motorcycle
Generation
Generation Code:
TTR125 (First Generation)
👋 Introduction
Market Position
Target Audience:
Enthusiast riders, aspiring mechanics, and owners seeking to perform their own maintenance and repairs.
Category:
Entry-level/Recreational Off-Road Motorcycle
Competitive Analysis
Competitors 2001:
Honda CRF100F, Kawasaki KX100, Suzuki DR-Z125.
Key Features
Platform Emphasis:
User-friendly, reliable, and capable for trail riding and learning.
Manual Value Proposition:
Provides essential knowledge for maintaining peak performance and longevity of the TTR125.
📋 Manual Details
Coverage Areas
Manual Type:
Owner's Service Repair Manual
Language:
English
Format:
Digital (PDF)
Page Count
Page Count:
Estimated 300-400 pages (typical for comprehensive service manuals)
📖 Manual Coverage
Systems Covered
Engine Mechanics:
Engine assembly, disassembly, inspection, and repair procedures for all internal components (piston, rings, cylinder, crankshaft, valves, camshaft, etc.).
Fuel System:
Carburetor service and adjustment, fuel tank maintenance, fuel line inspection and replacement.
Ignition System:
CDI ignition system inspection, troubleshooting, and component testing (stator, ignition coil, spark plug).
Transmission:
Gearbox inspection, maintenance, and repair; clutch operation and service; shift mechanism troubleshooting.
Suspension System:
Front fork (telescopic) maintenance, seal replacement, oil level and specification; rear shock absorber inspection and service.
Braking System:
Front and rear brake inspection, pad/shoe replacement, hydraulic system bleeding (if applicable), cable adjustment.
Electrical System:
Wiring diagrams, lighting system maintenance, battery care and testing, starter system troubleshooting, fuse replacement.
Chassis And Frame:
Frame inspection, steering head bearing service, swingarm maintenance, wheel bearing inspection.
Exhaust System:
Muffler and pipe inspection, cleaning, and potential gasket replacement.
Cooling System:
Air-cooled engine specifics, no liquid cooling system to cover.
Procedures Included
Routine Maintenance:
Oil changes, filter replacement, chain adjustment, spark plug inspection/replacement, air filter cleaning/replacement.
Troubleshooting Guides:
Diagnostic charts and procedures for common performance issues, starting problems, and electrical faults.
Component Rebuilds:
Detailed step-by-step instructions for engine, transmission, carburetor, and suspension component overhauls.
Tightening Specifications:
Torque specifications for all critical fasteners throughout the motorcycle.
Diagnostic Techniques:
Methods for identifying and rectifying mechanical and electrical problems.
Wiring Diagrams:
Comprehensive electrical schematics for all systems.
Technical Depth
Depth Level:
Comprehensive (from basic maintenance to full engine rebuilds)
Diagnostic Capability:
Advanced diagnostic procedures for electrical and mechanical systems.
Rebuild Instruction:
Detailed, illustrated instructions for complete engine, transmission, and suspension overhauls.
📊 Manual Specifications
File Format
Digital Format:
PDF
Searchability:
Searchable text content for quick information retrieval.
Print Readiness:
Printable pages for workshop use.
Print Quality
Illustration Clarity:
High-resolution illustrations and diagrams.
Binding Type
Binding:
N/A (Digital Format)
Paper Type
Paper:
N/A (Digital Format)
⚙️ Engine Specifications
Primary Engine
Engine Type:
4-Stroke, Air-Cooled, SOHC
Bore X Stroke:
54.0 mm x 54.5 mm
Displacement:
124 cc
Compression Ratio:
9.5:1
Performance
Horsepower:
Approx. 10-11 HP (estimated)
Torque:
Approx. 7-8 lb-ft (estimated)
Fuel System
Carburetor Model:
Mikuni VM20SS
Fuel Type:
Unleaded Gasoline
Fuel Tank Capacity:
4.1 L (1.1 gal)
Lubrication
Oil Capacity:
0.9 L (0.95 US qt)
Recommended Oil Viscosity:
Yamalube 4 (or equivalent SAE 10W-30 or 20W-40)
🔧 Transmission
Standard
Transmission Type:
Constant-mesh 5-speed
Clutch Type:
Wet, multiple-disc
Features
Final Drive:
Chain drive
Transmission Oil Type:
Yamalube Gear Oil (or equivalent SAE 80 hypoid gear oil)
Transmission Oil Capacity:
0.45 L (0.48 US qt)
📐 Dimensions
Exterior
Overall Length:
1840 mm (72.4 in)
Overall Width:
790 mm (31.1 in)
Overall Height:
1085 mm (42.7 in)
Seat Height:
795 mm (31.3 in)
Wheelbase:
1270 mm (50.0 in)
Ground Clearance:
295 mm (11.6 in)
Weights
Dry Weight:
77 kg (169.8 lbs)
Wet Weight:
Estimated 84 kg (185 lbs)
🛡️ Safety Features
Ratings
Safety Ratings:
N/A (Motorcycle safety is typically defined by design and rider skill)
Active Features
Braking System Type:
Front: Drum Brake, Rear: Drum Brake (Note: Some later models or variations may have disc brakes)
Tires Front:
2.50-17 4PR
Tires Rear:
4.10-14 4PR
Passive Features
Lighting:
Headlight, taillight, brake light, turn signals (may vary by region/spec).
💡 Technology Features
Infotainment
Infotainment System:
N/A (Basic motorcycle, no infotainment features)
Driver Assistance
Driver Assistance Features:
N/A (No electronic rider aids)
Connectivity
Connectivity Features:
N/A (No digital connectivity)
Engine Management
Ignition Control:
CDI (Capacitor Discharge Ignition) system.
🔧 Maintenance
Service Intervals
Engine Oil Change Interval:
Every 1,000 km (600 miles) or 6 months, whichever comes first.
Oil Filter Change Interval:
Recommended with every oil change.
Air Filter Cleaning Interval:
Every 500 km (300 miles) or as needed in dusty conditions.
Spark Plug Inspection Interval:
Every 1,000 km (600 miles).
Chain Lubrication And Adjustment Interval:
Every 500 km (300 miles) and inspect tension.
Valve Clearance Check Interval:
Every 6,000 km (3,700 miles) or annually.
Fluid Specifications
Engine Oil Specification:
Yamalube 4 (or SAE 10W-30 / 20W-40 API SE, SF type or higher).
Transmission Oil Specification:
SAE 80 API GL-4 or GL-5 hypoid gear oil.
Brake Fluid Specification:
DOT 3 or DOT 4 (if hydraulic brakes are equipped).
Known Issues
Common Wear Items:
Clutch plates, brake pads/shoes, chain and sprockets, wheel bearings, fork seals.
Carburetor Maintenance:
Carburetors can sometimes get clogged with debris if fuel is not clean or the bike sits for extended periods. Regular cleaning and proper fuel storage are key.
Suspension Wear:
Front fork seals can leak over time, requiring replacement. Rear shock absorber may lose damping effectiveness with heavy use.
Electrical Connections:
Corrosion in electrical connectors, especially in off-road environments, can lead to intermittent issues. Inspect and clean as needed.
📚 Vehicle History
Brand Heritage
Yamaha Motorcycles Legacy:
Yamaha Motor Company is a Japanese manufacturer of motorcycles, marine products, and other motorized products. Founded in 1955, it has a long history of innovation and performance in motorsports.
Model Evolution
Ttr Series Introduction:
The TTR line was introduced by Yamaha to offer reliable and accessible off-road motorcycles for various skill levels. The TTR125 was developed as a capable, user-friendly option for younger riders and recreational trail use.
Ttr125 Variants:
The TTR125 platform later evolved into models with different suspension travel, wheel sizes (e.g., TTR125L for longer travel and larger front wheel), and electric start options.
Production
Initial Production Year:
The TTR125 was first introduced to the market in 2000 for the 2001 model year.
Manufacturing Location:
Typically manufactured in Japan or potentially at Yamaha's global manufacturing facilities.
🏆 Awards & Recognition
Recognitions
Industry Recognition:
Consistently recognized as a reliable and popular choice in its segment for youth and beginner riders.
Sale

Unavailable
