🏷️ Basic Information

Make:

Honda

Model:

Silverwing

Model Codes:

FSC600, FSC600A

Product Name:

Honda 2002-2006 Silverwing Service Repair Manual

Covered Years:

2002, 2003, 2004, 2005, 2006

Generation Code:

SC15

👋 Introduction

Market Position:

The Honda Silverwing is a premium maxi-scooter known for its comfort, performance, and practicality, often competing with other large-displacement scooters in the touring and commuting segments. This manual is essential for owners seeking to maintain and repair their premium scooter.

Competitive Analysis:

The Silverwing (FSC600/FSC600A) historically competed with models like the Suzuki Burgman 650 and Yamaha TMAX 500. Its robust engineering and reliable performance made it a strong contender in the maxi-scooter market. This manual provides the same level of detail as expected for high-end vehicles.

Key Features Manual:

Unlockable PDF format, extensive coverage (over 500 pages), bookmarked and searchable content, factory-level accuracy, and immediate download upon purchase. This manual is designed for efficient and effective maintenance and repair.

📋 Manual Details

Covered Systems:

General Information, Frame/Body Panels/Exhaust, Maintenance, Lubrication System, Fuel System, Cooling System, Engine Removal/Installation, Cylinder Head/Valves, Drive Pulley/Driven Pulley/Clutch, Final Reduction, Alternator/Starter Clutch, Crankcase/Crankshaft/Balancer, Front Wheel/Suspension/Steering, Rear Wheel/Suspension, Brake System, Anti-Lock Brake System (ABS), Battery/Charging System, Ignition System, Electric Starter, Lights/Meters/Switches, Wiring Diagrams, Troubleshooting, Index

Page Count:

Over 500 pages

Manual Type:

Digital Factory Service Manual

Language:

English

Format:

PDF

Update Information:

While this is a digital factory service manual, it reflects the knowledge and procedures available at the time of its creation for the specified model years. It is the definitive source for maintenance and repair of these specific models.

📖 Manual Coverage

Engine System Coverage:

Detailed coverage of engine removal and installation, cylinder head and valve servicing, lubrication system, fuel system (including injection components), cooling system, crankcase, crankshaft, and balancer assembly. Covers internal engine components and their maintenance and repair.

Drivetrain Coverage:

Comprehensive information on the drive pulley, driven pulley, clutch assembly, and final reduction gears. Includes procedures for inspection, maintenance, and replacement of these critical drivetrain components.

Chassis Coverage:

Covers front wheel, suspension, and steering systems, as well as rear wheel and suspension components. Includes service procedures for forks, shock absorbers, bearings, and related linkage.

Braking System Coverage:

In-depth coverage of both standard and Anti-Lock Brake Systems (ABS), including hydraulic components, brake pads, discs, lines, and related electronic control units for ABS models. Diagnostic and service procedures are detailed.

Electrical System Coverage:

Extensive coverage of the battery, charging system (alternator), starter clutch, ignition system (including spark plug specifications and timing), electric starter motor, lights, meters, switches, and a complete set of wiring diagrams for electrical troubleshooting.

Maintenance Procedures:

Routine maintenance tasks such as oil changes, filter replacements, coolant checks and flushes, brake fluid replacement, drive belt inspection and replacement, tire pressure checks, and general lubrication points. Includes recommended service intervals.

Repair Procedures:

Detailed step-by-step repair instructions for all major mechanical and electrical systems. Covers engine overhaul, transmission servicing, suspension component replacement, brake caliper overhaul, electrical component testing and replacement, and body panel repair.

Troubleshooting Procedures:

Comprehensive troubleshooting guides and flowcharts for diagnosing common and uncommon issues across all vehicle systems. Aids in identifying problems and implementing correct solutions.

Diagnostic Procedures:

Includes procedures for diagnosing electrical faults, engine performance issues, braking system malfunctions, and suspension problems. May include specific diagnostic tools or techniques recommended by Honda.

Technical Depth:

Factory-level technical depth, suitable for professional mechanics and experienced DIY enthusiasts. Covers everything from basic adjustments and fluid changes to complete engine rebuilds and complex electrical diagnostics.

Diagnostic Codes:

Likely includes procedures for reading or interpreting diagnostic trouble codes (DTCs) if the vehicle is equipped with an OBD-II or similar diagnostic system, though this is less common on scooters of this era. Focus will be on systematic troubleshooting.

📊 Manual Specifications

File Format:

Unlocked PDF

Print Quality:

Printable and copyable to multiple devices

Binding Type:

N/A (Digital Download)

Paper Type:

N/A (Digital Download)

Searchability:

Bookmarked and searchable content

Software Requirements:

Free PDF reader (e.g., Adobe Acrobat Reader, built-in OS readers)

Ease Of Use:

Designed for ease of use with clear headings, illustrations, and logical flow. Bookmarked chapters and search functionality significantly reduce time spent locating specific information.

⚙️ Engine Specifications

Engine Type:

Liquid-cooled, four-stroke, parallel-twin cylinder

Displacement:

582 cc (for most models in this range, exact might vary slightly)

Bore X Stroke:

66.0 mm x 42.5 mm (typical for this engine platform)

Valve Train:

SOHC, 4 valves per cylinder

Horsepower:

Approximately 45-50 HP (est. at crank, depending on year and specific tuning)

Torque:

Approximately 50-55 Nm (est. at crank, depending on year)

Fuel Induction:

Programmed Fuel Injection (PGM-FI)

Fuel Type:

Unleaded gasoline, 87-91 octane

Cooling System Type:

Liquid-cooled with fan assist

Ignition System Type:

Full transistor ignition with electronic advance

Spark Plug Specification:

NGK CR9EH-9S or equivalent. Gap: 0.8-0.9 mm (0.031-0.035 in).

🔧 Transmission

Transmission Type:

Automatic (CV-T - Continuously Variable Transmission)

Optional Transmissions:

N/A (CV-T is standard)

Transmission Features:

Automatic clutch and belt-driven CVT for seamless acceleration and optimal engine RPM. Includes a two-speed transmission (standard and overdrive ratios selectable on some models) and a parking brake mechanism within the transmission housing.

📐 Dimensions

Overall Length:

Approx. 2,280 mm (90.6 in)

Overall Width:

Approx. 775 mm (30.5 in)

Overall Height:

Approx. 1,345 mm (53.0 in)

Curb Weight:

Approx. 240-250 kg (529-551 lbs), depending on ABS model and specific equipment.

Wheelbase:

Approx. 1,590 mm (62.6 in)

🛡️ Safety Features

Safety Ratings:

Not applicable in the same manner as cars. Focus is on rider safety features.

Active Safety Features:

Optional Combined ABS (C-ABS) on 'A' models, which links front and rear braking for improved stability and stopping power. Large disc brakes front and rear for effective deceleration.

Passive Safety Features:

Sturdy frame construction, comfortable ergonomics reducing rider fatigue, integrated lighting, and passenger grab handles. The maxi-scooter design offers a degree of wind protection.

💡 Technology Features

Infotainment Features:

Basic instrument cluster with speedometer, tachometer, fuel gauge, coolant temperature gauge, odometer, trip meters, and indicator lights for turn signals, oil pressure, engine, and headlights. No advanced infotainment system is present on models from this era.

Driver Assistance Features:

Optional Combined ABS (C-ABS) for enhanced braking performance and stability. Otherwise, relies on rider skill and the mechanical systems.

Connectivity Features:

N/A (No Bluetooth, smartphone integration, or telematics)

🔧 Maintenance

Engine Oil Change Interval:

Every 6,000 km (3,700 miles) or 12 months, whichever comes first. Refer to manual for specific oil type and capacity.

Drive Belt Inspection Interval:

Inspect every 12,000 km (7,500 miles), replace as needed based on wear.

Coolant Replacement Interval:

Initial replacement at 24,000 km (15,000 miles) or 2 years, then every 12,000 km (7,500 miles) or 12 months thereafter.

Engine Oil Specification:

SAE 10W-40 API SG or higher, JASO MA certified. Capacity: Approx. 1.7 L (1.8 US qt) without filter change, 1.8 L (1.9 US qt) with filter change.

Coolant Specification:

Honda Genuine Coolant or equivalent, 50/50 mix of antifreeze and distilled water. Capacity: Approx. 1.4 L (1.5 US qt).

Brake Fluid Specification:

DOT 4 Honda Genuine Brake Fluid or equivalent.

Final Drive Oil Specification:

Honda Genuine Gear Oil or equivalent API GL-4, SAE 80 or 90. Capacity: Approx. 80 ml (0.08 US qt).

Known Issues:

Some owners have reported issues with the automatic transmission lock-up clutch, leading to slippage or overheating under sustained high loads. Other potential concerns can include stator or rectifier failure, fuel pump issues, and fork seal leaks, though overall reliability is considered high. The manual would provide diagnostic steps for these.

📚 Vehicle History

Brand Heritage:

Honda has a long-standing reputation for building reliable, innovative, and high-quality motorcycles and scooters. The Silverwing builds upon this heritage, offering a sophisticated and durable maxi-scooter experience.

Model Evolution:

The Silverwing (FSC600) was introduced in 2001 as a successor to the Honda X-Eleven. It was designed as a comfortable, high-performance maxi-scooter for touring and commuting. The 'A' models feature the Combined Anti-lock Braking System (C-ABS). The model saw continuous updates throughout its production run, including minor cosmetic changes and technical refinements, until its discontinuation after the 2013 model year in many markets, replaced by newer models in Honda's scooter lineup.

Production Years:

2001-2013 (covered range 2002-2006)

Manufacturing Location:

Japan (primarily)

🏆 Awards & Recognition

Recognitions:

While specific awards for the 2002-2006 models are not widely documented, the Silverwing line has generally been praised in reviews for its comfort, performance, and practicality, solidifying its position as a top-tier maxi-scooter. Its enduring popularity and the availability of this comprehensive service manual are testaments to its successful design and engineering.
