Target Audience:
Dodge Ram Truck owners (1500, 2500, 3500) seeking factory-level repair and maintenance knowledge.
Differentiation:
Actual Genuine Factory Service Manuals, not third-party alternatives.
Value Proposition:
Enables DIY repairs, saving significant labor costs ($50-$60 per hour), provides factory-trained technician knowledge.
Search Functionality:
Searchable PDF allows users to quickly find specific information using keywords.
Primary Coverage:
Full Factory Service and Repair
Estimated Pages:
Hundreds (specific number not provided, but described as comprehensive)
Type:
Factory Service Repair Manual
Authenticity:
Original factory content, not a third-party reproduction.
Delivery Method:
Digital Download link available on checkout page after payment completion.
Storage Options:
Can be saved to hard drive and burned to CD-ROM.
Engine Management:
Engine Service/Repair, Engine Control System, Fuel Injection/Fuel System
Drivetrain:
Transmission Service/Repair, Differential/Drive, Axle
Chassis And Suspension:
Brake System, Suspension, Steering, Periodic Lubrication
Electrical And Electronics:
Wiring Diagram, Electrical System, Engine Control System
Comfort And Climate:
Heater/Air Conditioner
Body And Interior:
Chassis/Body, Interior, Restraint System
Emissions And Diagnostics:
Emission System, Troubleshooting
Cooling System:
Thermostat replacement, water pump service, radiator inspection and repair, coolant hose replacement, fan clutch operation.
Fuel System:
Fuel pump testing, fuel filter replacement, injector diagnosis and cleaning, fuel pressure regulation.
Steering:
Power steering system diagnosis and repair, steering linkage inspection and replacement, steering column service.
Emissions System:
Catalytic converter testing, oxygen sensor diagnosis, EVAP system leak detection, EGR system service.
Restraint System:
Airbag system fault diagnosis, seatbelt mechanism service, SRS module replacement procedures.
Interior:
Door panel removal, seat adjustment mechanisms, dashboard disassembly and reassembly, HVAC control unit service.
Differential Drive:
Front and rear differential service, lubrication, bearing adjustment, and replacement procedures. Coverages for various axle ratios.
Axle:
Front and rear axle component inspection, service, and repair. Drive shaft and U-joint maintenance.
Maintenance And Repair:
General Maintenance, Step-by-step repair procedures, Rebuild procedures, Refurbishment, Restoration
Diagnostics:
Advanced troubleshooting guide, Electrical system diagnostics
Electrical Troubleshooting:
Combined troubleshooting and electrical service procedures with detailed wiring diagrams for ease of use.
Scope:
Comprehensive, covering all aspects of repair and maintenance, designed for professional technicians and owners.
Diagnostic Tools:
Guidance on using diagnostic trouble codes (DTCs) and recommended diagnostic procedures.
Instructional Elements:
Detailed substeps, notes, cautions, warnings, numbered instructions, bold figure numbers, detailed illustrations, drawings, photos, and enlarged inset views.
Table Of Contents:
Numbered table of contents for quick and easy information retrieval.
Engine Options 2002 Ram:
3.7L Magnum V6, 4.7L Magnum V8, 5.9L Magnum V8 (natural aspirated and High Output Turbo Diesel for HD models)
Power And Torque:
Specifications for all listed engine variants are detailed within the manual, including horsepower and torque figures.
Injection Type:
Multi-point fuel injection (MPI) for gasoline engines, Direct Injection for diesel engines.
ECU Coverage:
Information on the Powertrain Control Module (PCM) and its functions, diagnostic parameters, and reprogramming (if applicable).
Gasoline Displacements:
3.7L (226 cu in), 4.7L (287 cu in)
Diesel Displacement:
5.9L (359 cu in) Cummins Turbo Diesel
Transmission Options 2002 Ram:
4-speed automatic (45RFE, 48RE), 5-speed manual (NV3500, G56 for HD models)
Transmission Features:
Overdrive gears, torque converter lock-up (automatic), dual-mass flywheel (manual).
Transmission Service Details:
Fluid type, capacity, filter replacement procedures, and diagnostic information for all available transmissions.
Body Styles 2002 Ram:
Regular Cab, Club Cab (Extended Cab), Quad Cab (4-door extended cab); Short Bed, Long Bed
Bed Dimensions:
Detailed specifications for bed length, width, and payload capacities for all configurations are included.
Gvwr And Payload:
Gross Vehicle Weight Rating (GVWR) and payload capacities vary by model (1500, 2500, 3500) and configuration, all detailed.
Scheduled Maintenance:
Detailed schedules for oil changes, filter replacements, fluid checks, and other preventive maintenance tasks based on mileage and time.
Lubrication:
Detailed instructions for periodic lubrication of chassis components, drive shafts, and other moving parts.
Engine Oil:
Specific SAE viscosity grades (e.g., 5W-30, 10W-30 depending on engine and temperature) and API service classifications provided.
Coolant:
Type and mixture ratio for the cooling system (e.g., Mopar HOAT coolant) specified.
Transmission Fluid:
Dexron III/Mercon or equivalent for automatic transmissions, gear oil specifications for manual transmissions and differentials.
Brake Fluid:
DOT 3 or DOT 4 brake fluid specifications.
Power Steering Fluid:
Specifications for power steering fluid type and capacity.
Common Wear Items:
The manual would detail procedures for addressing common issues such as intake manifold gaskets, radiator leaks, and wear on suspension components.
Diesel Specific Issues:
For 5.9L Cummins Diesel models, information on fuel system maintenance, turbocharger service, and emission control systems would be included.
Dodge Truck Legacy:
Dodge has a long history of producing durable and capable trucks, with the Ram line being a significant part of its identity.
Third Generation Ram:
The 2002 model year falls within the third generation of the Dodge Ram trucks (1994-2001 was second gen, 2002-2008 was third gen), known for its bold styling and improved capabilities.
Generation Key Changes:
The 2002 model year saw continued refinement of the third-generation Ram platform, with potential minor updates to features or powertrain options.
Manufacturing Locations:
Primarily produced at Dodge assembly plants in the United States and Mexico.
