Segment:
Compact city car, known for its practicality, fuel efficiency, and distinctive styling.
Target Audience:
Urban dwellers, first-time car buyers, small families, and individuals seeking an economical and maneuverable vehicle.
Key Competitors:
Hyundai i10, Kia Picanto, Volkswagen Fox, Peugeot 107, Citroën C1, Toyota Aygo.
Unique Selling Points:
Compact dimensions, high seating position, surprisingly spacious interior for its size, robust build quality for the segment, availability of the sporty '100HP' variant.
Benefit To Owner:
Empowers owners to perform their own maintenance and repairs, saving significant costs on dealership labor. Provides in-depth understanding of vehicle systems for effective troubleshooting and care.
Years Covered:
2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012
Models Covered:
All Fiat Panda 169 models, including all engines, trim levels, and transmission types.
Estimated Pages:
Hundreds (Specific count not provided, but described as 'complete workshop' which implies extensive detail).
Type:
Complete Workshop Service Repair Manual
Language:
Likely English, based on product description language.
Format:
Downloadable Digital File (PDF compatibility required)
Powertrain:
Engine mechanical, fuel system, ignition system, cooling system, exhaust system, lubrication system, emissions control.
Transmission Drivetrain:
Manual transmission, automated manual transmission (Dualogic), clutch system, drive axles, CV joints.
Chassis Suspension:
Front suspension (MacPherson struts), rear suspension (torsion beam), steering system, wheel alignment specifications.
Brakes:
Front disc brakes, rear drum brakes (or disc brakes depending on variant), parking brake system, ABS (Anti-lock Braking System) if equipped.
Electrical Electronic:
Battery, charging system, starting system, lighting, instrument panel, body control module, infotainment, diagnostics.
Body Interior:
Body panels, doors, windows, locks, seats, dashboard, HVAC (Heating, Ventilation, and Air Conditioning) system.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection and replacement.
Troubleshooting:
Diagnostic procedures for common faults, fault code interpretation (OBD-II), electrical circuit tracing.
Repair:
Component removal and installation, engine overhaul, transmission service, brake pad and disc replacement, suspension component replacement.
Specifications Data:
Torque specifications for critical fasteners, fluid capacities, component dimensions, electrical resistance values.
Depth:
Comprehensive, covering everything from basic fluid checks to complete engine and transmission rebuilds. Includes diagnostic procedures and wiring diagrams.
File Type:
PDF (Portable Document Format)
Print Resolution:
High quality, suitable for printing individual pages or entire chapters. Assumed to be clear and legible.
Binding:
N/A (Digital download, binding not applicable to the file itself but can be printed and bound by the user).
Paper Quality:
N/A (Digital download, paper type not applicable to the file itself but can be printed on various paper types by the user).
Engine Code Example:
188A4.000 (1.2 Fire)
Engine Type:
Inline 4-cylinder, SOHC/DOHC (depending on variant)
Displacement Example:
1242 cc (1.2 Liters)
Bore X Stroke Example:
70.8 mm x 78.9 mm (example for 1.2 Fire)
Compression Ratio Example:
9.5:1 to 10.0:1 (depending on engine)
Horsepower Example:
60-80 HP (for 1.1 and 1.2 engines), 100 HP (for the 1.4 16V Fire '100HP' variant)
Torque Example:
95-115 Nm (for 1.1 and 1.2 engines), 131 Nm (for the 1.4 16V Fire '100HP' variant)
Fuel Delivery:
Multi-point fuel injection (MPI) with electronic control.
Fuel Type:
Unleaded gasoline (Petrol).
Engine List:
1.1 Fire (8-valve), 1.2 Fire (8-valve/16-valve), 1.3 Multijet (Diesel), 1.4 Fire (16-valve, including 100HP variant), 0.9 TwinAir (later models within range).
Type Standard:
5-speed Manual Transmission.
Type Optional:
5-speed Dualogic (Automated Manual Transmission).
Clutch Type:
Dry single-plate clutch.
Manual Transmission Fluid:
API GL-4 SAE 75W-85 or SAE 75W-90 synthetic gear oil. (Refer to specific manual for exact OEM recommendation and capacity).
Dualogic Fluid:
Specific ATF (Automatic Transmission Fluid) for Dualogic system. (Crucial to use correct type, consult manual for PN and capacity).
Length Mm:
~3540 - 3680 mm (Varies slightly by model year and specific variant).
Width Mm:
~1600 - 1650 mm
Height Mm:
~1550 - 1600 mm
Wheelbase Mm:
~2300 - 2305 mm
Seating Capacity:
4-5 seats (depending on configuration).
Trunk Volume Liters:
~230 - 260 liters (Expandable with rear seats folded).
Curb Weight Kg:
~900 - 1050 kg (Varies significantly by engine and equipment).
Euro Ncap Rating:
4 Stars (for models tested, e.g., 2004 testing results).
ABS:
Standard on most models, optional on early base models.
Esp Asl Hsa:
Optional on some higher trims and later models, particularly on the 100HP variant. Includes Hill Holder. (Check specific model for availability).
Brake Assist:
May be included with ESP systems.
Airbags:
Driver and front passenger airbags standard. Optional side airbags and curtain airbags available on higher trims.
Seatbelts:
Pre-tensioned seatbelts with force limiters for front seats. ISOFIX child seat anchor points.
Audio System:
Basic radio/CD player with standard speakers. Higher trims may feature MP3 capability and steering wheel controls.
Connectivity:
Auxiliary input for external audio devices (on some models). Bluetooth hands-free system was an option on later models.
Parking Sensors:
Optional rear parking sensors available on higher trims.
Cruise Control:
Rarely fitted as standard, available as an option on some higher-spec models.
Oil Change Interval:
Typically every 15,000 km or 1 year, whichever comes first. (Consult manual for specific engine and oil type).
Air Filter Replacement:
Every 30,000 km or 2 years. (Inspect more frequently in dusty conditions).
Spark Plug Replacement Example:
1.1/1.2 Fire (8V): 45,000 km. 1.2 Fire (16V)/1.4 Fire: 60,000 km. (Refer to manual for exact plugs and intervals).
Timing Belt Replacement:
Crucial for Fire engines. Typically 120,000 km or 5 years. Failure can cause severe engine damage. (Critical to adhere to this interval).
Engine Oil Specification:
Refer to manual. Commonly SELENIA K Pure Energy 0W-30 or SELENIA 20K FOR. Always use oil meeting Fiat's specific API and ACEA standards for the engine variant.
Engine Oil Capacity Example:
Approx. 2.8 - 3.2 liters (for 1.2L engine, including filter). Check dipstick.
Coolant Specification:
Paraflu Up or similar coolant concentrate mixed 50:50 with distilled water. (Typically ethylene glycol based).
Coolant Capacity:
Approx. 5.0 - 5.5 liters.
Brake Fluid Specification:
DOT 4.
Power Steering Fluid:
Hydraulic fluid, typically of the Dexron III type or specific Fiat recommendation. (Not all models have hydraulic power steering; electric is common).
Common Faults:
Clutch wear (especially in city driving), minor electrical gremlins, suspension wear (bushings, ball joints), potential EGR valve issues on diesel models, timing belt maintenance is critical.
Reliability Perception:
Generally considered reliable for its class, especially with proper maintenance. Certain components may require more frequent attention due to its city car nature.
Manufacturer Origin:
Italy
Brand Focus:
Fiat is known for producing small, economical, and stylish cars for the mass market.
First Generation Launch:
1980 (Original Fiat Panda).
Second Generation Launch:
2003
Key Milestone 100Hp:
Introduction of the Fiat Panda 100HP in 2006, offering a significant performance upgrade with its 1.4L engine and sportier suspension.
Production Location:
Pomigliano d'Arco, Naples, Italy.
Production Years Covered By Manual
Production Run:
2003-2012 (for this specific manual's coverage).
