Introduction
|
|
Market Position
|
|
Vehicle Type:
|
Light Commercial Vehicle (LCV) / Ute / Pickup Truck
|
|
Target Audience:
|
DIY mechanics, independent workshops, fleet maintenance, and owners seeking to maintain and repair their Isuzu Holden Rodeo.
|
|
Competitive Analysis
|
|
Competitors:
|
Ford Ranger, Mazda BT-50, Toyota Hilux, Mitsubishi Triton, Nissan Navara (during the 2003-2008 model years).
|
|
Key Features
|
|
Manual Value Proposition:
|
Provides comprehensive, factory-level repair and maintenance information, crucial for accurate diagnosis and repair, saving significant costs compared to dealership servicing. Instant download offers immediate access.
|
|
Vehicle Strengths:
|
Known for its robust construction, off-road capability (especially 4x4 models), reliable diesel engines (4JA1/4JH1-TC), and versatility as both a workhorse and lifestyle vehicle.
|
|
Manual Details
|
|
Coverage
|
|
Coverage Areas:
|
General Information, Heating and Airconditioning, Frame and Cab, Steering, Suspension, Wheels and Tires, Axle, Brakes, Engine (4JA1, 4JH1-TC, 6VE1, C24SE, Petrol HFV6), Transmission (AW30-40LE, JR405E, MSG Models, MUA Models), Clutch, Transfer Case, Electrical (Body and Chassis), Accessories & Restraints, Cab, Security
|
|
Page Count:
|
N/A (Digital Download)
|
|
Manual Type:
|
Factory Workshop Service Repair Manual
|
|
Language:
|
English
|
|
Format
|
|
File Format:
|
PDF
|
|
Compatibility:
|
All Versions of Windows & Mac
|
|
Delivery Method:
|
Instant Download
|
|
Manual Coverage
|
|
Systems Covered
|
|
Engine Systems:
|
Comprehensive coverage for 4JA1 (2.5L Diesel), 4JH1-TC (3.0L Turbo Diesel), 6VE1 (3.5L V6 Petrol), C24SE (2.4L Petrol), and Petrol HFV6 (3.6L V6) engines including: Engine mechanical, fuel system, ignition system, cooling system, lubrication system, emission control systems, engine diagnostics, and overhaul procedures.
|
|
Drivetrain Systems:
|
Detailed information for AW30-40LE (4-speed Automatic), JR405E (5-speed Automatic), MSG Models (Manual), and MUA Models (Manual) transmissions. Includes clutch system, transfer case operation and repair, drive shafts, axles, and differentials.
|
|
Chassis Systems:
|
In-depth coverage of steering system (power steering), suspension (front and rear), wheels, tires, brakes (hydraulic, ABS), and frame/chassis components.
|
|
Electrical Systems:
|
Extensive electrical schematics for body and chassis systems. Includes: lighting, instrumentation, power windows, door locks, wipers, horn, audio systems, air conditioning controls, security system, and accessory wiring.
|
|
Procedures Included
|
|
Maintenance Procedures:
|
Scheduled maintenance, oil changes, filter replacements, fluid checks and changes, spark plug replacement, belt inspection and replacement, brake pad and rotor replacement, battery maintenance.
|
|
Repair Procedures:
|
Step-by-step instructions for engine overhaul, transmission repair, brake system repair, steering and suspension component replacement, electrical component diagnostics and repair, body panel repair, and HVAC system servicing.
|
|
Troubleshooting Guides:
|
Diagnostic procedures and fault finding for various systems, including engine performance issues, transmission shifting problems, electrical gremlins, brake system malfunctions, and HVAC issues. Often includes symptom-based troubleshooting charts.
|
|
Technical Specifications:
|
Torque specifications for fasteners, engine component clearances, fluid capacities and types, wiring diagrams, diagnostic trouble codes (DTCs) and their meanings, component testing procedures.
|
|
Technical Depth
|
|
Depth Of Coverage:
|
Complete workshop level, covering everything from basic maintenance and fluid changes to complex engine and transmission rebuilds. Includes diagnostic procedures, component removal and installation, and troubleshooting.
|
|
Engine Specifications
|
|
Primary Engine
|
|
Engine Codes Covered:
|
4JA1, 4JH1-TC, 6VE1, C24SE, Petrol HFV6
|
|
Performance
|
|
4Ja1 Specs:
|
2.5L (2499cc) SOHC Diesel; Approx. 76-80 kW (102-107 hp) @ 3800-4000 rpm; Approx. 175-185 Nm (129-136 lb-ft) @ 2000-2400 rpm
|
|
4Jh1-Tc Specs:
|
3.0L (2999cc) DOHC Turbo Diesel; Approx. 85-96 kW (114-129 hp) @ 3600-3800 rpm; Approx. 280-320 Nm (207-236 lb-ft) @ 1800-2000 rpm
|
|
6Ve1 Specs:
|
3.5L (3494cc) DOHC V6 Petrol; Approx. 145 kW (195 hp) @ 5200 rpm; Approx. 320 Nm (236 lb-ft) @ 3000 rpm
|
|
C24Se Specs:
|
2.4L (2384cc) SOHC Petrol; Approx. 92 kW (123 hp) @ 5000 rpm; Approx. 190 Nm (140 lb-ft) @ 3000 rpm
|
|
Petrol Hfv6 Specs:
|
3.6L (3564cc) DOHC V6 Petrol (LW7/LY7); Approx. 175-180 kW (235-241 hp) @ 5800-6000 rpm; Approx. 325-343 Nm (240-253 lb-ft) @ 3200-3600 rpm
|
|
Fuel System
|
|
Diesel Fuel System:
|
Common Rail Direct Injection (CRDi) for 4JH1-TC; Indirect Injection for 4JA1.
|
|
Petrol Fuel System:
|
Multi-point Fuel Injection (MPI) for C24SE and 6VE1; Direct Injection (DI) or Port Injection (PI) for HFV6 depending on sub-model.
|
|
Maintenance
|
|
Service Intervals
|
|
Oil Change Interval:
|
Typically 5,000 - 10,000 km (3,000 - 6,000 miles) or 6-12 months, depending on engine type (petrol/diesel), driving conditions, and oil used. Refer to manual for specific recommendations.
|
|
Transmission Fluid Change:
|
Automatic: 40,000 - 80,000 km (25,000 - 50,000 miles). Manual: Check for leakage, typically serviced if issues arise. Refer to manual for specific fluid type and interval.
|
|
Fluid Specifications
|
|
Engine Oil Specification:
|
API CD/CE or SF/SG for older diesel engines; API SG/SH or higher for petrol engines. Viscosity grades like 15W-40, 10W-30 or 5W-30 depending on engine and climate. Refer to manual for precise specifications and capacities (e.g., 4JH1-TC typically requires 7.5L).
|
|
Coolant Specification:
|
Ethylene glycol-based, anti-freeze/anti-corrosion coolant. Capacity varies by engine, typically 8-10L. Use a 50/50 mix with distilled water.
|
|
Brake Fluid Specification:
|
DOT 3 or DOT 4 brake fluid.
|
|
Known Issues
|
|
Common Wear Items:
|
Clutch wear, brake components (pads, rotors), suspension bushings and ball joints, exhaust system corrosion, radiator hoses, glow plugs (diesel), EGR valve (diesel).
|
|
Diesel Specific Issues:
|
Potential for turbocharger issues on 4JH1-TC if maintenance is neglected, injector problems, DPF (Diesel Particulate Filter) issues on later emissions models (though less common on this generation).
|
