Segment:
Compact Executive Coupe / Sporty GT
Competitors:
BMW 3 Series Coupe, Audi A4 Coupe, Mercedes-Benz CLK, Peugeot RCZ (later model), Volkswagen Scirocco (later model)
Design Philosophy:
Combines Italian styling flair with a potent naturally aspirated V6 engine and a focus on driving dynamics.
Target Audience:
Enthusiasts seeking a stylish, performance-oriented coupe with a distinctive character.
Benefit To Buyer:
Provides comprehensive factory-level repair and maintenance information, enabling cost savings and empowering owners for self-service.
Primary Coverage:
Service, Repair, Maintenance, Troubleshooting
Specific Systems:
Engine mechanical, Fuel system, Throttle body, Cooling system, Lubrication system, Chassis, Electrical system, Emission control systems, Wiring diagrams
Estimated Page Count:
Extensive, likely exceeding 1500 pages (typical for a complete factory service manual)
Type:
Factory Service Repair Manual (Workshop Manual)
Language:
English (implied by product description)
File Format:
.ISO / .EXE (Disc Image File)
Engine Mechanical:
Complete disassembly and reassembly of the 3.2 V6 engine, including cylinder heads, crankshaft, pistons, connecting rods, timing components, valve train.
Fuel System:
Fuel injection system diagnostics and repair, fuel pump, injectors, fuel pressure regulator, fuel filter replacement.
Throttle Body:
Electronic throttle body operation, diagnostics, cleaning, and replacement procedures.
Cooling System:
Radiator, water pump, thermostat, cooling fans, coolant types and specifications, bleeding procedures.
Lubrication System:
Oil pump, oil pan, oil filter, oil types and specifications, lubrication points.
Chassis:
Suspension (front and rear), steering system, braking system (including ABS), wheel alignment specifications.
Electrical System:
Battery, charging system, starter motor, ignition system, lighting, sensors, actuators, body control modules.
Emission Control:
Catalytic converter, oxygen sensors, EVAP system, emissions testing procedures.
Wiring Diagrams:
Comprehensive electrical wiring diagrams for all vehicle systems.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, fluid checks and top-offs, spark plug replacement.
Repair:
Detailed step-by-step repair procedures for all major components and systems.
Troubleshooting:
Diagnostic procedures for common and uncommon faults, fault code interpretation, symptom-based troubleshooting.
Disassembly Reassembly:
Complete step-by-step instructions for the disassembly and reassembly of the entire vehicle.
Depth:
Comprehensive (from basic DIY to advanced mechanical and electrical diagnosis)
Engine Type:
Naturally Aspirated, V-configuration
Displacement:
3179 cc (3.2 Liters)
Horsepower Peak:
240 PS (237 bhp / 177 kW) @ 6200 rpm (approximate for the Busso V6)
Torque Peak:
289 Nm (213 lb-ft) @ 4800 rpm (approximate for the Busso V6)
Fuel Delivery:
Multi-point Fuel Injection (MPI)
Recommended Fuel:
Unleaded 95 RON (or higher)
Block Material:
Aluminum Alloy
Cylinder Head Material:
Aluminum Alloy
Bore X Stroke:
93.0 mm x 78.0 mm (approximate)
Compression Ratio:
10.0:1 (approximate)
Valve Train:
DOHC (Dual Overhead Camshafts), 4 valves per cylinder
Timing Drive:
Timing Belt (requiring regular replacement)
Euro Ncap Rating:
4 Stars (for the Alfa GT range, specific 3.2 V6 rating may vary)
Esp:
Standard (likely VDC - Vehicle Dynamic Control)
Brake Assist:
Likely included with ESP
Airbags:
Front, Side, Curtain Airbags (depending on trim)
Seatbelts:
Pre-tensioning Seatbelts
Oil Change Interval:
15,000 km or 1 year, whichever comes first (typical for this era, check manual for exact)
Timing Belt Replacement:
60,000 km or 5 years (critical for the Busso V6, early replacement recommended)
Spark Plug Replacement:
60,000 km (for the 3.2 V6)
Engine Oil:
Selena WR-FE 5W-40 or equivalent (refer to manual for exact OE specification, e.g., Selenia K.P.E. 5W-40)
Coolant:
Paraflu UP (Antifreeze/Coolant concentrate, blue color, ethylene glycol based)
Transmission Fluid:
API GL-4 SAE 75W-85 (Manual Transmission Gear Oil)
Engine Reliability:
Busso V6 is renowned for its sound and performance but requires diligent maintenance. Timing belt replacement is crucial. Potential for oil leaks from seals and gaskets.
Suspension:
Front wishbone bushes and ball joints can wear over time, affecting handling.
Electrical:
Minor electrical gremlins can occur, common in older Italian cars. Check connections and grounds.
Major Repairs:
Timing belt service, clutch replacement, suspension component renewal.
Brand Focus:
Italian automotive manufacturer with a long history of sporty and stylish vehicles, known for their 'Alfismo' culture.
Platform Basis:
Based on the Fiat Premium platform, shared with the Alfa Romeo 156 and 147.
Design Inspiration:
Designed by Bertone, featuring a distinctive coupé silhouette and a bold front-end design. Successor to the Alfa Romeo GTV.
Manufacturing Location:
Pomigliano d'Arco, Italy
Production Period:
2003-2010
