Target Audience:
Audi A4 Cabriolet owners seeking professional-level service and repair guidance
Advantage:
Comprehensive coverage, dealer-level information, instant PDF download, no additional software required
Feature 1:
All-inclusive service and repair information
Feature 2:
Directly downloadable in PDF format
Feature 3:
Covers all engine and transmission variants
Feature 4:
Dealer-level accuracy and detail
Engine Variants:
All Petrol and Diesel variations
Transmission Variants:
Manual and Automatic Transmissions
Regions Covered:
Global (standard Audi specifications)
Type:
Workshop Service and Repair Manual
Included Components:
Full Maintenance Manual, Full Wiring Manual, Full Workshop Manual
Accessibility:
PC, Mac, Smartphone, Tablet compatible
Bookmarking:
Fully bookmarked for ease of use
Engine Management:
Engine System, Fuel Charging and Controls, Accessory Drive, Engine Ignition, Engine Emission Control, Intake Air Distribution, Emissions, Electronic Engine Controls
Drivetrain:
Driveline System, Driveshaft, Manual Transmission, Clutch Controls
Suspension Steering Brakes:
Suspension, Wheels and Tyres, Brake System, Anti-Lock Control, Steering System
Fuel Exhaust Climate:
Fuel System, Exhaust System, Climate Control System, Air Distribution, Control Components
Electrical Body:
Lighting, Electrical Distribution, Electronic Feature Group, Body System, Body Panels, Interior Trim, Mirrors, Seating, Glass, Frames and Mechanisms, Instrument Panel and Console, Wipers and Washers, Roof, Bumpers, Safety Belt System
Comfort Convenience:
Information and Entertainment Systems
Chassis:
Jacking and Lifting, Noise Vibration and Harshness, Subframe and Mounting System
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, tune-ups
Diagnostics:
Troubleshooting, fault code interpretation, component testing
Repair:
Component replacement, system overhauls, wiring harness repairs
Installation:
Accessory installation, component upgrades
Body Work:
Body panel repair, metal repairs, glass replacement
Depth:
Dealer level factory manual standard, covering all elements of service and repair
Engine Type Example:
2.0L TFSI (Turbocharged Fuel Stratified Injection) Inline-4, 3.0L V6, 4.2L V8 (S4 variant)
Horsepower Range Example:
170 hp to 340 hp (depending on engine option)
Torque Range Example:
225 Nm to 410 Nm (depending on engine option)
Fuel Delivery Example:
Multi-point Fuel Injection (MPI) or Direct Injection (FSI)
Fuel Type:
Unleaded gasoline, Diesel (TDI)
Emission Standards:
Euro 4 / LEV II compliant (region dependent)
Transmission Type Std Example:
6-speed Manual
Transmission Type Opt Example:
6-speed Tiptronic Automatic with Sport Mode
Drivetrain Layout:
Front-Wheel Drive (FWD) or quattro All-Wheel Drive (AWD)
Manual Transmission Fluid:
G 052 171 A2 (or equivalent GL-4 SAE 75W-90)
Automatic Transmission Fluid:
G 052 162 A2 (or equivalent ATF LT71141)
NHTSA Rating Example:
Not explicitly available for this specific manual's scope, but generally high for its class in period.
Active Safety Features:
Anti-lock Braking System (ABS), Electronic Stability Control (ESC/ESP), Traction Control System (ASR/TCS)
Passive Safety Features:
Front airbags, Side airbags, Roll-over protection system (integrated into A-pillars and windscreen frame), Seatbelt pre-tensioners
Infotainment System Example:
Audi Symphony or Concert radio, optional navigation system (RNS-E)
Audio Features:
CD player, optional Bose sound system
Driver Assistance Features Example:
Cruise Control, Parking Sensors (rear), Xenon headlights with DRL (Daytime Running Lights)
Connectivity Features Example:
Optional Bluetooth preparation, Telematics systems (depending on market and options)
Oil Change Interval Example:
Every 15,000 km or 12 months, whichever comes first (Long-Life Service, requires specific VW 504 00 / 507 00 oil).
Timing Belt Replacement Example:
For specific engines (e.g., 3.0L V6), check manual. TFSI engines often use timing chains.
Brake Fluid Change Interval:
Every 2 years
Engine Oil Specification:
VW 503 00 / 503 01 (for petrol engines, check specific variant), VW 506 00 / 506 01 (for diesel engines, check specific variant)
Coolant Specification:
G12 Plus / G12++ (VW TL 774 F / G)
Common Issue 1:
Convertible top hydraulic leaks/failures
Common Issue 2:
Ignition coil failures (common across many Audi models of this era)
Common Issue 3:
PCV (Positive Crankcase Ventilation) system issues leading to oil consumption
Common Issue 4:
Water pump failures (especially on V6 engines)
Common Issue 5:
HVAC (Heater, Ventilation, and Air Conditioning) blower motor resistor failure
Brand Focus:
Audi AG is a German manufacturer of premium automobiles. Known for its quattro all-wheel-drive system, innovative technology, and design.
Cabriolet Lineage:
The A4 Cabriolet (Typ 8H) replaced the Audi A4 B5 Cabriolet and was part of the Audi A4 B6 generation, offering a more refined and larger convertible experience.
Production Period Example:
2002-2009 for the B6/B7 generation of A4 Cabriolet. The 2003 model falls within the initial B6 phase.
