Suzuki DL 650 V-Storm 2004-2009 Service Repair Manual

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

22 people are viewing this right now

类型: Motorcycle

斯库: 151142

标签: 2004 2005 2006 2007 2008 2009 DL 650 V-Storm Motorcycle Motorcycles Suzuki V Storm Models

产品多属性

Description

The Suzuki DL650 V-Strom, produced for the 2004 through 2009 model years, is a versatile middleweight adventure touring motorcycle renowned for its reliability and broad capability. Built upon a dependable V-twin engine platform, this model excels in a variety of riding conditions, from daily commuting to long-distance touring and even light off-road excursions. Its engineering emphasizes a balance of performance, comfort, and practicality, making it a popular choice for riders seeking a dependable companion for diverse journeys. The DL650 V-Strom's robust construction and user-friendly design contribute to its strong reputation for durability and owner satisfaction. This comprehensive service and repair manual provides essential information for the maintenance and repair of your Suzuki DL650 V-Strom. Covering critical systems including the engine, chassis, and electrical components, it details routine maintenance procedures, in-depth repair steps, and diagnostic strategies. With clear instructions and high-quality illustrations, this manual is an indispensable resource for owners, mechanics, and technicians aiming to ensure the optimal performance, longevity, and safety of their vehicle. It addresses common issues and provides detailed specifications to facilitate accurate servicing and troubleshooting.

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

DL650 V-Strom

Generation

Generation:

First Generation (2004-2010)

Codes

Chassis Code:

DL650 K4-K9

👋 Introduction

Market Position

Segment:

Middleweight Adventure Touring Motorcycle

Competitive Analysis

Key Competitors:

Kawasaki KLR650, Honda Transalp (in markets where available), BMW F650GS (earlier models)

Key Features

Vehicle Selling Points:

Versatility for commuting, touring, and light off-road use, reliable V-twin engine, comfortable ergonomics, good fuel economy

📋 Manual Details

Coverage Areas

Covered Model Years:

2004, 2005, 2006, 2007, 2008, 2009

Page Count

Estimated Page Count:

Approximately 500-700 pages (typical for this era Suzuki service manuals)

Manual Type

Manual Type:

Service and Repair Manual

Language

Language:

English

Format

File Format:

PDF / WinRAR

📖 Manual Coverage

Systems Covered

Engine Systems:

Engine mechanical, lubrication, cooling, fuel injection (FI), emission control, ignition, starting, charging

Chassis Systems:

Frame, suspension (front and rear), steering, brakes (front and rear), wheels and tires

Electrical Systems:

Wiring diagrams, lighting, instruments, starting and charging systems, ignition system, EFI system components

Procedures Included

Maintenance Procedures:

Oil changes, filter replacements, chain adjustment, spark plug replacement, air filter cleaning/replacement, brake fluid service, coolant service

Repair Procedures:

Engine disassembly and reassembly, transmission overhaul, carburetor/throttle body servicing, suspension component replacement, brake caliper servicing, electrical component troubleshooting and replacement

Diagnostic Procedures:

FI system diagnosis, troubleshooting common electrical faults, identifying engine performance issues

Technical Depth

Diagnostic Capabilities:

Detailed troubleshooting charts, fault code explanations (if applicable to the era's diagnostic tools), step-by-step diagnostic procedures

Rebuild Scope:

Comprehensive engine rebuild procedures, including torque specifications, clearances, and component testing

📊 Manual Specifications

File Format

Digital Format:

PDF (searchable text where available), WinRAR archive for compression

Print Quality

Illustration Quality:

High-resolution photos and illustrations for clarity in repair procedures

Binding Type

Binding Type:

Digital Delivery (No physical binding)

Paper Type

Paper Type:

N/A (Digital)

⚙️ Engine Specifications

Primary Engine

Engine Type:

Liquid-cooled, 4-stroke, V-twin, DOHC, 8-valve

Displacement:

647 cc

Performance

Bore X Stroke:

81.0 mm x 62.6 mm

Compression Ratio:

11.5:1

Horsepower:

Approximately 67 HP @ 8800 RPM (claimed)

Torque:

Approximately 44 lb-ft @ 7600 RPM (claimed)

Fuel System

Fuel Delivery:

Electronic Fuel Injection (EFI) with Dual Throttle Valves (SDTV)

Fuel Type:

Unleaded gasoline, 91 octane or higher (RON+MON)/2 recommended

Lubrication

Lubrication System:

Wet sump with oil cooler

Ignition

Ignition System:

Electronic ignition (transistorized)

🔧 Transmission

Standard

Transmission Type:

Constant mesh 6-speed, return type

Optional

Optional Transmission:

Features

Clutch Type:

Wet, multi-plate

Final Drive:

O-ring sealed chain, 525 series

📐 Dimensions

Exterior

Overall Length:

Approx. 2255 mm (88.8 in)

Overall Width:

Approx. 830 mm (32.7 in)

Overall Height:

Approx. 1360 mm (53.5 in)

Wheelbase:

Approx. 1555 mm (61.2 in)

Ground Clearance:

Approx. 165 mm (6.5 in)

Weights

Curb Weight:

Approx. 213 kg (470 lbs)

Fuel Tank Capacity:

22.0 L (5.8 US gal)

🛡️ Safety Features

Ratings

Safety Features:

Standard disc brakes front and rear, available ABS on select models/markets (check specific model)

Active Features

Braking System Front:

Dual hydraulic discs

Braking System Rear:

Single hydraulic disc

Passive Features

Lighting:

Halogen headlights, LED tail light

💡 Technology Features

Infotainment

Instrument Cluster:

Analog tachometer, digital speedometer, odometer, trip meter, fuel gauge, clock, engine coolant temperature indicator, gear position indicator (on some models/years)

Driver Assistance

ABS Availability:

Optional Anti-lock Braking System (ABS) available on some configurations and model years. The manual will likely cover ABS component diagnosis if equipped.

Connectivity

Diagnostic Ports:

Suzuki's proprietary diagnostic connector for FI system checks.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 6,000 km (3,700 miles) or 6 months, whichever comes first

Spark Plug Replacement Interval:

Every 24,000 km (15,000 miles)

Air Filter Inspection Interval:

Every 6,000 km (3,700 miles); replace as needed

Fluid Specifications

Engine Oil Type:

Suzuki Motor Oil 10W-40 SL grade or SJ grade, API certified, JASO MA certified (e.g., Motul 5100 10W-40)

Engine Oil Capacity With Filter:

3.1 L (3.3 US qt)

Coolant Type:

Suzuki Super Coolant (antifreeze and coolant mixture), or equivalent ethylene glycol-based coolant (50% solution with distilled water)

Brake Fluid Type:

DOT 4

Known Issues

Common Complaints:

Stalling at low RPMs (often related to idle control or TPS adjustment), occasional clutch drag, stator failures on higher mileage units, minor vibration at specific RPMs

Maintenance Tips:

Regular cleaning of the fuel injectors and throttle bodies, proper chain maintenance, timely valve clearance checks are crucial for optimal performance and longevity.

📚 Vehicle History

Brand Heritage

Suzuki Motorcycle Legacy:

Suzuki has a long history in motorcycle manufacturing, known for reliable engines and innovative designs across various segments.

Model Evolution

V Strom Lineage:

The DL650 V-Strom was introduced in 2004, leveraging the proven SV650 V-twin engine and chassis, adapted for the adventure touring segment.

Production

Manufacturing Location:

Japan

🏆 Awards & Recognition

Recognitions

Model Reputation:

The DL650 V-Strom is widely recognized for its reliability, value, and all-around capability, often praised in motorcycle reviews and by owner communities.

Ratings

Owner Satisfaction:

Generally high owner satisfaction due to its robust V-twin engine and dependable nature.
