Positioning:
Premium luxury SUV with off-road capabilities.
Competitors:
Porsche Cayenne, BMW X5, Mercedes-Benz ML-Class, Audi Q7.
Luxury Appointments:
High-quality interior materials, advanced comfort features, and sophisticated design.
Off Road Capability:
Terrain Response system, robust chassis, and advanced all-wheel-drive technology.
Performance:
Powerful V8 and V6 engine options, refined on-road dynamics.
Model Years Covered:
2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012
Model Variants Covered:
All models, engines, trims, and transmission types
Estimated Page Count:
Comprehensive (specific number not provided, implied extensive coverage)
Type:
Workshop Service Repair Manual
Digital Format:
Downloadable (PDF or similar)
Engine Management:
Detailed diagnostics, repair procedures, and specifications for all engine variants.
Transmission:
Coverage for automatic and manual transmission systems, including repair and overhaul.
Drivetrain:
Includes information on differentials, driveshafts, and four-wheel-drive systems.
Suspension Steering:
Comprehensive details on air suspension, hydraulic systems, steering rack, and components.
Brakes:
Service, repair, and troubleshooting for the entire braking system, including ABS and electronic parking brake.
Electrical System:
Extensive coverage of wiring diagrams, component testing, and repair for all electrical systems.
Body Chassis:
Information on body panel removal, repair, structural integrity, and associated components.
HVAC:
Service and repair procedures for the climate control system.
Infotainment Navigation:
Troubleshooting and basic service for the integrated audio, navigation, and communication systems.
Routine Maintenance:
Oil changes, filter replacements, fluid checks, and inspections.
Engine Overhaul:
Complete engine rebuild procedures, component replacement, and tuning.
Transmission Repair:
Step-by-step guides for transmission removal, disassembly, repair, and reassembly.
Suspension Component Replacement:
Instructions for replacing air springs, shocks, control arms, and other suspension parts.
Brake System Service:
Pad and rotor replacement, caliper service, brake fluid bleeding, and diagnostic procedures.
Electrical Diagnostics:
Troubleshooting using wiring diagrams, sensor testing, and module diagnostics.
Bodywork Repair:
Procedures for dent repair, panel replacement, and bumper servicing.
Troubleshooting Guides:
Diagnostic flowcharts and symptom-based troubleshooting for common issues.
Component Testing:
Specific tests and specifications for various sensors, actuators, and control modules.
Depth:
Complete workshop level, covering everything from basic maintenance to full engine and transmission rebuilds.
Detail Level:
Step-by-step instructions with detailed diagrams and torque specifications.
Engine Options:
Primarily 4.2L V8 (Naturally Aspirated & Supercharged), 4.4L V8 (BMW-derived), 3.6L V6 (BMW-derived), 4.0L V8 Diesel (TDV8), 3.0L V6 Diesel (TDV6).
Horsepower Range:
Approx. 270 hp (V6 Diesel) to 510 hp (Supercharged V8).
Torque Range:
Approx. 440 Nm (V6 Diesel) to 700 Nm (Supercharged V8).
Fuel Delivery:
Electronic fuel injection (MPI/GDI) for petrol engines, Common Rail Direct Injection (CRDI) for diesel engines.
L322 V8 Petrol:
4.4L M62TUB44 (BMW era)
L320 V8 Supercharged:
4.2L 428PS, 5.0L 508PS (AJ-V8 Gen III)
L320 V8 Diesel:
3.6L TDV8 (DMF, EX200), 4.4L TDV8 (448DT, TDV8)
L320 V6 Diesel:
3.0L TDV6 (306DT)
Gearbox Type:
Primarily 6-speed automatic (ZF 6HP series for many models, later 8-speed for some variants).
Optional Gearbox:
Some earlier models may have offered a 5-speed automatic.
Drivetrain Layout:
Permanent four-wheel drive (4WD) with center differential and often a locking rear differential.
Transmission Control:
Electronic control with manual override (CommandShift).
Wheelbase:
Approx. 2,745 mm (108.1 in)
Length:
Approx. 4,784 mm (188.3 in)
Width:
Approx. 1,915 mm (75.4 in) (excluding mirrors)
Height:
Approx. 1,780 mm (70.1 in) (variable with air suspension)
Curb Weight:
Varies significantly by engine and specification, starting around 2,100 kg (4,600 lbs).
Euro Ncap Rating:
4 Stars (2007 model)
Terrain Response:
Selectable modes for various terrains (e.g., Sand, Mud, Gravel, Snow, Rock Crawl).
Electronic Stability Control:
Standard, including Trailer Stability Assist.
Hill Descent Control:
Standard.
Airbags:
Front, side, and curtain airbags.
Child Seat Anchors:
ISOFIX mounting points.
Touchscreen System:
Features a touchscreen interface for navigation, audio, and climate control (updated significantly in 2010 model).
Audio Systems:
Optional Harman Kardon or Meridian premium audio systems.
Adaptive Cruise Control:
Available on some models.
Parking Aids:
Front and rear parking sensors, rearview camera (available).
Bluetooth:
Standard or optional for hands-free calling and audio streaming.
Usb Aux Input:
Available for media playback.
Oil Change Interval:
Typically 10,000-15,000 miles (16,000-24,000 km) or 12 months, whichever comes first (varies by engine and oil specification).
Transmission Fluid Change:
Recommended at 40,000-60,000 miles (64,000-96,000 km) or based on driving conditions. Lifelong fluid is not recommended by independent specialists.
Engine Oil Spec:
API SN/SM or ACEA A3/B4, viscosity typically 5W-30 or 5W-40 (refer to specific engine for exact spec).
Transmission Fluid Spec:
ZF LifeguardFluid 6 for 6-speed automatics, ZF LifeguardFluid 8 for 8-speed automatics (check specific gearbox).
Coolant Type:
OAT (Organic Acid Technology) coolant, typically orange or pink (e.g., Jaguar/Land Rover STC50527 or equivalent).
Air Suspension Faults:
Common issues include leaking air springs, compressor failure, and valve block problems.
Timing Chain Wear:
Can be an issue on certain V8 petrol engines (especially the 4.4L BMW M62) if not properly maintained.
Diesel Particulate Filter Dpf Issues:
DPF regeneration problems can occur with frequent short trips, leading to blockages.
Intercooler Leaks:
Can affect TDV6 and TDV8 diesel engines, impacting performance.
Electronically Controlled Transfer Case:
Potential issues with the actuator or control module.
Land Rover Legacy:
Long history of producing capable off-road vehicles, known for durability and luxury.
First Generation L320:
Launched in 2005 based on the L322 Range Rover platform but shorter wheelbase; designed to be more sporting and road-focused.
Facelift 2010:
Significant update with revised styling, new interior, and updated powertrain options (including the 5.0L Supercharged V8 and 3.0L TDV6).
Manufacturing Plant:
Solihull, West Midlands, United Kingdom.
