🏷️ Basic Information

Make:

Alfa Romeo

Model:

Brera / Spider

Model Code:

Type 939

Generation Designation:

First Generation (939 Series)

Engine Codes:

2.2 JTS (939A5000), 3.2 JTS (939A000, 939A0000, 939A0001), 2.4 JTD 20V (939B5000)

👋 Introduction

Product Offering:

High-quality, complete, and informative workshop repair and service manual for DIY enthusiasts and professional mechanics, offering a cost-effective alternative to dealership services.

Manual Quality Statement:

Positions itself against 'cheap, incomplete, inferior manuals' by emphasizing completeness, official information, and customer satisfaction guarantee.

Delivery And Access:

Instant digital download link provided immediately after payment, with no usage restrictions on the saved file.

Customer Support:

Guaranteed customer satisfaction with prompt email support (within hours) for any issues encountered with the purchased item, including replacement links or full refunds if at fault.

Content Attributes:

Abundant illustrations, lots of pictures & diagrams, comprehensive diagnostic and repair procedures, fault finding guides.

📋 Manual Details

Covered Model Years:

2005, 2006, 2007, 2008, 2009, 2010

Covered Engine Variants:

2.2 JTS (185 PS / 136 kW), 3.2 JTS V6 (260 PS / 191 kW), 2.4 JTD 20V Diesel (200 PS / 147 kW)

Body Styles Covered:

Coupe (Brera), Convertible/Roadster (Spider)

Estimated Page Count:

Extensive (indicative of full factory coverage, specific number not provided in product description but implies comprehensive)

Manual Type:

Workshop Repair & Service Manual

Supported Languages:

Czech (CZ), English (EN), German (DE), Spanish (ES), French (FR), Greek (GK), Italian (IT), Dutch (NL), Polish (PL), Portuguese (PT), Turkish (TR)

Digital Format:

Downloadable digital file (implied PDF or similar e-book format)

📖 Manual Coverage

Mechanical Systems:

Engine (complete service, disassembly, reassembly, removal), Fuel and Lubrication Systems, Cooling System, Exhaust System, Transmission (service, removal, installation), Clutch Removal and Installation, Brakes, Steering, Suspension (front and rear), Axles, Chassis Assembly

Electrical Systems:

Electrical System (complete overview), Ignition System, Charging System, Starter System, Battery, Switches, Wiring Diagrams, Wire/Cable/Hose Routing

Bodywork And Chassis:

Bodywork, Chassis, Body Panels, Structural Information

Maintenance Procedures:

Periodic Maintenance and Tune-Up Procedures, Factory Maintenance Schedules, Lube Points, Oil Types, Fluid Specifications

Repair Procedures:

All Factory Repair Procedures, Engine Servicing, Rebuilds, Refurbishment, Restoration, Fault Finding, Troubleshooting, Diagnostic Procedures

Technical Data And Specifications:

Tightening Torques, Service Data, Detailed Specifications, Engine Firing Order, Carb Rebuild/Adjustments (if applicable to specific engines), U-Joint Service Procedures, CV Joint Service Procedures, Timing Chain Service, Exhaust Service

Depth Of Coverage:

Comprehensive DIY Repair and Professional Workshop Level. Covers from basic maintenance to complete engine overhaul, electrical diagnostics, and chassis repair. Provides same information as professional technicians.

📊 Manual Specifications

File Type:

Digital Download (likely PDF)

Printability:

Printable (designed for users to print sections as needed for garage use)

Binding Description:

N/A (Digital format, binding is relevant for physical manuals)

Paper Quality:

N/A (Digital format, paper type is relevant for physical manuals)

⚙️ Engine Specifications

2.2 Jts Engine Details:

Naturally aspirated inline-4, 2.2-liter displacement, Fuel Stratified Injection (JTS), 185 PS (136 kW) @ 6500 rpm, 230 Nm (170 lb-ft) @ 4500 rpm. Engine Code: 939A5000.

3.2 Jts V6 Engine Details:

Naturally aspirated V6, 3.2-liter displacement, Fuel Stratified Injection (JTS), 260 PS (191 kW) @ 6200 rpm, 320 Nm (236 lb-ft) @ 4500 rpm. Engine Codes: 939A000, 939A0000, 939A0001.

2.4 Jtd 20V Engine Details:

Turbocharged inline-5 Diesel, 2.4-liter displacement, Common Rail Direct Injection (JTD), 200 PS (147 kW) @ 3500 rpm, 400 Nm (295 lb-ft) @ 2000 rpm. Engine Code: 939B5000.

Power Output Range:

136 kW (185 PS) to 191 kW (260 PS) depending on engine variant.

Injection Type:

Fuel Stratified Injection (JTS) for petrol engines; Common Rail Direct Injection (JTD) for diesel engines.

🔧 Transmission

Standard Gearbox:

6-speed manual transmission (Getrag M32 for most variants).

Optional Gearbox:

6-speed Q-Tronic automatic transmission (typically available with 3.2 JTS and 2.4 JTD engines).

Drivetrain:

Front-wheel drive (FWD) standard. All-wheel drive (Q4 system, derived from GM's Theta platform) available with the 3.2 JTS V6 engine.

📐 Dimensions

Length Brera:

Approx. 4410 mm (173.6 in)

Width Brera:

Approx. 1830 mm (72.0 in)

Height Brera:

Approx. 1370 mm (53.9 in)

Length Spider:

Approx. 4414 mm (173.8 in)

Width Spider:

Approx. 1830 mm (72.0 in)

Height Spider:

Approx. 1320 mm (52.0 in)

Boot Capacity Brera:

Approx. 350 liters (12.4 cu ft)

Boot Capacity Spider:

Approx. 212 liters (7.5 cu ft)

Curb Weight Range:

Approx. 1500 kg - 1750 kg (depending on engine and drivetrain)

🛡️ Safety Features

Euro Ncap Rating:

Brera: 5 Stars (2005). Spider: 4 Stars (2005).

Standard Active Safety:

ABS with EBD, Brake Assist (BAS), Traction Control (TCS), Electronic Stability Program (ESP) with Hill Holder function.

Standard Passive Safety:

Multiple airbags (driver, passenger, side, curtain), active headrests, crumple zones, safety cage structure.

💡 Technology Features

Infotainment System:

Factory fitted radio/CD player, optional premium audio systems (e.g., Bose), Bluetooth connectivity for hands-free calling and audio streaming available on some models. Navigation system often optional.

Driver Assistance Features:

Cruise control, parking sensors (rear, sometimes front), rain-sensing wipers, auto-dimming rearview mirror. Limited advanced driver-assistance systems compared to modern vehicles.

Connectivity Options:

Basic connectivity via Bluetooth for phone calls and audio streaming. USB connectivity often not standard.

🔧 Maintenance

Oil Change Interval Petrol:

Typically 20,000 km (12,500 miles) or 12 months, whichever comes first (check specific oil grade and driving conditions). Refer to manual for exact guidance.

Oil Change Interval Diesel:

Typically 25,000 km (15,500 miles) or 12 months, whichever comes first (check specific oil grade and driving conditions). Refer to manual for exact guidance.

Major Service Interval:

Recommended major services at 40,000 km / 60,000 km and 80,000 km / 120,000 km, covering timing belt (if applicable, check engine specifics), fluids, filters, and inspections. Manual provides detailed schedule.

Engine Oil Petrol:

API SN/SM/SL or ACEA C3 or A3/B4, SAE 5W-40 or 5W-30 (e.g., Selenia Star Pure Energy KFE 5W-40 or KPE 0W-30). Refer to manual for exact OEM specifications.

Engine Oil Diesel:

API CF or ACEA C3, SAE 5W-30 (e.g., Selenia WR Pure Energy 5W-30). Refer to manual for exact OEM specifications.

Coolant:

Paraflu UP (concentrated antifreeze/coolant) mixed with distilled water, typically a 50/50 mix. Refer to manual for specific type and capacity.

Brake Fluid:

DOT 4 (refer to manual for specific OEM grade).

Common Problems Petrol:

Potential issues include minor oil leaks from valve cover gaskets, intake manifold issues (e.g., swirl flaps on 2.2 JTS), and exhaust manifold cracks (especially on 3.2 V6). Check for timing chain wear on higher mileage 2.2 JTS. Clutch slave cylinder failures.

Common Problems Diesel:

Diesel Particulate Filter (DPF) regeneration issues, glow plug failures, EGR valve clogging, turbocharger wear, swirl flap issues in the intake manifold. Check for clutch and dual-mass flywheel wear.

Chassis And Electrical:

Front suspension wear (bushings, ball joints), wheel bearing failures, electronic system glitches (e.g., CAN bus errors), parking sensor issues, and some water ingress issues in certain areas.

📚 Vehicle History

Alfa Romeo Legacy:

Alfa Romeo boasts a long history of producing stylish, driver-focused sports cars and grand tourers with a strong emphasis on design and handling.

Brera Spider Genesis:

Based on the GM Epsilon platform (shared with Opel Vectra C/Signum). Designed by Giorgetto Giugiaro (Brera) and Pininfarina (Spider). The Brera was initially a concept car. Launched in 2005, with the Spider following shortly after.

Production Period:

2005 - 2010

Manufacturing Location:

Italy (primarily at the Pomigliano d'Arco plant, alongside the Alfa Romeo 159).

🏆 Awards & Recognition

Design Awards:

The Brera concept was highly acclaimed for its design, winning numerous awards. The production models maintained much of this aesthetic appeal.

Safety Awards:

Euro NCAP 5-star rating for Brera, indicating a high standard of occupant protection for its era.
