KTM 950 990 Adventure 2005 Service Repair Manual

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

23 people are viewing this right now

类型: Motorcycle

斯库: 149035

标签: 2005 950 990 Adventure KTM Motorcycle Motorcycles

产品多属性

Description

This manual covers the 950 Adventure and 990 Adventure models from 2005. Renowned for their V-twin LC8 engines, long-travel suspension, and robust construction, these dual-sport motorcycles are engineered for both adventure touring and challenging off-road excursions. The 950 Adventure features a carbureted LC8 V-twin, while the 990 Adventure offers a fuel-injected evolution of this platform, both known for their significant torque and power delivery. A heritage in off-road and motorsport translates into these highly capable machines, designed to handle diverse terrains and long-distance travel with reliability and comfort. This comprehensive service repair manual provides detailed information for maintaining and repairing your 950 or 990 Adventure. It covers all major systems, including engine overhaul, transmission, clutch, brakes, suspension, and electrical systems, with specific procedures for both carbureted and fuel-injected models. You will find step-by-step instructions for scheduled maintenance, component repair, and troubleshooting common issues. Technical specifications, wiring diagrams, and fluid recommendations are also included, making this manual an essential resource for owners and technicians seeking to ensure optimal performance and longevity of their vehicle.

🏷️ Basic Information

Identification

Make:

Model:

990 Adventure

Year:

Codes

Engine Code 950:

LC8 V-Twin

Engine Code 990:

LC8 V-Twin (Fuel Injected)

👋 Introduction

Market Position

Vehicle Segment:

Dual-sport/Adventure Touring Motorcycle

Key Features

Engine Type:

V-twin LC8 engine known for its torque and power delivery

Suspension:

Long-travel suspension for off-road capability and comfortable on-road touring

Design Philosophy:

Built for both long-distance adventure touring and challenging off-road terrain

📋 Manual Details

Coverage Areas

Coverage:

Comprehensive service, repair, and maintenance

Page Count

Estimated Page Count:

Likely 500+ pages (typical for a full service manual)

Manual Type

Manual Type:

Service Repair Manual

Language

Language:

English

Format

File Format:

PDF Download

📖 Manual Coverage

Systems Covered

Engine:

Engine overhaul, top-end rebuild, cooling system, lubrication system, fuel delivery (carbureted for 950, fuel injected for 990), exhaust system

Transmission:

Clutch operation, gearbox disassembly and assembly, shift mechanism

Chassis:

Frame inspection, suspension (front and rear), steering system, swingarm

Brakes:

Brake system components, hydraulic circuits, pad replacement, fluid bleeding, caliper overhaul

Electrical:

Wiring diagrams, ignition system, starting system, charging system, lighting, instrumentation, ECU (for 990), sensors

Bodywork:

Fairing removal and installation, body panel repairs, seat assembly

Procedures Included

Maintenance:

Scheduled maintenance tasks, oil and filter changes, chain adjustment, spark plug replacement, air filter cleaning/replacement

Repair:

Step-by-step repair procedures for all major systems, component disassembly and reassembly

Troubleshooting:

Diagnostic procedures for common issues, fault code interpretation (for 990)

Technical Depth

Depth:

Suitable for professional technicians and skilled DIY mechanics with basic mechanical and electrical knowledge

📊 Manual Specifications

File Format

Print Quality:

Full Printable

Zoom Capability:

Delivery

Delivery Method:

Instant Download

Requirements

Software Requirements:

Adobe PDF Reader, WinZip

Compatibility

Operating Systems:

All Versions of Windows & Mac

⚙️ Engine Specifications

Primary Engine 950

Engine Type:

942cc, 75° V-twin, four-stroke, LC8

Bore X Stroke 950:

98 x 62.4 mm

Fuel System 950:

Two Keihin 38mm CV carburetors

Power Output 950:

Approx. 98 hp @ 8000 rpm

Torque 950:

Approx. 93 Nm (69 lb-ft) @ 7000 rpm

Primary Engine 990

Engine Type:

999cc, 75° V-twin, four-stroke, LC8 (Fuel Injection)

Bore X Stroke 990:

101 x 62.4 mm

Fuel System 990:

Electronic fuel injection with dual throttle bodies

Power Output 990:

Approx. 105 hp @ 7500 rpm

Torque 990:

Approx. 98 Nm (72 lb-ft) @ 6000 rpm

Performance

Compression Ratio 950:

11.1:1

Compression Ratio 990:

11.5:1

Cooling System:

Liquid-cooled

🔧 Transmission

Standard

Transmission Type:

6-speed constant mesh

Features

Clutch Type:

Wet multi-disc clutch, hydraulically operated

📐 Dimensions

Weights

Dry Weight 950:

Approx. 202 kg (445 lbs)

Dry Weight 990:

Approx. 208 kg (458 lbs)

Capacity

Fuel Tank Capacity:

22 Liters (5.8 Gallons)

🛡️ Safety Features

Passive Features

Frame Type:

CrMo steel trellis frame

Brakes Front:

Dual 300mm discs with 4-piston calipers

Brakes Rear:

Single 240mm disc with 2-piston caliper

Wheels:

Spoked wheels (21" front, 18" rear) suitable for off-road use

💡 Technology Features

Infotainment

Instrumentation:

Analog tachometer, digital speedometer, trip meters, clock, coolant temperature gauge. (990 may have additional warning lights)

Driver Assistance

ABS was an optional feature on some 2005 models (check specific vehicle configuration); manual would detail its operation and servicing.

Connectivity

ECU 990:

The 990's ECU manages fuel injection and ignition timing, with potential for diagnostic port access covered in the manual.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically every 5,000-7,500 km (or as specified in manual)

Valve Clearance Check:

Typically every 10,000-15,000 km (crucial for LC8 engines)

Fluid Specifications

Engine Oil Type:

API SG/SH/SJ or higher, JASO MA compliant 10W-40 or 10W-50 (refer to manual for exact spec)

Coolant Type:

Ethylene glycol based coolant (50% mix with distilled water)

Brake Fluid Type:

DOT 4

Known Issues

Cam Chain Tensioner:

Early models had hydraulic cam chain tensioners that could fail; manual would likely cover inspection and replacement with manual units.

Water Pump Seal:

Potential for water pump seal leaks over time; manual will detail inspection and replacement.

Carburetor Sync 950:

Crucial for smooth running on the 950; manual provides the procedure.

📚 Vehicle History

Brand Heritage

Brand Focus:

KTM is renowned for its off-road and motorsport heritage, translating this into capable adventure bikes.

Model Evolution

Development:

The 950 Adventure marked KTM's significant entry into the adventure touring segment, leveraging their LC8 engine platform. The 990 represents an evolution with fuel injection and other refinements.

🏆 Awards & Recognition

Recognitions

Design Award Potential:
