Pontiac Vibe 2005 Service Repair Workshop Manual

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Pontiac Model: Vibe Year: 2005 Trim Level Coverage: All trims (Base, GT) Generation Generation Designation: First Generation (2003-2009) Codes Platform: GM 'Toyota Matrix' platform (Zze130)...

27 people are viewing this right now

类型: Car

斯库: 182074

标签: 2005 Car Cars Featured Pontiac Vibe

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Pontiac

Model:

Year:

Trim Level Coverage:

All trims (Base, GT)

Generation

Generation Designation:

First Generation (2003-2009)

Codes

Platform:

GM 'Toyota Matrix' platform (Zze130)

👋 Introduction

Market Position

Market Position:

Compact hatchback/wagon segment, offering practicality and efficiency with a sportier alternative to mainstream offerings.

Competitive Analysis

Key Competitors:

Mazda3, Honda Civic Si, Volkswagen GTI, Ford Focus.

Key Features

Vibe Key Features:

Versatile cargo space, sporty GT model option, reliable Toyota mechanicals, distinctive styling.

Manual Value Proposition

Manual Value:

Provides professional-level repair and maintenance information, empowering owners and independent mechanics with the same data used by dealerships.

📋 Manual Details

Coverage Areas

Coverage Areas:

Engine, Transmission, Drivetrain, Suspension, Steering, Brakes, HVAC, Electrical Systems, Body, Interior, Diagnostics, Troubleshooting, Maintenance

Page Count

Page Count:

Hundreds of pages (exact number not specified but described as comprehensive)

Manual Type

Manual Type:

Factory Service Repair Workshop Manual

Language

Language:

English

Format

Format:

Digital Download (PDF)

📖 Manual Coverage

Systems Covered

Engine Systems:

1.8L 1ZZ-FE (I4), 2.4L 2AZ-FE (I4 - GT Model), Engine Mechanical, Engine Electrical, Fuel System, Cooling System, Lubrication System, Emission Control Systems

Transmission Systems:

Manual Transmission (5-speed), Automatic Transmission (4-speed - Toyota U241E based), Drivetrain Components (CV Axles, Differentials)

Chassis Systems:

Suspension (Front McPherson Strut, Rear Torsion Beam), Steering (Power Steering System), Brakes (Front Disc, Rear Drum/Disc depending on trim), ABS, Wheels, Tires

Electrical Systems:

Starting and Charging System, Ignition System, Lighting System, Instrumentation, Power Accessories, Body Control Modules, Audio Systems, HVAC Controls, SRS (Airbag) System

Body Interior Systems:

Body Construction, Doors, Hood, Tailgate, Bumpers, Interior Trim, Seating Systems, Restraint Systems

Procedures Included

Maintenance Procedures:

Oil Changes, Filter Replacements, Fluid Checks and Replenishments, Spark Plug Replacement, Belt Inspections and Replacements, Brake Pad and Rotor Service, Tire Rotation

Repair Procedures:

Engine Component Rebuilds, Transmission Overhaul, Suspension Component Replacement, Brake System Repairs, Electrical Component Diagnosis and Replacement, Body Panel Repair and Replacement

Troubleshooting Procedures:

Systematic Diagnostic Flowcharts, DTC (Diagnostic Trouble Code) Interpretation and Resolution, Common Symptom Diagnosis

Diagnostic Procedures:

On-Board Diagnostics (OBD-II) Scan Tool Usage, Sensor Testing, Actuator Testing, Circuit Testing

Technical Depth

Technical Depth:

Comprehensive: Covers basic maintenance to complete engine and transmission rebuilds, including detailed diagnostic procedures and exploded views.

📊 Manual Specifications

File Format

File Format:

Searchable Text:

Yes (implied by standard PDF capabilities and target audience of professionals)

Print Quality

Printability:

Printable (single pages or entire manual)

Binding Type

Binding Type:

Not Applicable (Digital Download)

Paper Type

Paper Type:

Not Applicable (Digital Download)

Compatibility

Operating Systems:

Windows and MAC compatible

Licensing

Usage License:

Lifetime use on unlimited devices

Version

Version Type:

Full, unrestricted version

⚙️ Engine Specifications

Primary Engine

Base Engine Displacement:

1.8 Liter

Base Engine Code:

1ZZ-FE

Base Engine Cylinders:

Inline-4

Base Engine Horsepower:

126 hp @ 6000 rpm

Base Engine Torque:

122 lb-ft @ 4200 rpm

Gt Engine Option

Gt Engine Displacement:

2.4 Liter

Gt Engine Code:

2AZ-FE

Gt Engine Cylinders:

Inline-4

Gt Engine Horsepower:

164 hp @ 6000 rpm

Gt Engine Torque:

163 lb-ft @ 4000 rpm

Fuel System

Fuel Delivery:

Electronic Fuel Injection (EFI) - Sequential multiport

Recommended Fuel:

87 Octane Regular Unleaded (for 1ZZ-FE), 87 Octane Regular Unleaded recommended for 2AZ-FE (GT)

Engine Management

Engine Control Unit:

GM ECM (Engine Control Module) controlling Toyota sourced engine components

🔧 Transmission

Standard Transmission

Standard Transmission Type:

5-speed Manual Transmission

Optional Transmission

Optional Transmission Type:

4-speed Automatic Transmission (U241E)

Automatic Transmission Features

Automatic Transmission Logic:

Electronically Controlled Automatic Transmission (ECT)

Transmission Fluid

Manual Transmission Fluid Spec:

API GL-4, SAE 75W-90 (Specific Toyota/GM specification recommended)

Automatic Transmission Fluid Spec:

Dexron III/VI or equivalent (Toyota Type T-IV often compatible/recommended)

📐 Dimensions

Exterior

Length:

169.1 inches (4295 mm)

Width:

69.4 inches (1763 mm)

Height:

60.0 inches (1524 mm)

Wheelbase:

102.4 inches (2600 mm)

Cargo

Cargo Volume Seats Up:

27.7 cubic feet (784 liters)

Cargo Volume Seats Down:

53.3 cubic feet (1509 liters) (with rear seats folded)

Weights

Curb Weight Base:

Approx. 2850 lbs (1293 kg)

Curb Weight Gt:

Approx. 2970 lbs (1347 kg)

🛡️ Safety Features

Ratings

NHTSA Front Impact Driver:

5-Star

NHTSA Front Impact Passenger:

5-Star

IIHS Front Offset Crash Rating:

IIHS Side Impact Crash Rating:

Acceptable

Active Features

Standard Safety Features:

Anti-lock Braking System (ABS), Traction Control System (TCS), Electronic Stability Control (ESC - often optional or on higher trims)

Passive Features

Passive Safety Features:

Front Airbags, Side-Curtain Airbags (optional), Front Seatbelt Pretensioners

💡 Technology Features

Infotainment

Infotainment System:

Standard AM/FM/CD stereo with optional premium audio, auxiliary input (may vary by trim and options).

Driver Assistance

Driver Assistance Features:

ABS, Traction Control (optional/standard depending on trim), Cruise Control.

Connectivity

Connectivity Options:

Limited by modern standards; primarily focused on audio playback.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 5,000 miles (8,000 km) or 6 months (whichever comes first) under normal driving conditions. Consult manual for severe driving conditions.

Engine Air Filter Replacement:

Every 30,000 miles (48,000 km) or as needed based on inspection.

Spark Plug Replacement 1Zz-Fe:

Approx. 100,000 miles (160,000 km) using iridium-tipped plugs.

Transmission Fluid Change Automatic:

Every 60,000 miles (96,000 km) or as specified by severe service intervals.

Fluid Specifications

Engine Oil Capacity 1Zz-Fe:

4.4 US quarts (4.2 Liters) with filter, SAE 5W-30 recommended (API SM or higher).

Engine Oil Capacity 2Az-Fe:

4.5 US quarts (4.3 Liters) with filter, SAE 5W-30 recommended (API SM or higher).

Coolant Capacity:

Approx. 5.9 US quarts (5.6 Liters) for 1ZZ-FE, 6.2 US quarts (5.9 Liters) for 2AZ-FE (with 50/50 mix of Toyota Super Long Life Coolant or equivalent).

Known Issues

Common Issues:

Excessive oil consumption (especially on 1ZZ-FE early models), potential for catalytic converter failure due to oil burning, front suspension component wear (bushings, struts), minor interior trim rattles.

Transmission Issues:

Automatic transmission may exhibit delayed shifting or harsh engagement if fluid is neglected. Manual transmissions are generally robust.

📚 Vehicle History

Brand Heritage

Pontiac Heritage:

Pontiac was an American automobile division of General Motors known for performance-oriented and sporty vehicles.

Model Evolution

Vibe Development:

Co-developed with Toyota, sharing the platform and many mechanical components with the Toyota Matrix. This ensured reliability and quality.

Production

Manufacturing Location:

Fremont, California, USA (NUMMI plant)

Production Years:

2003-2009

🏆 Awards & Recognition

Recognitions

Popular Mechanics Editors Choice:

Awarded 'Editors' Choice' for its value and practicality in 2005.

Ratings

Consumer Reports Reliability:

Generally rated as average to above-average for reliability due to Toyota mechanicals, though oil consumption concerns are noted for certain engine variants.
