Model Variant:
XVS65 Custom, Midnight Custom
Model Years Covered:
2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016
Internal Code:
LIT-11616-CU-66
Target Audience:
Do-it-yourself mechanics and V-Star 650 owners.
Value Proposition:
Saves on dealer labor costs, empowers owners for self-maintenance and repair.
Alternative Resources:
Dealer service departments (high cost), generic online forums (variable quality).
Convenience:
Instant download, no waiting, accessible digital format.
Utility:
Enables efficient troubleshooting, maintenance, and repair for all covered models.
Engine Top End:
Detailed coverage of cylinder heads, valves, camshafts, and associated components.
Engine Lubrication System:
Includes oil pump, oil filter, oil passages, and lubrication theory.
Crankshaft Crankcase:
Covers crankshaft, connecting rods, pistons, rings, and crankcase disassembly/assembly.
Transmission:
Detailed information on gearbox operation, maintenance, and repair.
Wheels Tires:
Covers wheel bearings, tire replacement, balancing, and spoke maintenance.
Final Drive:
Information on shaft drive maintenance, including universal joints and final gearcase.
Brakes:
Includes front and rear brake system servicing, fluid changes, caliper and master cylinder overhaul.
Suspension:
Covers front fork (telescopic) and rear shock absorber maintenance and adjustment.
Steering:
Detailed procedures for steering head bearing service and adjustment.
Frame:
Covers frame components, mounting points, and related hardware.
Electrical System:
Comprehensive coverage including wiring diagrams, lighting, ignition, charging system, and starter motor.
General Information:
Vehicle identification, safety precautions, and basic service guidelines.
Periodic Maintenance:
Scheduled maintenance tasks, fluid checks, lubrication, and adjustments.
Fuel System:
Carburetor overhaul, adjustment, fuel filter replacement, and fuel line servicing.
Engine Removal Installation:
Step-by-step instructions for removing and reinstalling the engine.
Diagnostics:
Troubleshooting guides and diagnostic procedures for common issues.
Repair Procedures:
Detailed instructions for overhauling and repairing all major vehicle systems.
Depth Of Coverage:
From basic maintenance to complete engine and transmission rebuilds.
Visual Aids:
Detailed diagrams, illustrations, photographs, and exploded views.
Instruction Style:
Step-by-step instructions for clarity and ease of use.
PDF Quality:
High Resolution
Searchability:
Keyword Searchable
Navigation:
Clickable Menu, Bookmarks
Printability:
Fully Printable (individual pages, chapters, or entire manual)
Suggested Binding:
3-Ring Binder (user configurable)
Digital Paper Type:
Digital (PDF), allows for reprinting of soiled pages.
Engine Type:
Air-cooled, 4-stroke, SOHC, V-twin
Displacement:
649 cc (39.6 cubic inches)
Bore X Stroke:
76.0 mm x 71.0 mm
Horsepower:
Approx. 41.4 HP @ 6,000 RPM (OEM specification, may vary slightly by year/tune)
Torque:
Approx. 37.7 lb-ft @ 3,500 RPM (OEM specification, may vary slightly by year/tune)
Carburetion:
Dual Mikuni BSR34 carburetors
Fuel Tank Capacity:
4.2 US gal (16 L)
Ignition System:
TCI (Transistor Controlled Ignition)
Overall Length:
Approx. 92.7 inches (2355 mm)
Overall Width:
Approx. 34.5 inches (875 mm)
Overall Height:
Approx. 47.0 inches (1195 mm)
Seat Height:
Approx. 27.1 inches (690 mm)
Dry Weight:
Approx. 428 lbs (194 kg)
Wet Weight:
Approx. 474 lbs (215 kg)
Wheelbase:
Approx. 61.3 inches (1555 mm)
Crash Test Ratings:
N/A (Motorcycle specific safety is typically assessed via component integrity and rider protection)
Braking System:
Disc brakes front and rear, with potential for ABS on select later models or specific regional variants (manual covers standard braking).
Lighting:
Halogen headlight, LED tail light, standard turn signals.
Oil Change Interval:
Typically every 3,000 miles or 6 months, refer to manual for exact specification.
Air Filter Inspection:
Recommended every 3,000 miles or annually.
Spark Plug Replacement:
Typically every 6,000-10,000 miles, depending on plug type. Manual will specify.
Brake Fluid Flush:
Recommended every 2 years or per manual specification.
Engine Oil Type:
Yamalube 4 (or equivalent) SAE 20W-40 API SG or higher. Manual will confirm specific API rating and viscosity for temperature.
Engine Oil Capacity:
Approx. 3.3 US qt (3.1 L) without filter change, 3.5 US qt (3.3 L) with filter change. Manual for precise quantity.
Brake Fluid Type:
DOT 4 hydraulic brake fluid.
Final Drive Oil Type:
Yamalube Gear Oil (or equivalent) SAE 80 hypoid gear oil.
Final Drive Oil Capacity:
Approx. 0.25 US qt (0.24 L). Manual for precise quantity.
Common Wear Items:
Clutch wear, brake pads, tires, steering head bearings, fork seals.
Carburetor Tuning:
Carburetors may require periodic adjustment or cleaning due to fuel quality and usage patterns. Manual provides detailed tuning procedures.
Charging System:
While generally reliable, components like the stator or voltage regulator can fail over time, affecting battery charging. The manual details testing and replacement.
Yamaha Motorcycle History:
Yamaha has a long-standing reputation for producing reliable and performance-oriented motorcycles across various categories, including cruisers.
V Star 650 Lineage:
The V-Star 650 Custom is part of Yamaha's popular V-Star cruiser line, known for its classic styling and accessible V-twin engine.
Manufacturing Location:
Japan (primary manufacturing)
