Kawasaki Vulcan 900 Classic Custom Complete Workshop Service Repair Manual 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

20 people are viewing this right now

类型: Motorcycle

斯库: 99528

标签: 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 Kawasaki Misc Motorcycle Motorcycles Vulcan 900 Classic Vulcan 900 Custom

产品多属性

Description

The Vulcan 900 Classic and Custom models represent a significant offering in the cruiser motorcycle segment, renowned for their blend of classic V-twin aesthetics and dependable engineering. Produced between 2006 and 2015, these motorcycles cater to riders seeking an authentic cruiser experience, characterized by user-friendly ergonomics and a robust 903cc V-twin engine. The Vulcan 900 series has earned a reputation for reliability and enjoyable performance, making it a popular choice for both seasoned riders and those new to the cruiser lifestyle, consistently praised for its value and classic styling. This comprehensive workshop service and repair manual provides detailed guidance for the Vulcan 900 Classic and Custom models from 2006 through 2015. It covers all essential aspects of maintenance, repair, and troubleshooting, including in-depth procedures for the engine, fuel system, ignition, transmission, drivetrain, brakes, suspension, and electrical systems. With step-by-step instructions, torque specifications, wiring diagrams, and diagnostic procedures, this manual is an indispensable resource for owners, mechanics, and technicians to ensure the optimal performance and longevity of their vehicle.

🏷️ Basic Information

Identification

Make:

Kawasaki

Model:

Vulcan 900 Classic/Custom

Product Type:

Workshop Service Repair Manual

👋 Introduction

Market Position

Segment:

Cruiser motorcycle, targeting riders seeking classic styling with modern reliability and performance.

Competitive Analysis

Competitors:

Honda Shadow, Yamaha V-Star, Suzuki Boulevard.

Key Features

Design Philosophy:

Combines classic V-twin cruiser aesthetics with user-friendly ergonomics and proven Kawasaki engineering.

Manual Value Proposition:

Provides owners and technicians with the authoritative knowledge to maintain, repair, and optimize their Vulcan 900 Classic or Custom model.

📋 Manual Details

Coverage Areas

Applicable Years:

2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015

Variant Coverage:

Classic, Custom

Page Count

Estimated Pages:

High (Detailed workshop manuals typically exceed 300 pages)

Manual Type

Type:

Complete Workshop Service and Repair Manual

Language

Language:

English

Format

Format:

Downloadable Digital File (Likely PDF)

📖 Manual Coverage

Systems Covered

Engine:

Internal combustion engine (ICE) - 903cc V-twin, disassembly, assembly, inspection, and repair procedures.

Fuel System:

Fuel injection system (EFI), fuel pump, injectors, throttle body, fuel lines, fuel tank servicing.

Ignition System:

Ignition coils, spark plugs, ECU control, timing specifications.

Transmission:

5-speed gearbox, clutch operation, lubrication, disassembly, and reassembly.

Drivetrain:

Belt drive system, final drive belt tensioning and inspection, rear wheel alignment.

Brakes:

Front and rear hydraulic brake systems, caliper maintenance, rotor inspection, brake fluid bleeding procedures.

Suspension:

Front telescopic forks, rear swingarm and shock absorbers, fork oil replacement, seal replacement, shock absorber adjustments.

Electrical System:

Wiring diagrams, battery maintenance, charging system (stator, regulator/rectifier), lighting, starter motor, horn, instrumentation.

Cooling System:

Air-cooled engine, no specific coolant system to detail, but any related heat management aspects.

Frame And Bodywork:

Chassis inspection, frame integrity, body panel removal and installation, seat, fenders, fuel tank mounting.

Wheels And Tires:

Wheel bearing inspection and replacement, tire pressure, tire wear inspection, wheel removal and installation.

Procedures Included

Maintenance:

Routine inspections, oil changes, filter replacements, lubrication points, chain/belt adjustment and cleaning.

Troubleshooting:

Diagnostic procedures for common performance issues, starting problems, electrical faults, and mechanical noises.

Repair:

Step-by-step instructions for component removal, repair, reassembly, and adjustment of all major systems.

Disassembly And Assembly:

Detailed guides for taking apart and putting back together various motorcycle components and sub-assemblies.

Torque Specifications:

Essential torque values for critical fasteners throughout the motorcycle.

Wiring Diagrams:

Comprehensive electrical schematics for diagnosing and repairing electrical issues.

Special Tools:

Identification of any specialized tools required for specific procedures.

Technical Depth

Depth:

Comprehensive, suitable for both DIY mechanics and professional technicians. Covers everything from basic maintenance to complete engine rebuilds and electrical system diagnostics.

📊 Manual Specifications

File Format

File Type:

Searchable Text:

Likely present in a professionally produced PDF, allowing for quick keyword searches.

Print Quality

Resolution:

High resolution for clear diagrams and text.

Binding Type

Binding:

N/A (Digital Format)

Paper Type

Paper Quality:

N/A (Digital Format)

⚙️ Engine Specifications

Primary Engine

Engine Type:

Four-stroke, V-twin, SOHC, 4 valves per cylinder

Displacement:

903 cc (55.1 cu in)

Bore X Stroke:

88.0 x 74.2 mm

Cooling Method:

Air-cooled

Performance

Horsepower:

Approx. 49 HP @ 5700 RPM (Varies slightly by model year/region)

Torque:

Approx. 53 lb-ft @ 3700 RPM (Varies slightly by model year/region)

Fuel System

Fuel Delivery:

Fuel Injection (EFI), Digital Fuel Injection with dual 34mm throttle bodies

Fuel Type:

Unleaded gasoline

Fuel Capacity:

20 Liters (5.3 US gal)

Ignition System

Ignition:

TCBI (Transistor Controlled Ignition) with electronic advance

Engine Oil

Oil Type:

API SG, SH, SJ, SL, or SM, SAE 10W-40 recommended (check manual for precise specs)

Oil Capacity:

Approx. 3.0 Liters (3.2 US qt) with filter change

🔧 Transmission

Standard

Type:

5-speed constant mesh

Clutch:

Wet, multi-disc

Features

Final Drive:

Belt drive, 2.591 (78/30)

Transmission Oil

Oil Type:

API GL-4, SAE 80W-90 Hypoid Gear Oil (check manual for precise specs)

Oil Capacity:

Approx. 0.8 Liters (0.85 US qt)

📐 Dimensions

Exterior

Overall Length:

Approx. 2405 mm (94.7 in)

Overall Width:

Approx. 925 mm (36.4 in)

Overall Height:

Approx. 1130 mm (44.5 in)

Wheelbase:

Approx. 1635 mm (64.4 in)

Weights

Curb Weight:

Approx. 263 kg (580 lbs)

Front Tire:

100/90-19 M/C 57S

Rear Tire:

180/70-15 M/C 76S

Ground Clearance:

Approx. 140 mm (5.5 in)

Seat Height:

Approx. 705 mm (27.8 in)

🛡️ Safety Features

Ratings

Safety Features:

Standard braking systems. ABS was an option on later models or specific trims, but not universally standard across all 2006-2015 models.

Active Features

Braking System:

Hydraulic disc brakes (front and rear). ABS availability should be confirmed for specific sub-models.

Passive Features

Lighting:

Halogen headlamp, LED taillight, standard turn signals.

💡 Technology Features

Infotainment

Instrumentation:

Analog speedometer with integrated digital display for odometer, trip meter, clock, and fuel gauge (may vary by trim). Classic styling with modern functionality.

Driver Assistance

Anti-lock Braking System (ABS) available as an option on some models and later years. Manual will cover its diagnostics if equipped.

Connectivity

Diagnostic Ports:

On-board diagnostics (OBD) or proprietary diagnostic connectors for electronic system checks, covered in the manual.

🔧 Maintenance

Service Intervals

First Service:

Typically around 600 miles (1000 km) for initial break-in service, including oil change, filter check, and general inspection.

Regular Oil Change:

Every 3,700 miles (6,000 km) or 6 months, whichever comes first (refer to manual for exact interval).

Air Filter Cleaning:

Inspect every 3,700 miles (6,000 km), clean or replace as needed.

Belt Inspection:

Inspect belt tension and condition every 3,700 miles (6,000 km).

Spark Plug Replacement:

Replace every 7,500 miles (12,000 km) or as needed.

Fluid Specifications

Brake Fluid:

DOT 4 recommended (check manual for exact specification).

Known Issues

Common Wear Items:

Clutch wear, drive belt wear, front fork seals (typical for many motorcycles), brake pad wear.

Efi Considerations:

While generally reliable, EFI systems can sometimes benefit from throttle body cleaning and sensor checks if performance degrades.

📚 Vehicle History

Brand Heritage

Kawasaki Legacy:

Kawasaki Heavy Industries has a long-standing reputation for engineering excellence in motorcycles, from sportbikes to cruisers.

Model Evolution

Vulcan Lineage:

The Vulcan 900 series is an evolution of Kawasaki's cruiser platform, building on the success of earlier Vulcan models, offering a blend of classic styling and modern amenities.

Production

Production Span Covered:

2006-2015, indicating this manual covers a significant and relatively stable period of the model's life.

🏆 Awards & Recognition

Recognitions

Market Reception:

Consistently well-received by riders for its value, reliability, and authentic cruiser experience.
