🏷️ Basic Information

Make:

Acura

Model:

CSX

Model Years Covered:

2006, 2007, 2008, 2009

Chassis Code:

ES (based on Honda Civic ES)

Engine Code General:

K20 (specifically K20Z3 for Type-S)

👋 Introduction

Target Audience:

Acura CSX owners, DIY enthusiasts, professional automotive technicians seeking comprehensive repair and maintenance information.

Value Proposition:

Provides factory-level diagnostic and repair data at a fraction of the cost of professional labor, enabling significant cost savings for vehicle upkeep.

Content Detail:

Features hundreds of detailed illustrations, diagrams, wiring schematics, and step-by-step instructions for a thorough understanding of repair procedures.

Completeness Assurance:

Guaranteed 100% complete and intact, with no missing or corrupt pages/sections.

📋 Manual Details

Overall Scope:

Complete service, repair, maintenance, and rebuilding for all Acura CSX models 2006-2009, including all engines and trim levels.

Total Pages:

2893

Type:

Factory Service Manual / Workshop Manual

Language:

English

File Format:

PDF

📖 Manual Coverage

Powertrain:

Engine overhaul and rebuilding, timing belt replacement, engine performance diagnostics, firing orders, serpentine belt routings, transmission removal/installation, in-car transmission servicing.

Brakes And Suspension:

Brake servicing procedures, front-end alignment procedures and specifications, suspension system servicing.

Electrical And Body:

Wiring diagrams, diagnostic trouble codes, computer diagnostic trouble tree charts, sunroof service, A/C service and capacities, vacuum diagrams.

Diagnostic Repair:

All diagnostic and repair procedures, troubleshooting, computer diagnostics, specific repair procedures.

Maintenance And Specifications:

Factory maintenance schedules and charts, complete torque specifications, detailed specifications on every model covered, driving concerns.

Diagnostic Level:

Advanced diagnostics including computer diagnostic codes and trouble trees, intended for both DIY and professional mechanics.

Repair Scope:

Covers complete disassembly of the vehicle for rebuild, refurbishment, and restoration purposes.

📊 Manual Specifications

Compatibility:

Compatible with all versions of Windows, Mac, Linux OS, iPhone, iPad, Android devices via Adobe PDF Reader.

Readability:

Searchable and bookmarked for easy navigation, zoomable for detail, printable.

Digital Format:

Instant Digital Download (PDF)

Physical Format:

Not applicable (Digital Download)

⚙️ Engine Specifications

Engine Type Base:

Naturally Aspirated Inline-4

Engine Code Specific:

K20Z3 (for Type-S)

Displacement Liters:

2.0

Horsepower Typical:

155 hp @ 6000 rpm (standard), 197 hp @ 7800 rpm (Type-S)

Torque Typical:

130 lb-ft @ 4500 rpm (standard), 141 lb-ft @ 6000 rpm (Type-S)

Injection Type:

Programmed Fuel Injection (PGM-FI)

Fuel Type:

Unleaded gasoline

🔧 Transmission

Transmission Type Standard:

5-Speed Manual

Transmission Type Optional:

5-Speed Automatic (with Sequential SportShift)

Clutch Type:

Hydraulically Actuated Diaphragm Spring

📐 Dimensions

Length Inches:

177.3

Width Inches:

69.0

Height Inches:

56.7

Curb Weight Lbs Approx:

2800 - 3000

Gross Vehicle Weight Rating Lbs Approx:

3900

🛡️ Safety Features

NHTSA Front Crash Rating:

5-Star (for driver and front passenger)

IIHS Side Crash Rating:

Good

ABS:

Standard Anti-lock Braking System (ABS)

Traction Control:

Standard Traction Control System (TCS)

Airbags Front:

Dual-Stage, Multiple-Threshold front airbags

Airbags Side:

Front side airbags with Occupant Position Detection System (OPDS)

Side Curtain Airbags:

Available side curtain airbags

💡 Technology Features

Audio System:

Standard AM/FM/CD audio system with optional premium sound, MP3 compatibility, and auxiliary input jack.

Navigation:

Optional factory-installed DVD-based navigation system.

Cruise Control:

Standard electronic cruise control.

Bluetooth:

Optional HandsFreeLink Bluetooth phone system.

🔧 Maintenance

Oil Change Interval Recommendation:

Every 7,500 miles or 6 months, or as indicated by the Maintenance Minder System.

Timing Belt Replacement Interval:

N/A (CSX features a maintenance-free timing chain)

Engine Oil Type:

0W-20 synthetic (API Certified)

Coolant Type:

Honda Type 2 Coolant (or equivalent blue long-life coolant)

Transmission Fluid Manual:

Honda MTF (Manual Transmission Fluid)

Transmission Fluid Automatic:

Honda ATF-DW1 (or equivalent)

Common Wear Item:

Clutch wear (especially in manual transmission models), front suspension components (bushings, ball joints) due to road conditions.

Electrical Concern:

Occasional issues with power window regulators or infotainment system glitches.

Engine Performance Concern:

Minor oil consumption can be noted in some higher mileage K-series engines.

📚 Vehicle History

Parent Company:

Honda Motor Company

Platform Sharing:

Based on the 8th generation Honda Civic platform (specifically the European/Japanese Civic type, designated ES).

Market Introduction North America:

2006

Manufacturing Location:

Alliston, Ontario, Canada

Production Years:

2006 - 2011 (though manual covers 2006-2009)

🏆 Awards & Recognition

IIHS Award:

Insurance Institute for Highway Safety (IIHS) 'Top Safety Pick' for 2006 and 2007 models.

Car And Driver Ranking:

Frequently featured in Car and Driver's '10Best' lists for affordable sports sedans during its production run.
