Segment:
Compact family car (C-segment).
Design Philosophy:
Focus on comfort, practicality, and Peugeot's signature styling.
Key Competitors:
Volkswagen Golf, Ford Focus, Opel Astra, Renault Mégane, Fiat Bravo.
Manual Value Proposition:
Empowers owners to perform their own maintenance and repairs, saving significant costs.
Manual Usability:
Step-by-step instructions with clear pictures make complex tasks accessible.
Year Coverage:
2007, 2008, 2009, 2010, 2011, 2012, 2013
Engine Coverage:
All Petrol and Diesel Engine Variants
Trim Coverage:
All Trim Levels
Transmission Coverage:
All Transmission Types (Manual & Automatic)
Estimated Page Count:
Extensive (specific count not provided, but implies comprehensive coverage)
Type:
Workshop Service Repair Manual
Delivery Format:
Downloadable Digital File
File Type:
PDF (Adobe Reader compatible)
Engine Mechanical:
Engine disassembly, assembly, overhaul, timing systems, lubrication, cooling, fuel, exhaust, emission control.
Engine Management:
Ignition system, fuel injection, electronic engine control units (ECU), sensors, actuators, diagnostic trouble codes (DTCs).
Transmission Manual:
Clutch, gearbox disassembly/assembly, shifting mechanisms, maintenance.
Transmission Automatic:
Automatic transmission operation, hydraulic control, torque converter, valve body, servicing, repair.
Drivetrain:
Front-wheel drive, driveshafts, CV joints, differential.
Suspension:
Front and rear suspension components, shock absorbers, springs, control arms, steering knuckle, alignment procedures.
Steering:
Power steering system (hydraulic or electric), steering rack, steering column, tie rod ends.
Brakes:
Brake system components (discs, pads, calipers, lines), ABS, EBD, brake fluid specifications, bleeding procedures.
Electrical System:
Battery, charging system (alternator, starter), lighting system, wiring diagrams, fuses, relays.
Body And Chassis:
Body panel removal/installation, interior trim, exterior trim, chassis components, welding, structural repairs.
HVAC:
Heating, ventilation, and air conditioning (HVAC) system, refrigerant, compressor, condenser, evaporator, climate control.
Body Electronics:
Power windows, power locks, central locking, remote keyless entry, comfort features.
Safety Systems:
Airbag system, seatbelt pre-tensioners, SRS (Supplemental Restraint System) diagnostics.
Maintenance:
Routine servicing, oil changes, filter replacements, spark plugs, fluid checks and top-ups.
Troubleshooting:
Diagnostic procedures for common problems, symptom-based troubleshooting guides.
Repair:
Step-by-step instructions for component removal, repair, and reinstallation.
Diagnostics:
Detailed diagnostic procedures, including the use of diagnostic tools and interpretation of scan data.
Technical Specifications:
Torque values, clearances, adjustments, fluid capacities, electrical specifications.
Wiring Diagrams:
Comprehensive electrical wiring diagrams for all systems.
Rebuilding:
Engine and transmission rebuilding procedures.
Depth:
Comprehensive (covers everything from basic maintenance to full engine and transmission rebuilds).
Engine Families Covered:
EP series (petrol), DV/DW/DT series (diesel).
Petrol Engine Examples:
1.4 VTi (EP3), 1.6 VTi (EP6), 1.6 THP (EP6DT/DTS).
Diesel Engine Examples:
1.6 HDi (DV6), 2.0 HDi (DW10), 1.4 HDi (DV4).
Typical Petrol Power Range:
95 PS (70 kW) to 175 PS (129 kW).
Typical Diesel Power Range:
70 PS (51 kW) to 136 PS (100 kW).
Petrol Injection:
Multi-point Fuel Injection (MPI) or Direct Injection (GDI).
Diesel Injection:
Common Rail Direct Injection (CRDi).
ECU Examples:
Bosch Motronic, Siemens VDO.
Timing Drive:
Timing belt (VTi, HDi) or timing chain (THP).
Standard Transmission:
5-speed or 6-speed Manual Transmission (e.g., BE series).
Optional Transmission:
4-speed or 6-speed Automatic Transmission (e.g., AL4, AT6).
Transmission Control:
Electronic control for automatic transmissions, clutch actuation for manuals.
Manual Transmission Fluid:
API GL-4 or GL-5, SAE 75W-80 (specifics vary by gearbox model).
Automatic Transmission Fluid:
ATF LT 71141 or equivalent (e.g., for AL4).
Body Styles:
Hatchback (3-door and 5-door), Estate (SW).
Length Approx:
4276 mm (Hatchback), 4500 mm (Estate).
Height Approx:
1496 mm (Hatchback), 1525 mm (Estate).
Boot Capacity Min Approx:
347 litres (Hatchback), 470 litres (Estate).
Kerb Weight Range Approx:
1300 kg - 1500 kg (depending on engine and specification).
Infotainment System:
Integrated CD/MP3 player, optional navigation system (e.g., WIP Nav), USB connectivity, Bluetooth.
Driver Assistance Features:
Cruise control, speed limiter, parking sensors (rear, sometimes front).
Connectivity Options:
Bluetooth hands-free calling and audio streaming, aux-in port, USB port (depending on trim and options).
Oil Change Interval:
Typically 15,000 miles (24,000 km) or 12 months, whichever comes first (may vary by engine and oil specification).
Timing Belt Replacement:
Recommended replacement every 60,000-120,000 miles (96,000-192,000 km) or 4-5 years (highly dependent on specific engine, check manual for exact interval).
Air Filter Replacement:
Recommended every 15,000-30,000 miles (24,000-48,000 km).
Engine Oil Type:
Fully synthetic, e.g., TOTAL QUARTZ INEO ECS 5W-30 (meeting PSA B71 2290 standard is common for diesel).
Coolant Type:
Long-life antifreeze coolant (e.g., PSA Grade 017).
Brake Fluid Type:
DOT 4 or DOT 5.1.
Common Faults Petrol:
Ignition coil failures (especially on THP engines), timing chain issues (THP), thermostat housing leaks.
Common Faults Diesel:
DPF (Diesel Particulate Filter) clogging, EGR valve issues, swirl flap problems (older HDi), injector sealing.
General Issues:
Water pump leaks, suspension component wear, electrical gremlins.
