The Mazda CX-9, produced for the 2007 and 2008 model years, is a mid-size crossover SUV known for its stylish design, engaging driving dynamics, and practical three-row seating. Built upon Mazda's Jinba-Ittai philosophy, this vehicle emphasizes a connection between the driver and the road, offering a responsive experience for its class. The Grand Touring trim, powered by a 3.5-liter V6 engine, delivers robust performance, complemented by available all-wheel drive for enhanced capability. Its commitment to safety is underscored by a 5-star NHTSA front impact rating and recognition as an IIHS Top Safety Pick, making it a well-rounded choice for families.
This comprehensive Workshop Repair Service Manual provides in-depth guidance for the maintenance, troubleshooting, and repair of the Mazda CX-9, covering all models, engines, trims, and transmission types from 2007-2008. It details procedures for essential systems including powertrain, chassis, electrical, and comfort systems, offering step-by-step repair instructions, diagnostic methods, and technical specifications with diagrams and illustrations. The manual is designed to assist owners and professional technicians in performing routine service, complex repairs, and preventative maintenance, ensuring the longevity and optimal performance of the vehicle.
Model Years Covered:
2007, 2008
First Generation Code:
TB
Vehicle Segment:
Mid-size Crossover SUV
Key Competitors 2007 2008:
Toyota Highlander, Honda Pilot, Ford Explorer, Chevrolet Traverse (later models), Buick Enclave
Distinguishing Features Of Cx9:
Stylish design, engaging driving dynamics (for an SUV), available all-wheel drive, three-row seating.
Cost Savings Potential:
Enables DIY repairs, potentially saving hundreds to thousands of dollars in labor costs.
Overall Scope:
Comprehensive service, maintenance, and troubleshooting for all models, engines, trims, and transmission types.
Estimated Page Count:
Hundreds of pages (specific count not provided, but described as 'hundreds of pages of diagrams and detailed information')
Type:
Workshop Repair Service Manual
Powertrain:
Engine Service/Repair, Transmission Service/Repair, Differential/Drive, Axle, Cooling System, Fuel Injection/Fuel System, Emission System, Engine Control System
Chassis And Suspension:
Brake System, Suspension, Steering, Chassis/Body
Electrical And Electronics:
Wiring Diagram, Electrical System, Engine Control System
Comfort And Convenience:
Heater/Air Conditioning, Interior
Safety And Restraint:
Restraint System
Maintenance:
General Maintenance, Periodic Lubrication, Routine Service
Repair And Diagnostics:
Troubleshooting, Diagnostic Procedures, Repair Procedures (step-by-step), Disassembly, Assembly, Reinstallation
Technical Data:
Specifications, Diagrams, Illustrations, Photos, Wiring Diagrams, Technical Bulletins
Depth:
Professional-level, mirroring dealership service departments. Includes detailed substeps, notes, cautions, and warnings.
Printability:
Full Printable
Zoom Functionality:
Zoom IN/OUT enabled
Delivery:
Instant Download
Reader Requirement:
Adobe PDF Reader
Utility Requirement:
WinZip (for potential archive extraction)
Operating Systems:
All Versions of Windows & Mac
Engine Code And Type:
6G75 (MIVEC V6, 24-Valve SOHC)
Displacement:
3.5 Liters (3496 cc)
Horsepower Rating:
263 hp @ 6250 rpm (approximate)
Torque Rating:
246 lb-ft @ 4500 rpm (approximate)
Injection System:
Electronic Fuel Injection (EFI)
Engine Control Module:
ECU/ECM (covered in Engine Control System section)
Transmission Type:
6-Speed Automatic
Drive Configuration:
Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) available
Transmission Control:
Electronically controlled, with manual mode option (Sport Shift).
Length:
Approx. 192.7 inches
Width:
Approx. 75.4 inches
Height:
Approx. 68.1 inches
Wheelbase Measurement:
Approx. 113.2 inches
Curb Weight:
Approx. 4,475 - 4,674 lbs (depending on FWD/AWD)
Towing Capacity:
Up to 5,000 lbs (when properly equipped with towing package)
NHTSA Front Impact Rating:
5-Star (for driver and front passenger)
IIHS Top Safety Pick:
Yes (for 2007-2008 models)
Brake System Type:
4-Wheel Disc Brakes with ABS, Electronic Brakeforce Distribution (EBD), Brake Assist (BA)
Stability Control:
Dynamic Stability Control (DSC) and Traction Control System (TCS)
Airbags:
Front dual-stage airbags, front side-impact airbags, three-row side-curtain airbags with rollover protection.
Audio System:
Bose premium audio system with subwoofer available on Grand Touring trims, SiriusXM satellite radio capability.
Navigation:
Optional touchscreen navigation system available.
Parking Assistance:
Rear parking sensors available.
Climate Control:
Automatic climate control, dual-zone front and rear controls.
Keyless Entry And Start:
Keyless entry system with push-button start (Smart Key).
Oil Change Interval:
Typically every 5,000 miles or 6 months, or as indicated by the Maintenance Monitor System.
Air Filter Replacement:
Refer to manual for mileage or condition-based recommendation (e.g., every 30,000 miles).
Spark Plug Replacement:
Typically around 75,000 miles for iridium spark plugs (refer to specific plug type).
Engine Oil Type And Capacity:
SAE 5W-20 API Service SM or ILSAC GF-4 certified. Capacity approx. 5.5 quarts with filter.
Transmission Fluid Type:
Mazda ATF FZ or equivalent (specific DEXRON/MERCON compatibility may vary, consult manual for exact spec).
Coolant Type:
Mazda Genuine Long Life Coolant (Green) or equivalent Asian vehicle coolant (50/50 mix with distilled water).
Brake Fluid Type:
DOT 3 or DOT 4 brake fluid.
Common Repair Items First Gen:
Worn sway bar links/bushings, potential carbon buildup in intake valves, transmission shift issues (less common in these years but possible), AC condenser leaks.
Mazda Philosophy:
Jinba-Ittai ('Horse and Rider as One') driving philosophy emphasizing connection and responsiveness.
First Generation Launch:
Introduced for the 2007 model year.
Design Inspiration:
Based on Mazda's 'Nagare' design language, featuring flowing lines.
Manufacturing Location:
Hofu, Yamaguchi, Japan
IIHS Award:
Insurance Institute for Highway Safety (IIHS) Top Safety Pick for 2007 and 2008.
Family Car Recognition:
Often cited as a good choice for families due to its safety and practicality.
