Ford Mustang Shelby GT500 2007-2009 Workshop Service Repair Manual

$17.99
$17.99
🏷️ Basic Information Identification Make: Ford Model: Mustang Shelby GT500 Years Covered: 2007, 2008, 2009 Codes Platform Code: S197 (second generation) Chassis Code: Mustang / Shelby GT500 👋 Introduction Market...
21 people are viewing this right now
类型: Car
厂商:
Ford
斯库: 436155
标签: 2007 2008 2009 Car Cars Featured Ford Mustang Mustang Shelby GT500
Ford Mustang Shelby GT500 2007-2009 Workshop Service Repair Manual
🏷️ Basic Information
Identification
Make:
Ford
Model:
Mustang Shelby GT500
Years Covered:
2007, 2008, 2009
Codes
Platform Code:
S197 (second generation)
Chassis Code:
Mustang / Shelby GT500
👋 Introduction
Market Position
Positioning:
High-performance muscle car variant of the Ford Mustang
Competitive Analysis
Key Competitors:
Chevrolet Camaro SS, Dodge Challenger SRT8
Key Features
Vehicle Focus:
Performance, V8 engine, track-inspired capabilities
Manual Value Proposition:
Authoritative source for maintenance, repair, and diagnostics, saving on professional labor costs
📋 Manual Details
Coverage Areas
Primary Coverage:
Complete factory service and repair
Additional Coverage:
General maintenance, troubleshooting, electrical systems, wiring diagrams
Page Count
Estimated Page Count:
Hundreds of pages (exact count not specified, but implies comprehensive coverage)
Manual Type
Type:
Workshop Service Repair Manual (FSM)
Language
Language:
English
Format
Format:
PDF Download
📖 Manual Coverage
Systems Covered
Powertrain:
Engine Service/Repair, Transmission Service/Repair, Fuel Injection, Fuel System, Emission System, Engine Control System, Differential/Drive, Axle
Chassis And Suspension:
Suspension, Steering, Brake System
Electrical And Electronics:
Electrical System, Wiring Diagram, Engine Control System
Comfort And Convenience:
Heater/Air Conditioner, Interior
Safety And Restraint:
Restraint System
Body And Frame:
Chassis/Body
Procedures Included
Maintenance:
General Maintenance, Periodic Lubrication
Diagnostics And Repair:
Troubleshooting, Step-by-step repair procedures, diagnostics for electrical systems
Technical Depth
Depth:
Complete disassembly and reassembly guidance, detailed illustrations, photos, and diagrams
Target Audience:
Do-it-yourselfer (DIY) and experienced mechanic
📊 Manual Specifications
File Format
Type:
PDF
Compatibility:
All PC based Windows operating systems and Mac
Print Quality
Printability:
Printable without any restriction (entire manual or specific pages)
Binding Type
Delivery Method:
Instant download after payment
Paper Type
Physical Format Option:
Can be burned to CD-ROM (user responsibility)
Requirements
Software Requirement:
Adobe PDF Reader
⚙️ Engine Specifications
Primary Engine
Engine Code:
4.6L 32-Valve V8 (Coyote variant with Ford Racing enhancements)
Engine Type:
Supercharged V8
Performance
Horsepower:
500 hp @ 6000 rpm (approx.)
Torque:
480 lb-ft @ 4200 rpm (approx.)
Fuel System
Injection Type:
Electronic Fuel Injection (EFI)
Fuel Requirement:
Premium Unleaded Gasoline (91 octane or higher recommended)
🔧 Transmission
Standard
Transmission Type:
Tremec TR-6060 6-speed manual transmission
Optional
Optional Transmission:
N/A for Shelby GT500 during this generation
Features
Clutch Type:
Heavy-duty twin-plate clutch
📐 Dimensions
Exterior
Wheelbase:
107.1 inches
Overall Length:
189.3 inches
Overall Width:
73.9 inches
Overall Height:
55.0 inches
Weights
Curb Weight:
Approx. 3,950 - 4,000 lbs (varies by options)
🛡️ Safety Features
Ratings
NHTSA Front Impact:
4-star (driver), 5-star (passenger)
NHTSA Side Impact:
5-star (all seats)
IIHS Moderate Overlap Front:
Good
Active Features
Braking System:
Front: 14-inch Brembo vented discs with 4-piston calipers; Rear: 11.8-inch vented discs with 1-piston calipers
Stability Control:
Traction Control System (TCS), Electronic Stability Control (ESC) with sport mode
Passive Features
Airbags:
Driver and front passenger airbags, front side-impact airbags
Seatbelts:
3-point active restraints with pretensioners and load limiters
💡 Technology Features
Infotainment
Audio System:
Shaker 500 or Shaker 1000 audio systems with AM/FM, CD player, and auxiliary input.
Navigation:
Optional factory-installed navigation system (may vary by trim).
Driver Assistance
Cruise Control:
Standard electronic cruise control.
Connectivity
Sync:
Ford SYNC voice-activated communications and entertainment system available on some models.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 5,000 to 7,500 miles or 6-12 months (refer to manual for exact specification based on driving conditions)
Engine Coolant Flush:
Every 30,000 miles or 2 years
Transmission Fluid Change:
Every 60,000 miles (manual transmission)
Fluid Specifications
Engine Oil:
SAE 5W-20, meeting Ford WSS-M2C153-H specification (check manual for supercharger oil)
Coolant:
Ford Premium Gold Coolant (or equivalent meeting specification WSS-M97B51-A1)
Brake Fluid:
DOT 3 or DOT 4
Known Issues
Clutch Wear:
Can wear faster with aggressive driving; proper engagement is key.
Supercharger Belt:
Regular inspection and potential replacement due to high-performance operation.
Cooling System:
Ensure proper coolant levels and hose integrity due to the demands of the supercharged engine.
📚 Vehicle History
Brand Heritage
Heritage Connection:
Carrol Shelby's legendary Mustang modifications
Model Evolution
Gt500 Introduction:
Revival of the Shelby GT500 nameplate for the S197 Mustang platform
Key Updates 07-09:
Introduction of the supercharged 5.4L V8, significant chassis and suspension tuning, design enhancements over the standard Mustang GT
Production
Production Start Year:
2007
Production End Year:
2009
Manufacturing Location:
Flat Rock, Michigan, USA
🏆 Awards & Recognition
Recognitions
Automotive Press Awards:
Consistently recognized for its performance and aggressive styling by automotive publications.
Performance Accolades:
Often cited in lists of powerful American muscle cars of its era.
