🏷️ Basic Information

Make:

Jeep

Model:

Compass

Model Years Covered:

2007, 2008, 2009

Platform Code:

MK (Chrysler JS platform derivative)

👋 Introduction

Segment:

Compact SUV

Jeep Brand Alignment:

Entry-level offering within the Jeep lineup, blending SUV styling with a focus on urban maneuverability and affordability compared to traditional Jeep models.

Key Competitors:

Honda CR-V, Toyota RAV4, Ford Escape, Nissan Rogue, Subaru Forester

Design Language:

Distinctive Jeep styling cues adapted for a smaller, more car-like platform.

Drivetrain Options:

Available in Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) configurations.

Target Audience:

Individuals and families seeking a versatile, stylish, and capable compact SUV with the heritage of the Jeep brand.

📋 Manual Details

Primary Coverage:

Full factory service and repair

Secondary Coverage:

Diagnostics, troubleshooting, maintenance, overhaul

Estimated Page Count:

Thousands (comprehensive factory documentation)

Type:

Factory Service Manual / Workshop Manual

Language:

English

Digital Format:

PDF/HTML

📖 Manual Coverage

Powertrain:

Engine Mechanical, Fuel System, Ignition System, Emissions Control, Engine Management, Transmission (Automatic and Manual), Drivetrain (Front-Wheel Drive, All-Wheel Drive)

Chassis:

Suspension (Front and Rear), Steering System, Brake System (Hydraulic, ABS), Wheels and Tires

Body And Electrical:

Body Structure, Exterior Trim, Interior Trim, HVAC System, Restraint Systems (Airbags), Body Electrical Systems (Lighting, Power Accessories), Powertrain Control Module (PCM), Body Control Module (BCM), Diagnostic Trouble Codes (DTCs)

Maintenance:

Oil changes, fluid checks and changes, filter replacements, tire rotation, battery maintenance

Diagnostics And Troubleshooting:

Component testing, symptom-based diagnostics, DTC interpretation, wiring diagrams, diagnostic flowcharts

Repair And Overhaul:

Engine rebuilds, transmission repair/rebuild, suspension component replacement, brake caliper/rotor replacement, electrical component repair, body panel repair

Component Replacement:

Alternator, starter, water pump, fuel pump, injectors, sensors, actuators, CV joints, wheel bearings, shock absorbers, struts

Depth:

Comprehensive, covering from basic routine maintenance to complete component overhauls and specialized diagnostic procedures.

📊 Manual Specifications

Compatibility:

Windows 95/98/ME/XP (with potential tweaks for IE 10-11 as noted by seller)

Printability:

Designed for printing, allowing users to create physical copies of specific sections or the entire manual.

Binding Type:

Digital (PDF/HTML), no physical binding

Paper Type:

N/A (Digital format)

⚙️ Engine Specifications

Engine Code And Type:

2.4L GEMA I4 (World Engine)

Displacement:

2360 cc (2.4 Liters)

Bore X Stroke:

88.0 mm x 97.0 mm

Compression Ratio:

9.5:1

Horsepower:

172 hp @ 6000 rpm (SAE Net)

Torque:

165 lb-ft @ 4400 rpm (SAE Net)

Valvetrain:

DOHC, 16 valves, Variable Valve Timing (VVT)

Block Material:

Aluminum Alloy

Head Material:

Aluminum Alloy

Engine Management:

Chrysler P0507 ECU (Engine Control Unit)

Fuel System:

Multi-port Fuel Injection (MPI)

Engine Code And Type:

2.0L Hurricane I4 (Less common in North America for this generation)

Displacement:

1998 cc (2.0 Liters)

Horsepower:

156 hp @ 6300 rpm

Torque:

141 lb-ft @ 5000 rpm

🔧 Transmission

Transmission Type:

Continuously Variable Transmission (CVT) - Autostick

Cvtfb Fluid Type:

Chrysler/Dodge/Jeep CVT Fluid (NVT 4400)

Transmission Type:

5-Speed Manual Transmission (Getrag Getrag NT5)

Cvt Features:

Simulated gear changes ('Autostick' manual mode), variable ratio for optimal fuel economy and performance.

Manual Features:

Direct clutch engagement, standard gear ratios for manual shifting.

📐 Dimensions

Length:

171.5 inches (4356 mm)

Width:

71.0 inches (1803 mm)

Height:

65.7 inches (1669 mm)

Wheelbase:

103.7 inches (2634 mm)

Ground Clearance:

7.5 inches (190 mm)

Cargo Volume Behind Rear Seat:

23.0 cubic feet (0.65 cubic meters)

Cargo Volume With Rear Seat Folded:

53.6 cubic feet (1.52 cubic meters)

Curb Weight FWD:

Approximately 3320 lbs (1506 kg)

Curb Weight AWD:

Approximately 3450 lbs (1565 kg)

Towing Capacity:

1000 lbs (454 kg) (Unbraked)

🛡️ Safety Features

NHTSA Frontal Driver:

Good

NHTSA Frontal Passenger:

Good

NHTSA Side Driver:

Good

NHTSA Side Rear Passenger:

Good

NHTSA Rollover FWD:

4/5 Star (2WD)

NHTSA Rollover AWD:

4/5 Star (4WD)

Braking System:

Front Ventilated Disc, Rear Solid Disc

ABS:

Standard Anti-lock Braking System (ABS) with Electronic Brake-force Distribution (EBD)

Traction Control:

Standard Traction Control System (TCS)

Stability Control:

Optional Electronic Stability Program (ESP) with Roll Mitigation

Airbags:

Standard front-seat mounted airbags, optional front-seat side curtain airbags.

Seatbelts:

3-point seat belts with pretensioners and load limiters

💡 Technology Features

Audio System:

Optional Boston Acoustics premium audio system available on higher trims.

Connectivity:

Auxiliary audio input jack standard on most models, optional Uconnect hands-free communication system and satellite radio.

Optional Features:

Limited driver assistance features for this era; focus is on basic safety and convenience.

🔧 Maintenance

Oil Change Interval:

Every 3,750 miles or 6 months for severe driving, or 7,500 miles or 12 months for normal driving (refer to manual for specific conditions).

Tire Rotation Interval:

Every 7,500 miles or 6 months

Engine Air Filter Replacement:

Inspect every 7,500 miles, replace as needed or every 15,000-30,000 miles depending on conditions.

Cabin Air Filter Replacement:

Inspect annually, replace as needed or every 15,000-20,000 miles.

Transmission Fluid Change Cvt:

Replace CVT fluid and filter every 60,000 miles (severe duty) or refer to manual for normal duty.

Transmission Fluid Change Manual:

Inspect annually, replace as needed or consult manual for specific mileage recommendations.

Engine Oil Type:

SAE 5W-20, API SN/SM/SL certified

Engine Oil Capacity:

4.5 US quarts (4.3 Liters) with filter change

Coolant Type:

Chrysler OAT (Old Age Technology) Extended Life Antifreeze/Coolant (Red)

Coolant Capacity:

Approximately 7.5 US quarts (7.1 Liters)

Brake Fluid Type:

DOT 3

Common Complaints:

CVT transmission judder or failure, premature suspension component wear (ball joints, control arm bushings), HVAC blower motor issues, potential for ABS sensor faults.

Engine Performance Notes:

The 2.4L GEMA engine generally performs adequately but can be considered less refined than some competitors' offerings. Proper maintenance is key to longevity.

📚 Vehicle History

Jeep Legacy:

The Jeep brand is renowned for its off-road capability and ruggedness, established with the original Willys MB during WWII. The Compass represents an expansion of the brand into more urban-oriented and fuel-efficient segments.

First Generation Launch:

The Jeep Compass was introduced for the 2007 model year, marking Jeep's first venture into the compact crossover SUV segment. It was designed to appeal to a broader audience than traditional Jeep models.

Platform Sharing:

Built on the Chrysler/Dodge JS platform, shared with vehicles like the Dodge Caliber and Patriot, indicating a more car-like construction rather than traditional body-on-frame SUV architecture.

Assembly Location:

Belvidere Assembly Plant, Illinois, USA

🏆 Awards & Recognition

Safety Awards:

Awarded Good ratings in frontal, side, and rear impact tests by the IIHS (Insurance Institute for Highway Safety) for most model years within this range.
