Market Segment:
Naked sport-touring motorcycle with a unique automatic transmission.
Target Audience:
Riders seeking a comfortable, user-friendly, and technologically advanced motorcycle for commuting and touring.
Key Competitors:
Competes with other naked bikes and sport-touring models offering automatic or semi-automatic transmissions, such as certain Honda NC700/750 DCT models, or some Yamaha FJR models with automatic options.
Unique Selling Proposition:
The Aprilia Mana 850 is notable for its seamlessly integrated CVT automatic transmission, allowing riders to choose between fully automatic or sequential manual shifting modes, simplifying riding in urban environments and on tours.
Storage Compartment:
Features a unique 'frunk' (front trunk) storage compartment where a traditional fuel tank would be, enhancing practicality.
Primary Coverage:
Comprehensive service, repair, troubleshooting, and maintenance for Aprilia Mana 850 models.
Specific Systems:
Engine, fuel system, transmission, drivetrain, electrical system, chassis, suspension, brakes, bodywork, diagnostics.
Type:
Factory Service Manual / Workshop Manual
Engine:
Complete teardown and reassembly procedures, valve clearance adjustment, piston and cylinder inspection, lubrication system, cooling system.
Fuel System:
Fuel injection system diagnostics and repair, throttle body service, fuel pump and pressure checks, injector cleaning.
Transmission:
Continuous Variable Transmission (CVT) inspection and service, belt replacement, clutch operation, torque converter.
Drivetrain:
Final drive inspection, chain and sprocket maintenance, rear swingarm service.
Electrical System:
Wiring diagrams, component testing, starter system, charging system, lighting, ignition system, ECU diagnostics.
Chassis Suspension:
Front fork service and adjustments, rear shock absorber replacement and settings, steering head bearing maintenance, wheel bearing service.
Brakes:
Brake system bleeding (front and rear), pad and disc replacement, caliper service, ABS system diagnostics and troubleshooting.
Bodywork:
Fairing removal and installation, seat service, luggage system integration, body panel alignment.
Diagnostics:
Troubleshooting guides for common faults, diagnostic trouble codes (DTCs) and their meanings, ECU flashing procedures.
Maintenance:
Scheduled maintenance tasks, oil changes, filter replacements, chain lubrication, brake fluid changes, coolant flushes.
Repair:
Detailed step-by-step instructions for component repair and replacement across all major vehicle systems.
Troubleshooting:
Flowcharts and diagnostic trees to identify and resolve mechanical and electrical issues.
Engine Rebuild:
Full engine overhaul procedures, including torque specifications for all critical fasteners.
Electrical Diagnostics:
Testing of sensors, actuators, wiring harnesses, and ECU functions using multimeter and diagnostic tools.
Depth:
Comprehensive; covers routine maintenance to complete engine and component overhauls, including advanced diagnostics.
Searchability:
Searchable text for quick information retrieval.
Print Quality:
High-resolution, suitable for printing individual pages or sections.
Binding:
Not applicable (Digital Format)
Paper Quality:
Not applicable (Digital Format)
Engine Type:
V-twin, four-stroke, liquid-cooled, DOHC, 8 valves
Bore X Stroke:
90 mm x 66 mm
Compression Ratio:
10.1:1
Fuel Delivery:
Electronic fuel injection with ride-by-wire throttle control
Claimed Horsepower:
75 hp (55 kW) @ 7,000 rpm
Claimed Torque:
81 Nm (60 lb-ft) @ 6,000 rpm
Fuel Type:
Unleaded gasoline
Fuel Tank Capacity:
18.0 liters (4.75 US gal)
Oil Capacity:
Approximately 2.5 liters with filter change (refer to manual for exact spec)
Coolant Type:
Ethylene glycol-based coolant with anti-corrosion additives (refer to manual for specific Aprilia recommendation)
Transmission Type:
Sequential Sport Transmission (SST) - CVT with selectable modes (automatic and manual override)
Shifting Modes:
Three distinct modes: Automatic 3-speed, Automatic 5-speed, and Manual (5-speed sequential via handlebar controls).
Clutch Type:
Wet multi-plate, hydraulic control
Transmission Fluid Type:
Specific CVT fluid or engine oil as per Aprilia specification (consult manual for exact type and API rating)
Final Drive Type:
O-ring sealed chain
Chain Type:
525 pitch O-ring sealed chain
Length:
Approximately 2,170 mm (85.4 in)
Width:
Approximately 830 mm (32.7 in)
Height:
Approximately 1,270 mm (50.0 in)
Wheelbase:
Approximately 1,515 mm (59.6 in)
Dry Weight:
Approximately 215 kg (474 lbs)
Wet Weight:
Approximately 230 kg (507 lbs) (with fluids)
Max Payload:
Refer to specific model year documentation or manual.
Storage Capacity:
Integrated front storage compartment (approx. 15 liters) with 12V power outlet.
ABS Availability:
Optional (ABS model)
Braking System:
Dual front disc brakes, single rear disc brake. ABS available on specific models.
Lighting:
Halogen headlights, LED tail light.
Frame Type:
Aluminum alloy trestle frame with steel subframe.
Crash Protection:
Frame structure, rider protection via rider triangle.
Dashboard:
Digital instrument cluster displaying speed, RPM, gear indicator, fuel level, clock, trip meter, and warning lights.
ABS:
Available on GT ABS models, providing enhanced braking safety.
Power Outlet:
12V auxiliary power outlet in the front storage compartment.
Throttle Control:
Ride-by-wire electronic throttle system for precise control and integration with the CVT.
Oil Change Interval:
Recommended every 6,000 km (3,700 miles) or 12 months (refer to manual for specific conditions).
Valve Clearance Check:
Recommended every 12,000 km (7,500 miles).
Spark Plug Replacement:
Recommended every 12,000 km (7,500 miles).
Air Filter Cleaning Replacement:
Inspect every 6,000 km (3,700 miles), clean or replace as needed.
Coolant Change:
Recommended every 24,000 km (15,000 miles) or 24 months.
Engine Oil Grade:
SAE 10W-40, API SG or higher, JASO MA compliant (check manual for exact Aprilia specification).
Coolant Spec:
Aprilia approved ethylene glycol-based coolant
Potential Issues:
Some owners have reported occasional issues with the CVT system requiring specific diagnostic procedures. Electrical connectors can be prone to corrosion in damp environments. Minor vibrations at certain RPM ranges.
Maintenance Tips:
Regular cleaning and lubrication of the chain, proper torque settings on all fasteners, and diligent adherence to scheduled maintenance are crucial for longevity.
Manufacturer:
Aprilia is an Italian motorcycle manufacturer with a strong heritage in racing and performance motorcycles, known for innovation.
Introduction Year:
Introduced in 2007 as a groundbreaking model with its unique CVT transmission.
Subsequent Updates:
The Mana 850 GT ABS variant added Anti-lock Braking System and a small fairing for improved touring comfort, released shortly after the base model.
Manufacturing Location:
Italy
Production Period:
2007-2011
