🏷️ Basic Information

Make:

Kia

Model:

Rondo

Year:

2007

Engine Variant:

2.4L

Engine Code Identifier:

G4KC

Vehicle Segment:

Compact MPV / Crossover

👋 Introduction

Segment Positioning:

The Kia Rondo (also known as Carens in some markets) was positioned as a practical and versatile compact MPV, offering seating for up to seven passengers, competing with vehicles like the Mazda 5, Dodge Grand Caravan (smaller variants), and other compact minivans/MPVs.

Key Competitors 2007:

Mazda 5, Toyota Matrix, Pontiac Vibe, Saturn Aura (for some aspects of utility), potentially smaller minivans.

Vehicle Purpose:

Designed for families and individuals seeking a flexible vehicle with a blend of car-like driving dynamics and minivan-like practicality.

Manual Value Proposition:

Provides in-depth technical guidance for maintaining and repairing the 2007 Kia Rondo 2.4L, enabling owners to perform complex tasks, reduce repair costs, and extend vehicle lifespan.

📋 Manual Details

Specific Markets Covered:

Primarily North America, potentially other global markets where Rondo was sold.

Estimated Page Count:

Detailed, but not specified. Typically 1000+ pages for a comprehensive service manual.

Type:

Full Service & Repair Manual

Language:

English

Format:

PDF

📖 Manual Coverage

Powertrain:

Engine mechanical, fuel system, ignition system, exhaust system, cooling system, lubrication system, engine control systems (ECU, sensors).

Transmission:

Automatic transmission (likely 4-speed or 5-speed), transmission control module (TCM), fluid service, troubleshooting.

Drivetrain:

Front-wheel drive (FWD), CV axles, differential components, wheel bearings.

Chassis:

Suspension (front and rear), steering system, braking system (ABS, EBD), wheel alignment specifications.

Electrical:

Battery, charging system, starting system, lighting system (headlights, taillights, interior), wiring diagrams, fuses, relays, diagnostic connectors (OBD-II).

Body And Interior:

Body panels, doors, windows, seats, upholstery, HVAC system, dashboard, trim components, body sealing.

Safety Systems:

Airbag system, seatbelt pre-tensioners, ABS, traction control (if equipped).

Maintenance:

Oil and filter changes, air filter replacement, cabin air filter, spark plug replacement, coolant flush, brake fluid flush, transmission fluid service, timing belt/chain inspection (if applicable).

Troubleshooting:

Diagnostic trouble codes (DTCs), symptom-based troubleshooting for engine, transmission, electrical, and mechanical issues.

Repair:

Engine component replacement (e.g., alternator, starter, water pump), brake pad/rotor replacement, suspension component replacement, exhaust system repair, interior component repair.

Diagnostics:

Step-by-step diagnostic procedures for various systems, using scan tools, multimeters, and specific test equipment.

Component Disassembly And Assembly:

Detailed instructions for removing, inspecting, repairing, and reinstalling major vehicle components.

Depth:

Comprehensive, covering everything from basic maintenance to in-depth mechanical and electrical repairs. Suitable for professional mechanics and advanced DIY enthusiasts.

📊 Manual Specifications

File Format:

PDF

Print Quality:

High-resolution, printable for clear diagrams and text.

Binding Type:

Digital (Downloadable PDF, no physical binding).

Paper Type:

N/A (Digital format).

Zoom Capability:

Yes (Standard PDF zoom functionality).

Text Searchability:

Likely searchable text within the PDF, allowing for quick information retrieval.

⚙️ Engine Specifications

Engine Type:

Inline 4-cylinder, DOHC, 16-valve

Displacement:

2.4 Liters (2359 cc)

Bore X Stroke:

86.0 mm x 100.0 mm (Approximate)

Compression Ratio:

9.8:1 (Approximate)

Horsepower:

175 hp @ 6000 rpm (Approximate)

Torque:

169 lb-ft @ 4000 rpm (Approximate)

Fuel Delivery:

Electronic Fuel Injection (EFI), Sequential Multi-port Fuel Injection (MPI)

Fuel Type:

Unleaded Gasoline

Recommended Octane:

87 Octane (Minimum)

Coolant Type:

Ethylene Glycol based, Asian Red (Specific Kia specification recommended in manual).

Oil Type:

SAE 5W-20 (API SN or higher recommended)

Oil Capacity W Filter:

4.5 Liters (4.8 US Quarts) (Approximate)

🔧 Transmission

Type:

Automatic Transmission

Number Of Gears:

Likely 4-speed or 5-speed Automatic (Specific model year dependent, manual will detail).

Type:

Manual Transmission (Less common for this model in North America, but possible).

Transmission Fluid Type:

Kia ATF SP-III (or equivalent).

Transmission Fluid Capacity:

Approximately 7.0-8.0 Liters (7.4-8.5 US Quarts) (for complete fill, check manual for specific procedure).

📐 Dimensions

Length:

4505 mm (177.4 in)

Width:

1785 mm (70.3 in)

Height:

1650 mm (65.0 in)

Wheelbase:

2720 mm (107.1 in)

Front Track:

1545 mm (60.8 in)

Rear Track:

1555 mm (61.2 in)

Curb Weight:

1525 kg (3362 lbs) (Approximate, varies by trim/options)

Gross Vehicle Weight Rating:

2130 kg (4696 lbs) (Approximate)

Cargo Volume Behind 2Nd Row:

Approx. 393 Liters (13.9 cu ft)

Cargo Volume Behind 3Rd Row:

Approx. 165 Liters (5.8 cu ft)

Standard Tire Size:

215/60R16

Optional Tire Size:

235/55R17

Wheel Bolt Pattern:

5 x 114.3 mm (5 x 4.5 inches)

Center Bore:

67.1 mm

🛡️ Safety Features

NHTSA Front Impact Rating:

Not explicitly available for this year/model as a distinct rating, but generally considered safe for its class. Manual will detail specific structural safety points.

IIHS Crash Test Performance:

Refer to IIHS archives for specific model year testing. The Rondo generally performed adequately in its class during its production run.

Anti Lock Brakes:

Standard (ABS)

Electronic Brakeforce Distribution:

Standard (EBD)

Traction Control:

Available on some trims, likely ESP or TCS.

Airbags:

Front airbags, front side-impact airbags, side curtain airbags (available on higher trims or as option).

Seatbelts:

3-point seatbelts with pretensioners for front occupants, LATCH system for child seats.

Child Safety Locks:

Standard on rear doors.

💡 Technology Features

Audio System:

Standard AM/FM/CD player, potentially with MP3 capability. Upgrades may include SiriusXM satellite radio or premium audio systems.

Auxiliary Input:

May have an auxiliary audio input jack for connecting external media players.

Cruise Control:

Standard on most trims.

Rear Parking Sensors:

Optional on higher trim levels.

Bluetooth:

Typically not standard in 2007; may be an aftermarket addition or part of an optional tech package.

Keyless Entry:

Standard on most trims.

Power Windows And Locks:

Standard on all trims.

🔧 Maintenance

Engine Oil Change:

Every 7,500 miles (12,000 km) or 12 months, whichever comes first (under normal driving conditions). Consult manual for severe conditions.

Engine Air Filter:

Inspect every 15,000 miles (24,000 km), replace as needed. Recommended replacement at 30,000 miles (48,000 km).

Cabin Air Filter:

Inspect every 15,000 miles (24,000 km), replace as needed. Recommended replacement at 30,000 miles (48,000 km).

Spark Plugs:

Replace every 60,000 miles (96,000 km) (typically iridium or platinum type).

Coolant Flush And Replace:

Initial replacement at 105,000 miles (168,000 km), then every 45,000 miles (72,000 km) or 5 years.

Transmission Fluid Change:

Inspect every 30,000 miles (48,000 km), replace at 100,000 miles (160,000 km) under normal conditions. Severe conditions require more frequent service. Manual will specify precise interval.

Brake Fluid Flush:

Every 24 months or 30,000 miles (48,000 km), whichever comes first.

Power Steering Fluid:

Refer to manual for specific type, often ATF SP-III compatible or specific Kia power steering fluid.

Brake Fluid Type:

DOT 3 or DOT 4

Engine Oil Consumption:

Some owners have reported higher than expected oil consumption, necessitating regular oil level checks.

Suspension Wear:

Front suspension components (e.g., control arm bushings, ball joints) can wear over time, leading to clunking noises or steering issues.

Cv Axle Boots:

Torn CV axle boots can lead to joint damage if not addressed promptly.

HVAC Blower Motor:

HVAC blower motor failures have been reported in some instances.

Oil Filter Example:

Example: Purolator PBL10328, Fram PH10328, WIX 57145 (always verify with manual for exact fitment).

Engine Air Filter Example:

Example: Fram CA9873, WIX 49500 (always verify with manual for exact fitment).

📚 Vehicle History

Kia Founding:

Founded in 1944 as a manufacturer of steel tubing and bicycle parts, Kia Motors Corporation is South Korea's oldest manufacturer of motor vehicles.

Rondo Introduction:

The Kia Rondo was introduced globally in 2006 as a 2007 model year vehicle, based on the platform shared with the Kia Optima and Hyundai Sonata. It was designed to bridge the gap between a compact car and a minivan.

Production Location:

Primarily manufactured at Kia's Hwaseong plant in South Korea.

Production Years:

First Generation: 2007-2013 (North America)

🏆 Awards & Recognition

Safety Awards:

While the Rondo may not have specific individual awards for the 2007 model year, Kia vehicles of this era generally received positive marks for value and practicality from automotive review publications.

Value For Money:

Kia Rondo typically lauded for its affordable pricing and generous passenger/cargo capacity for its class.
