🏷️ Basic Information

Make:

Ford

Model:

Mustang Shelby GT500

Model Year Range:

2009-2011

Engine Code:

T80 (5.4L Supercharged V8)

👋 Introduction

Vehicle Segment:

High-performance, luxury muscle car.

Target Audience:

Enthusiast owners, DIY mechanics, restoration specialists.

Key Competitors:

Chevrolet Camaro SS, Dodge Challenger SRT8.

Manual Value Proposition:

Essential resource for accurate part identification and DIY repair planning for a specialized, high-performance vehicle.

Shelby Gt500 Distinctiveness:

Represents the pinnacle of Mustang performance for its era, featuring exclusive styling and powertrain enhancements.

📋 Manual Details

Systems Covered:

Body Panels, Cooling, HVAC, Airbags, Brakes, ABS, Cruise Control, Wheels, Front Suspension, Front Drive Axle, Steering Linkage, Steering Gear, Steering Wheel/Column, Engine Mounts, Engine Under Cover, Air Cleaner, Exhaust, Emission System, Electrical, Windshield, Cowl & Dash, Instrument Panel, Center Console, Rocker/Pillars/Floor, Front Seat, Rear Seat, Seat Belts, Front Door, Rear Door, Roof, Sunroof, Quarter Panel, Quarter Glass, Liftgate, Rear Suspension, Rear Drive Axle, Fuel Tank, Rear Body, Rear Lamps, Rear Bumper.

Procedures Included:

Component identification, part number lookup, labor time estimation, component illustrations, paint code identification, clear coat identification, information label identification, front impact kit, front bumper, grille, front lamps, hood, cooling system components, A/C refrigerant capacities, HVAC system, front fender, underhood dimensions, front inner structure, airbag system components, ABS/brake system components, cruise control system components, wheel specifications, front suspension components, front drive axle components, front steering linkage/gear components, steering pump, steering wheel/column components, engine mounts, engine under cover, air cleaner assembly, exhaust system components, emission system components, electrical system components, windshield, cowl & dash components, instrument panel components, center console components, rocker/pillars/floor components, front seat components, rear seat components, seat belt components, front door components, rear door components, roof components, sunroof components, quarter panel components, quarter glass components, liftgate components, rear suspension components, rear drive axle components, fuel tank components, rear body components, rear lamp components, rear bumper components.

Estimated Page Count:

Detailed, likely several hundred pages based on comprehensive coverage.

Manual Type:

Parts Catalog / Spare Parts List

Language:

English

Format:

Searchable PDF

📖 Manual Coverage

Exterior Body:

Front bumper, grille, hood, front fender, rocker panels, pillars, floor pan, doors, roof, sunroof, quarter panels, quarter glass, liftgate, rear body, rear bumper, rear lamps.

Cooling And HVAC:

Cooling system components, A/C refrigerant capacities, HVAC system components (A/C, Heater, Ventilation).

Safety And Restraint:

Air bag system, ABS/Brakes, Seat belts.

Suspension And Steering:

Wheels, front suspension, front drive axle, front steering linkage/gear, steering pump, steering wheel/column, rear suspension, rear drive axle.

Engine And Exhaust:

Engine mounts, engine under cover, air cleaner, exhaust system, emission system.

Electrical And Interior:

Electrical system components, windshield, cowl & dash, instrument panel, center console, front seat, rear seat, front door, rear door.

Part Identification:

Detailed component illustrations and corresponding part numbers.

Labor Estimation:

Includes labor information for part replacement.

Depth Of Coverage:

Comprehensive parts identification for external and structural components, as well as key systems. Excludes internal engine components.

📊 Manual Specifications

File Format:

Searchable PDF

Search Capability:

Yes, with linked bookmarks.

Zoom And Print:

Optimized for zooming and printing.

Digital Quality:

High-resolution digital file.

Binding Type:

N/A (Digital)

Paper Type:

N/A (Digital)

⚙️ Engine Specifications

Engine Type:

5.4L Supercharged V8 (Modular V8 Family)

Bore X Stroke:

90.2 mm x 105.0 mm (3.55 in x 4.13 in)

Compression Ratio:

8.5:1

Valvetrain:

SOHC, 3 valves per cylinder (2 intake, 1 exhaust)

Horsepower:

500-550 hp (depending on year and specific calibration)

Torque:

480-510 lb-ft (depending on year and specific calibration)

Fuel Delivery:

Sequential Electronic Fuel Injection (SEFI) with Supercharger

Supercharger Type:

Roush or Ford Racing (depending on specific GT500 variant)

🔧 Transmission

Transmission Type:

6-Speed Manual (Getrag MT82 or Tremec TR-6060)

Optional Transmission:

N/A for GT500 models in this range.

Clutch Type:

Dual-disc clutch (performance oriented)

📐 Dimensions

Length:

~191.1 inches (4854 mm)

Width:

~73.9 inches (1877 mm)

Height:

~54.5 inches (1384 mm)

Curb Weight:

~3900-4100 lbs (1769-1860 kg)

Gross Vehicle Weight Rating:

Typically around 4800 lbs (2177 kg)

🛡️ Safety Features

NHTSA Front Crash Test:

Likely 4 or 5-star (based on general Mustang platform)

IIHS Crash Test Ratings:

Good (typical for Mustang platform in relevant tests)

ABS:

Standard Anti-lock Braking System.

Traction Control:

Standard Electronic Traction Control System.

Electronic Stability Control:

Standard (AdvanceTrac with Electronic Stability Control)

Airbags:

Driver and front passenger airbags, side-curtain airbags (where equipped).

Seat Belts:

3-point active restraint system with pretensioners.

💡 Technology Features

Audio System:

Shaker 500 or Shaker 1000 audio system options, with CD player, MP3 capability, and SiriusXM Satellite Radio readiness.

Navigation:

Optional DVD-based navigation system.

Parking Sensors:

Optional rear parking sensors.

Bluetooth:

Optional SYNC voice-activated communications and entertainment system with Bluetooth connectivity.

🔧 Maintenance

Oil Change Interval:

Typically every 5,000-7,500 miles (8,000-12,000 km) or 6 months, depending on driving conditions. Refer to owner's manual for precise recommendations.

Air Filter Replacement:

Inspect every 15,000 miles (24,000 km), replace as needed.

Coolant Flush Interval:

Every 100,000 miles (160,000 km) or 5 years for Long-Life Coolant.

Engine Oil Type:

SAE 5W-50 Synthetic (preferred for supercharged applications).

Engine Oil Capacity:

Approximately 7.5 quarts (7.1 liters) with filter.

Transmission Fluid Type:

Mercon LV Automatic Transmission Fluid (if automatic equipped, though unlikely for GT500) or Manual Transmission Fluid specification (e.g., Motorcraft Dual Clutch Transmission Fluid or equivalent).

Coolant Type:

Ford Premium Gold Coolant or equivalent (50/50 mix with distilled water).

Clutch Wear:

Performance-oriented clutches can experience accelerated wear with aggressive driving.

Supercharger Belt:

Regular inspection and replacement of the supercharger drive belt is crucial.

Suspension Components:

High-performance suspension can be subject to wear, especially if driven hard.

📚 Vehicle History

Ford Performance:

Ford has a long and storied history in motorsports and performance vehicles, dating back to its early days.

Shelby Legacy:

The Shelby GT500 nameplate signifies a collaboration with Carroll Shelby and represents the highest performance tier of the Mustang.

Fifth Generation Mustang:

The 2005-2014 Mustang platform, known as the S197, marked a significant return to retro-styling and improved chassis dynamics, with the GT500 being a key variant.

Production Period:

2009-2011 model years.

Manufacturing Location:

Flat Rock, Michigan, USA

🏆 Awards & Recognition

Performance Awards:

Frequently recognized for its performance capabilities and iconic status within the automotive press and enthusiast communities.

Car And Driver 10Best:

While not always specifically for the GT500, the Mustang platform often received '10Best' or similar accolades.

Emissions Certification:

Meets U.S. EPA and California EPA emission standards for its model year.
