🏷️ Basic Information

Make:

Mazda

Model:

Mazda3 / Mazdaspeed3

Chassis Code:

BL Series

Model Years Covered:

2009-2012

👋 Introduction

Target Audience:

Professional Mechanics and DIY Enthusiasts seeking cost savings

Analogy:

Identical to service manuals used by local dealerships and technicians

Value Proposition:

Save money by performing repairs and maintenance independently; permanent digital backup

Convenience:

Immediate access, no waiting for postal delivery

📋 Manual Details

Primary Focus:

Workshop Service and Repair

Included Sections:

Owner's Manual

Specific Models Covered:

All variants of the Mazda3 and Mazdaspeed3 (BL series) equipped with the specified engines and transmissions.

Pages:

3500+

Type:

Comprehensive Workshop Service Repair Manual

Language:

English

Digital Format:

PDF

📖 Manual Coverage

Powertrain:

Engine Mechanical, Lubrication, Cooling, Intake Air, Fuel, Exhaust, Emission, Charging, Ignition, Starting, Cruise Control, Engine Control System

Drivetrain:

Driveline Axle, Clutch, Manual Transmission, Automatic Transmission

Chassis:

Suspension, Wheel Alignment, Wheels and Tires, Brake System, ABS, Parking Brake, Steering

Electrical:

Charging System, Ignition System, Starting System, Cruise Control System, Engine Control System, Lighting System, Wiper Washer System, Immobilizer System, Navigation System, Entertainment System, Power System

Body And Interior:

Heating and Ventilation, Air Conditioning, Restraints, Body & Accessories, Body Panels, Doors & Liftgate, Glass Window Mirror, Exterior & Interior, Security & Locks, Sunroof & Seat

Cruise Control:

Covers installation, operation, and troubleshooting of the cruise control system.

Immobilizer:

Details on the operation and troubleshooting of the vehicle's immobilizer and anti-theft system.

Nav And Infotainment:

Information pertaining to the navigation and entertainment systems, including basic troubleshooting.

Diagnostics:

Engine On-Board Diagnostic, Engine Symptom Troubleshooting

Maintenance:

Scheduled Maintenance, Fluid Changes, Filter Replacements

Repair And Overhaul:

Engine Mechanical Repair, Transmission Repair, Brake System Overhaul, Suspension Component Replacement, Electrical System Diagnosis and Repair, Body Panel Repair

Troubleshooting:

System-specific troubleshooting guides for various components and systems

Engine Mechanical Procedures:

Detailed procedures for engine disassembly, assembly, inspection, and measurement of all internal components.

Transmission Repair Procedures:

Comprehensive steps for the overhaul and repair of both manual and automatic transmissions, including gear inspection, seal replacement, and hydraulic system checks.

Brake System Procedures:

Service information for brake pad replacement, rotor resurfacing/replacement, caliper overhaul, bleeding procedures, and ABS component testing.

Electrical System Procedures:

Wiring diagrams, component testing, troubleshooting of starting and charging systems, lighting, and body electrical components.

Body And Trim Procedures:

Information on interior and exterior trim removal, door panel access, glass replacement, and body panel repair.

Wheel Alignment Procedures:

Specifications for camber, caster, and toe angles, along with adjustment procedures.

Level:

Comprehensive (suitable for professional mechanics and DIY enthusiasts)

Diagnostic Tools:

Covers the use of specific Mazda diagnostic tools and procedures for identifying and resolving faults.

Data Tables:

Includes technical data tables with specifications, tolerances, and torque values for all components.

📊 Manual Specifications

Format:

ZIP (requiring extraction for PDF viewing)

Viewer Requirement:

Adobe Acrobat Reader

Extraction Requirement:

WinZip or WinRAR

Size:

186 MB

Diagrams:

High Definition

Readability:

Readable on any device with PDF Reader

Printability:

Ready to Print

Binding:

N/A (Digital format)

Paper:

N/A (Digital format)

Organization:

Well-structured with bookmarks for every chapter

⚙️ Engine Specifications

Mazdaspeed3:

2.3L MZR DISI Turbocharged L3-VDT I4 Petrol Engine (Note: Product info lists 2.5L L5 I4, 2.0L LF MZR I4, 2.2L L3 I4 Turbo-Diesel. The Mazdaspeed3 BL typically used the 2.3L L3-VDT turbo. The 2.5L is common in the standard Mazda3 BL. The 2.2L diesel was also an option in some markets. This manual appears to cover multiple engine variants of the BL chassis.)

Engine 1:

2.5L L5 I4 Petrol Engine

Engine 2:

2.0L LF MZR I4 Petrol Engine

Engine 3:

2.2L L3 I4 Turbo-Diesel Engine

Mazdaspeed3 Performance Typical:

Approx. 263 hp @ 5500 rpm and 310 lb-ft @ 3000 rpm (for the 2.3L L3-VDT turbo variant. Specific figures for other engines will vary.)

Fuel Delivery:

Multi-point Fuel Injection (MPI) or Direct Injection (DI), depending on engine variant

Systems:

Catalytic converter, oxygen sensors, EGR (Exhaust Gas Recirculation), DPF (Diesel Particulate Filter) for diesel variants

🔧 Transmission

Mazdaspeed3 Manual:

6-Speed Manual Transmission (G35M-R or similar)

Automatic:

5-Speed Automatic Transmission (FS5A-EL)

Manual 1:

G35M-R

Manual 2:

G66M-R

Manual 3:

A26M-R

Automatic 1:

FS5A-EL

Clutch System:

Hydraulically operated single-plate dry clutch (for manual transmissions)

📐 Dimensions

Mazda3 Hatchback Typical Dimensions:

Length: Approx. 4460 mm (175.6 in), Width: Approx. 1755 mm (69.1 in), Height: Approx. 1470 mm (57.9 in) (Note: Specific dimensions can vary by body style and trim. Mazdaspeed3 often has slightly different dimensions due to body kits.)

Wheelbase Typical:

Approx. 2640 mm (103.9 in)

Mazdaspeed3 Curb Weight Typical:

Approx. 1485 kg (3274 lbs) (Note: Varies by equipment and body style)

Cargo Volume Hatchback:

Approx. 340 liters (12.0 cu ft) with rear seats up

🛡️ Safety Features

IIHS Top Safety Pick 2009 Mazda3:

Yes

NHTSA Front Side Impact Mazda3:

5-Star Rating (typical for this generation)

Standard Features:

Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA), Traction Control System (TCS), Dynamic Stability Control (DSC) - often standard or available across trims

Airbags:

Front airbags, Side curtain airbags, Front side-impact airbags

Structure:

High-tensile steel body structure, Crumple zones

💡 Technology Features

Head Unit Features:

AM/FM stereo, CD player, MP3 capability, Auxiliary audio input, Optional Navigation System, Optional Bluetooth connectivity

Stability Control:

Dynamic Stability Control (DSC) and Traction Control System (TCS) are key features for enhanced driving safety and performance.

Bluetooth Availability:

Available on higher trim levels and optional packages for hands-free calling and audio streaming.

🔧 Maintenance

Oil Change Typical:

Every 5,000-7,500 miles (8,000-12,000 km) or 6-12 months, depending on driving conditions and oil type

Air Filter Replacement Typical:

Every 15,000-30,000 miles (24,000-48,000 km)

Spark Plug Replacement Typical Petrol:

Every 60,000-100,000 miles (96,000-160,000 km), depending on plug type (e.g., iridium)

Engine Oil Type Petrol Typical:

API SN, ILSAC GF-5 certified, SAE 0W-20 or 5W-30 (Consult manual for specific engine variant and temperature ranges)

Engine Oil Type Diesel Typical:

API CJ-4 or CK-4, ACEA C3, SAE 5W-30 (Consult manual for specific engine variant)

Coolant Type:

Mazda Genuine Super Long Life Coolant (FL22) or equivalent (long-life ethylene glycol-based)

Brake Fluid Type:

DOT 3 or DOT 4 (Consult manual for specific recommendation)

Transmission Fluid Manual:

API GL-4, SAE 75W-90 (Consult manual for specific transmission and fill level)

Transmission Fluid Automatic:

Mazda ATF-FZ or equivalent (Consult manual for specific transmission fluid type and capacity)

Power Steering Fluid:

Refer to manual for specific type (e.g., Mazda Genuine ATF or Dexron III compatible fluid for some models).

Differential Fluid Manual Trans:

GL-5 specification, SAE 75W-90 (Consult manual for specific application and capacity).

Mazdaspeed3 Common Issues:

Clutch wear, Turbocharger issues (especially on high-mileage examples), Carbon buildup on intake valves (direct injection engines), EGR system clogging (diesel), Motor Mounts, Oil leaks

General Mazda3 Bl Common Issues:

Rear shock absorber leaks, Power steering fluid leaks (early models), Rattle noises from exhaust heat shields, AC system issues, Potential for rust in certain climates

📚 Vehicle History

Mazda Focus:

Known for 'Zoom-Zoom' driving dynamics and sporty handling

Mazda3 Generation Bl:

Second generation Mazda3 (BL) introduced in 2008 for the 2009 model year. Featured a more aerodynamic design and improved interior quality. The Mazdaspeed3 variant offered enhanced performance.

Manufacturing Locations Typical:

Japan (Hofu Plant), USA (Fremont, California – initially), Mexico (Salamanca)

🏆 Awards & Recognition

Mazda3 IIHS Top Safety Pick:

Awarded 'Top Safety Pick' by the Insurance Institute for Highway Safety (IIHS) for multiple model years in this generation, signifying excellent performance in crash testing.

Edmunds Consumer Ratings:

Generally received positive consumer ratings for performance, handling, and styling, though some reliability concerns were noted by specific owners.
