Aprilia SL750 Shiver 2009 Service Repair Workshop Manual
- 常规价格
- $16.99
- 促销价
- $16.99
- 常规价格
-
- 单价
- / 单价
🏷️ Basic Information Identification Make: Aprilia Model: SL750 Shiver Year: 2009 Product Type: Service Repair Workshop Manual 👋 Introduction Market Position Category: Sport-Touring / Naked Sportbike Target Audience: Riders seeking...
25 people are viewing this right now
类型: Motorcycle
厂商:
斯库: 602502
无法加载取货服务可用情况
共享
🏷️ Basic Information
Identification
Make:
Aprilia
Model:
SL750 Shiver
Year:
2009
Product Type:
Service Repair Workshop Manual
👋 Introduction
Market Position
Category:
Sport-Touring / Naked Sportbike
Target Audience:
Riders seeking a versatile, performance-oriented motorcycle for commuting, sport riding, and light touring.
Competitive Analysis
Competitors:
Competes with motorcycles such as the Ducati Monster series, Triumph Street Triple, and Yamaha FZ8.
Key Features
Engine Architecture:
L-twin engine known for its distinctive character and torque delivery.
Chassis Design:
Lightweight trellis frame contributing to agile handling.
Braking System:
High-performance Brembo braking components for excellent stopping power.
Suspension Quality:
Fully adjustable front and rear suspension for customizable ride and handling.
📋 Manual Details
Coverage Areas
Engine Service:
Complete engine overhaul, troubleshooting, tuning, and component repair.
Transmission Service:
Clutch, gearbox, final drive maintenance and repair.
Chassis Service:
Frame, suspension (front and rear), steering, and wheel bearing maintenance and repair.
Electrical System:
Wiring diagrams, ignition system, lighting, battery, starter, charging system, and ECU diagnostics.
Fuel System:
Fuel injection system, injectors, fuel pump, pressure regulator, and tank service.
Brake System:
Front and rear brake caliper, master cylinder, hydraulic lines, and ABS system (if applicable) service.
Cooling System:
Radiator, fan, thermostat, and coolant circulation system maintenance.
Exhaust System:
Muffler, catalytic converter, and exhaust pipe service.
Bodywork And Fairings:
Panel removal, installation, and repair.
Troubleshooting:
Diagnostic procedures for common and uncommon issues.
Periodic Maintenance:
Scheduled maintenance tasks and intervals.
Page Count
Approximate Pages:
500+
Manual Type
Type:
Factory Authorized Service Manual / Workshop Manual
Language
Language:
English
Format
Format:
Digital (PDF)
📖 Manual Coverage
Systems Covered
Engine:
V-twin, 8-valve, DOHC, liquid-cooled, fuel-injected engine specifications and repair procedures.
Transmission:
6-speed sequential gearbox, wet multi-plate clutch assembly.
Fuel Delivery:
Electronic fuel injection (EFI) system, including throttle bodies, sensors, and ECU calibration.
Ignition System:
Dual spark plug per cylinder ignition system, coil-on-plug design.
Electrical:
Complete electrical system including starter motor, alternator, battery, lighting circuits, and dashboard instrumentation.
Suspension:
Adjustable Sachs front fork (pre-load, rebound, compression) and rear monoshock absorber with adjustable pre-load and rebound damping.
Brakes:
Dual 320mm front discs with radial-mount Brembo calipers, single 240mm rear disc with Brembo caliper. Optional ABS.
Frame:
Steel trellis frame with aluminum rear subframe.
Wheels And Tires:
Front: 17 x 3.50 inch, Rear: 17 x 4.50 inch; standard tire sizes and pressures.
Procedures Included
Disassembly Reassembly:
Detailed step-by-step procedures for complete engine, transmission, suspension, and brake component disassembly and reassembly.
Diagnostics:
Troubleshooting guides based on symptoms, diagnostic trouble codes (DTCs), and measurement specifications.
Torque Specifications:
All critical bolt and fastener torque values for every component.
Alignment Calibration:
Steering head bearing adjustment, suspension alignment, and throttle body synchronization.
Electrical Testing:
Component testing for sensors, actuators, coils, and wiring continuity tests using multimeter and oscilloscope where applicable.
Maintenance Tasks:
Oil and filter changes, spark plug replacement, air filter cleaning/replacement, valve clearance checks/adjustments, coolant replacement, brake fluid replacement.
Technical Depth
Depth:
Comprehensive, covering everything from basic maintenance and inspection to full engine rebuilds and advanced electrical system troubleshooting.
📊 Manual Specifications
File Format
File Format:
PDF
Searchability:
Fully searchable text for quick information retrieval.
Printability:
Printable pages for workshop use.
Print Quality
Image Resolution:
High-resolution images and diagrams for clarity.
Binding Type
Binding:
N/A (Digital Product)
Paper Type
Paper Type:
N/A (Digital Product)
⚙️ Engine Specifications
Primary Engine
Engine Type:
V-twin, four-stroke, liquid-cooled, DOHC, 4 valves per cylinder
Displacement:
749.9 cc (45.7 cu in)
Bore X Stroke:
94 mm x 54.2 mm (3.70 in x 2.13 in)
Compression Ratio:
11.0:1
Performance
Horsepower:
95 hp (70 kW) @ 9000 rpm
Torque:
79 Nm (58.3 lb-ft) @ 7000 rpm
Fuel System
Fuel Delivery:
Electronic Fuel Injection (EFI) with dual 38mm throttle bodies
Fuel Type:
Unleaded gasoline, minimum 91 octane (RON+MON)/2
Lubrication
Oil Type:
SAE 10W-40, API SG or higher, JASO MA certified synthetic or semi-synthetic motorcycle oil
Oil Capacity:
3.2 liters (3.4 US qt) with filter change
Ignition
Ignition Type:
Electronic ignition with dual spark plugs per cylinder
🔧 Transmission
Standard
Transmission Type:
6-speed sequential, constant mesh
Clutch Type:
Wet, multi-plate
Features
Final Drive:
O-ring sealed chain
Gear Ratios:
1st: 2.46:1, 2nd: 1.75:1, 3rd: 1.38:1, 4th: 1.14:1, 5th: 1.00:1, 6th: 0.88:1
Transmission Fluid:
SAE 75W-90 API GL-4 or GL-5 gear oil (refer to manual for specific capacity)
📐 Dimensions
Exterior
Length:
2182 mm (85.9 in)
Width:
840 mm (33.1 in)
Height:
1120 mm (44.1 in)
Wheelbase:
1460 mm (57.5 in)
Ground Clearance:
140 mm (5.5 in)
Seat Height:
830 mm (32.7 in)
Weights
Dry Weight:
185 kg (407.9 lbs)
Wet Weight:
210 kg (463 lbs) (approximate with fluids)
Fuel Capacity:
15 liters (3.96 US gal)
Fuel Reserve:
3 liters (0.79 US gal) (approximate)
🛡️ Safety Features
Ratings
Safety Features Implied:
High-performance braking system, agile chassis for evasive maneuverability.
Active Features
ABS:
Optional Anti-lock Braking System (ABS) available on some models.
Lighting:
Dual headlights, LED taillight, turn signals.
Passive Features
Frame Construction:
Steel trellis frame provides rigidity and impact absorption.
Ergonomics:
Sport-oriented but relatively upright riding position for rider control.
💡 Technology Features
Infotainment
Instrument Cluster:
Digital LCD instrument cluster with tachometer, speedometer, gear indicator, fuel gauge, odometer, trip meters, clock, and diagnostic warning lights.
Driver Assistance
Ride By Wire:
Ride-by-wire throttle system for precise throttle control and potential for integrated electronic rider aids (though less advanced on this model compared to later iterations).
Connectivity
Connectivity Features:
No integrated smartphone connectivity or advanced Bluetooth features typical of modern motorcycles.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 6,000 km (3,700 miles) or annually, whichever comes first.
Oil Filter Replacement:
At every oil change.
Spark Plug Replacement:
Every 12,000 km (7,500 miles).
Air Filter Cleaning:
Every 6,000 km (3,700 miles), replacement as needed.
Valve Clearance Check:
Every 12,000 km (7,500 miles).
Coolant Replacement:
Every 24,000 km (15,000 miles) or every two years.
Brake Fluid Replacement:
Every 24,000 km (15,000 miles) or every two years.
Fluid Specifications
Coolant Type:
Ethylene glycol-based antifreeze, 50% mixture with distilled water.
Brake Fluid Type:
DOT 4
Known Issues
Common Complaints:
Some owners report occasional sensitivity in the ride-by-wire throttle response, potential for stator failure, and minor electrical gremlins if not properly maintained. Clutch slave cylinder leaks can also occur.
Troubleshooting Focus:
The manual provides detailed procedures for diagnosing and rectifying these and other potential issues.
📚 Vehicle History
Brand Heritage
Brand Origin:
Aprilia is an Italian motorcycle manufacturer founded in 1945.
Brand Focus:
Known for its racing pedigree and innovative motorcycle designs, particularly in smaller displacement and sportbike categories.
Model Evolution
Shiver Introduction:
The Shiver line was introduced as a significant step into the naked sportbike segment for Aprilia, aiming to blend performance with everyday usability.
2009 Model Context:
The 2009 model represents an early iteration of the SL750 Shiver, showcasing its initial design and engineering, building on Aprilia's V-twin expertise.
Production
Manufacturing Location:
Italy
🏆 Awards & Recognition
Recognitions
Industry Reception:
The Aprilia Shiver 750 generally received positive reviews for its V-twin engine character, sharp handling, and premium componentry, often praised as a distinctive alternative in its class.
