Description

🏷️ Basic Information

Identification

Make:

Model:

A6 Quattro

Year:

Generation

Chassis Code:

Generation Name:

Third Generation (C6)

Codes

Platform:

Volkswagen Group MLB platform

👋 Introduction

Market Position

Vehicle Class:

Executive Sedan/Wagon

Segment:

Luxury Mid-size

Competitive Analysis

Key Competitors:

BMW 5 Series, Mercedes-Benz E-Class, Lexus GS, Infiniti M

Key Features

Dvp Manufacturer:

RepairSurge

Dvp Advantage:

More convenient and less expensive than outdated printed manuals.

📋 Manual Details

Coverage Areas

Coverage Summary:

Comprehensive service and repair information for the 2009 Audi A6 Quattro.

Page Count

Estimated Page Count:

Extensive (Specific digital count not provided, but factory-derived OE materials imply thousands of pages of technical data).

Manual Type

Manual Type:

Service and Repair Manual Software

Language

Language:

English

Format

Format:

Online Software/Digital Access

Access Duration:

1 Year (with discount for extensions)

Device Compatibility:

PC, Laptop, Smartphone, Tablet

Browser Requirement:

Requires internet connection and web browser

📖 Manual Coverage

Systems Covered

Engine:

Detailed diagnosis, repair, and overhaul procedures for gasoline and diesel engines.

Drivetrain:

Service and repair for Quattro all-wheel-drive system, differentials, axles, and driveshafts.

Transmission:

Repair and maintenance for automatic transmissions (e.g., Tiptronic) and manual transmissions.

Brakes:

Front and rear brake system service, including ABS, ESP, and parking brake systems.

Suspension Steering:

Diagnosis and repair of suspension components (struts, shocks, control arms, bushings) and steering systems.

Electrical Electronics:

Extensive coverage of wiring diagrams, component testing, ECU diagnosis, sensors, actuators, lighting, and onboard electronics.

Bodywork Chassis:

Body panel removal/installation, interior trim, chassis components, and corrosion protection.

Climate Control:

HVAC system diagnosis and repair, including A/C refrigerant service and climate control modules.

Exhaust Emissions:

Catalytic converters, exhaust manifold, oxygen sensors, and emissions control systems.

Procedures Included

Maintenance Procedures:

Scheduled maintenance, fluid changes (oil, coolant, brake fluid, transmission fluid), filter replacements, spark plug service.

Diagnostic Procedures:

Step-by-step troubleshooting guides, fault code interpretation, component testing procedures.

Repair Procedures:

Detailed instructions for component removal, installation, and adjustment for all major vehicle systems.

Rebuilding Procedures:

Engine and transmission overhaul procedures, including torque specifications and tolerances.

Wiring Diagrams:

Comprehensive and detailed electrical schematics for all vehicle circuits.

Technical Depth

Depth Of Information:

Factory-level diagnostic and repair data, suitable for professional technicians and advanced DIYers.

Diagnostic Tools:

References diagnostic procedures that may require specialized Audi VCDS or equivalent tools.

Special Tools:

Identifies specific tools required for certain repair procedures.

📊 Manual Specifications

File Format

Digital Format:

Web-based software with search functionality

Print Quality

Print Capability:

Pages can be printed from the online interface.

Binding Type

Binding:

N/A (Digital Format)

Paper Type

Paper Quality:

N/A (Digital Format)

Software Features

Searchability:

Fully searchable text for quick access to information.

Licensing:

Officially licensed, derived from OE materials.

⚙️ Engine Specifications

Primary Engine

Available Engines 2009 A6 Quattro:

3.2L FSI V6 (163kW/217hp), 4.2L FSI V8 (257kW/345hp), 3.0L TFSI V6 Supercharged (290hp - typically later models, but check specific VIN), 3.0L TDI V6 Diesel (240hp - availability varies by market).

Performance

Engine Variations Coverage:

Covers multiple engine variants present in the 2009 A6 Quattro lineup.

Fuel System

Fuel Delivery:

Fuel Stratified Injection (FSI) for gasoline engines, Common Rail Direct Injection (CDI) for TDI engines.

Engine Management:

Advanced Engine Control Units (ECUs) with detailed diagnostic parameters.

Fluid Specifications

Engine Oil Type:

Refer to manual for specific SAE viscosity grade and API/ACEA specifications (e.g., SAE 5W-40 or 0W-30, VW 502 00/505 00).

Coolant Type:

G12 PLUS+ (Pink) or equivalent silicate-free, organic acid technology (OAT) antifreeze.

🔧 Transmission

Standard

Standard Transmission Type:

Typically 6-speed Tiptronic automatic transmission (09L, 0B6 variants).

Optional

Optional Transmission Type:

Rarely, manual transmissions were offered in some markets, but automatic was dominant.

Features

Quattro Drivetrain:

Standard Torsen center differential providing permanent all-wheel drive.

Tiptronic Functionality:

Allows manual gear selection via shifter or steering wheel paddles.

Fluid Specifications

Automatic Transmission Fluid:

Refer to manual for specific G 055 005 or G 055 025 specification fluids for Tiptronic transmissions.

📐 Dimensions

Exterior

Wheelbase:

Approx. 2843 mm (111.9 inches)

Length:

Approx. 4916 mm (193.5 inches)

Width:

Approx. 1855 mm (73.0 inches)

Height:

Approx. 1477 mm (58.1 inches)

Weights

Curb Weight Range:

Approx. 1700 kg - 1900 kg (3748 lbs - 4189 lbs), depending on engine and options.

Gross Vehicle Weight Rating:

Refer to vehicle VIN plate for exact GVWR.

Wheel And Tire

Wheel Bolt Pattern:

5x112 mm

Standard Tire Sizes:

Common sizes include 225/55R17, 245/45R18, 255/35R19. Refer to manual or door jamb sticker for exact fitment.

🛡️ Safety Features

Ratings

NHTSA Safety Rating:

Likely received good ratings, but specific 2009 A6 Quattro NHTSA scores should be verified through official channels.

IIHS Top Safety Pick:

The C6 A6 generation generally performed well in IIHS testing, often earning 'Good' ratings.

Active Features

Electronic Stability Control:

Standard ESP (Electronic Stabilization Program) system.

Traction Control:

Standard ASR (Anti-Slip Regulation) as part of the Quattro system and ESP.

Passive Features

Airbags:

Front, side, and curtain airbags as standard.

Seatbelts:

Three-point inertia-reel seatbelts with pre-tensioners and force limiters.

Child Seat Anchors:

ISOFIX/LATCH child seat anchorage points.

💡 Technology Features

Infotainment

Mmi System:

Multi Media Interface (MMI) system controlling navigation, audio, climate, and vehicle settings.

Audio Systems:

Various audio options, including Bose and Bang & Olufsen sound systems.

Connectivity:

Optional Bluetooth phone integration, SiriusXM satellite radio, and SD card slots for media.

Driver Assistance

Parking Assistance:

Optional parking sensors (front and rear) and rearview camera.

Adaptive Cruise Control:

Optional Adaptive Cruise Control (ACC) system.

Lighting

Headlights:

Standard HID (Xenon) headlights with LED daytime running lights, often with adaptive cornering function.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically every 10,000 miles or 1 year, but flexible service system (ASF) may adjust based on driving conditions. Consult manual or MMI display.

Timing Belt Replacement:

Not applicable for 2009 A6 Quattro models; they use timing chains.

Spark Plug Replacement:

Varies by engine: FSI engines typically have longer intervals (e.g., 60,000 miles for initial replacement). Refer to manual for specific engine.

Brake Fluid Flush:

Typically every 2 years.

Automatic Transmission Service:

Audi typically recommends transmission fluid and filter service at around 60,000-100,000 miles, or as indicated by the vehicle's service history.

Known Issues

Common Issues Overview:

C6 A6 models can experience issues such as oil consumption in V6 engines, air suspension leaks (if equipped), MMI system glitches, and PCV valve failures.

Oil Consumption V6:

The 3.2 FSI V6 engine can be prone to higher than average oil consumption due to piston ring design.

Mmi System Quirks:

Infotainment system (MMI) can occasionally experience software glitches requiring resets or updates.

📚 Vehicle History

Brand Heritage

Audi Legacy:

Audi AG is a German manufacturer of performance luxury automobiles, known for its Quattro all-wheel-drive technology and sophisticated engineering.

Model Evolution

A6 Lineage:

The A6 designation replaced the Audi 100 in 1994. The C6 generation (2004-2011) represented a significant styling and technological update over its predecessor.

C6 Generation Introduction:

The C6 A6 was introduced in 2004 and received a facelift in 2008, with the 2009 model year featuring updated styling cues and technology.

Production

Manufacturing Locations:

Primarily manufactured in Neckarsulm, Germany.

🏆 Awards & Recognition

Recognitions

Car And Driver 10Best:

Audi A6 models have frequently been recognized on Car and Driver's 10Best lists in past years, indicating strong performance and appeal.

Ward Best Engines:

Audi's V6 and V8 FSI engines have received Wards 10 Best Engines awards in various years, highlighting their technological prowess.
