Positioning:
Premium mid-size luxury SUV, competing with vehicles like the Mercedes-Benz ML-Class, Audi Q7, and Lexus RX.
Key Competitors:
Mercedes-Benz ML-Class, Audi Q7, Lexus RX, Porsche Cayenne, Volvo XC90.
Vehicle Strengths:
Renowned BMW driving dynamics, luxurious interior, powerful engine options, advanced technology, and a robust AWD system (xDrive).
Manual Advantage:
Provides direct access to OE (Original Equipment) derived information, offering accuracy and completeness superior to generic repair manuals.
Convenience:
Online, searchable format accessible from multiple devices, offering instant access without the bulk and obsolescence of printed manuals.
Covered Regions:
Global (Standardized Automotive Repair Information)
Estimated Page Count:
Varies by specific engine/options, but extensive (comparable to comprehensive factory manuals)
Type:
Service and Repair Manual Software (Online Access)
Format:
Web-based Software (Accessible via Browser)
Engine:
Covers all major engine variants for the 2009 X5 including inline-6 and V8 gasoline engines, and diesel variants where applicable.
Drivetrain:
Detailed coverage of xDrive all-wheel-drive system, differentials, driveshafts, and axle components.
Suspension Steering:
Complete information on front and rear suspension systems, adaptive drive (if equipped), power steering systems, and steering components.
Brakes:
Comprehensive data on hydraulic brake systems, ABS, Dynamic Stability Control (DSC), parking brake systems, and brake component replacement.
Electrical Electronics:
Extensive wiring diagrams, electrical component locations, diagnostic procedures for body electronics, comfort systems, and powertrain electronics.
Bodywork:
Information on body panel removal/installation, doors, windows, sunroof, and interior trim components.
Heating Ventilation Air Conditioning HVAC:
Detailed diagnostics and repair procedures for HVAC systems, including refrigerant handling, climate control modules, and component replacement.
Maintenance:
Scheduled maintenance procedures, fluid changes, filter replacements, brake pad/rotor service, and general inspection routines.
Troubleshooting:
Diagnostic flowcharts, symptom-based troubleshooting guides, and error code explanations for various systems.
Repair Replacement:
Step-by-step repair instructions for virtually all mechanical and electrical components, including engine rebuilds, transmission overhauls, and body component repairs.
Technical Specifications:
Torque specifications, alignment data, fluid capacities, electrical schematics, and component dimensions.
Depth:
Factory-level technical information, suitable for professional technicians and advanced DIYers, covering everything from routine maintenance to complete overhauls and diagnostics.
Format Details:
Web-based, requiring an active internet connection and a modern web browser. No downloadable file provided.
Print Quality Expectation:
N/A (online access only, printing individual pages is user's responsibility and quality may vary)
Binding Type Expectation:
N/A (online access only)
Paper Type Expectation:
N/A (online access only)
Engine Options E70 2009:
xDrive30i (N52B30), xDrive48i (N62B48) - Note: Diesel variants (e.g., M57) may also be covered depending on regional market focus.
Xdrive30I Engine Specs:
3.0L Inline-6, approx. 255 hp @ 6600 rpm, 236 lb-ft torque @ 2750 rpm.
Xdrive48I Engine Specs:
4.8L V8, approx. 350 hp @ 6300 rpm, 350 lb-ft torque @ 3400 rpm.
Injection System:
Fuel injection (specific type varies by engine, e.g., Valvetronic and Double VANOS for N52).
Fuel Type:
Premium Unleaded Gasoline (91 octane or higher recommended).
Transmission Type Standard:
6-speed Automatic Steptronic (ZF 6HP26/6HP28).
Transmission Type Optional:
N/A for 2009 model year - Automatic was standard.
Transmission Features:
Steptronic manual shifting mode, adaptive shift programs.
Length:
Approx. 191.1 inches (4855 mm)
Width:
Approx. 76.5 inches (1943 mm)
Height:
Approx. 69.1 inches (1755 mm)
Wheelbase:
Approx. 115.6 inches (2935 mm)
Cargo Volume Seats Up:
Approx. 25.0 cu ft (708 liters)
Cargo Volume Seats Down:
Approx. 75.2 cu ft (2130 liters)
Curb Weight Approx 30I:
Approx. 4,600 lbs (2087 kg)
Curb Weight Approx 48I:
Approx. 4,900 lbs (2223 kg)
NHTSA Front Crash Test Rating:
5-Star (for driver and passenger frontal impact)
IIHS Top Safety Pick:
Yes (for models equipped with specific safety features)
Active Safety Systems:
Dynamic Stability Control (DSC), Dynamic Traction Control (DTC), Anti-lock Braking System (ABS), Hill Descent Control (HDC), Automatic Differential Brake (ADB-X).
Airbags:
Front airbags, front side-impact airbags, head protection system (air curtains) for front and rear passengers.
Seatbelts:
3-point inertia-reel seatbelts with front-seat pretensioners and force limiters, rear seatbelts, optional third-row seatbelts.
Infotainment System:
BMW iDrive system (CCC or CIC depending on specific production date/options), featuring navigation, radio, CD/DVD player, Bluetooth connectivity.
Driver Assistance Features:
Optional features may include adaptive cruise control, head-up display (HUD), lane departure warning, backup camera, parking assist sensors.
Connectivity Options:
Bluetooth for hands-free calling and audio streaming, optional USB/Auxiliary input for audio devices.
Oil Change Interval:
Condition-Based Service (CBS) system typically suggests oil changes around every 10,000-15,000 miles or annually, depending on driving conditions.
Major Service Interval:
Major inspections and fluid changes (e.g., transmission fluid, coolant, brake fluid) are typically recommended around 60,000 - 100,000 miles or as indicated by CBS.
Engine Oil Spec:
BMW Longlife-01 (LL-01) or BMW Longlife-04 (LL-04) approved synthetic oil, typically 5W-30 or 0W-30, depending on climate and specific engine.
Coolant Spec:
BMW Blue Antifreeze/Coolant (G48) or equivalent meeting BMW specifications.
Transmission Fluid Spec:
ATF LT 71141 or equivalent (for ZF 6HP transmissions) - often referred to as 'lifetime' fluid by BMW, but servicing is recommended.
Common X5 E70 Issues:
PCV valve failure (N52 engine), oil leaks (valve cover gaskets, oil pan gasket), cooling system issues (water pump, thermostat), VANOS solenoid issues, potential starter issues, tailgate struts failure.
Bmw SUV Lineage:
BMW's entry into the SUV market began with the X5 in 1999 (E53 generation), establishing the 'SAV' (Sports Activity Vehicle) nomenclature.
E70 Introduction:
The E70 generation debuted for the 2007 model year, marking a significant redesign with increased dimensions, improved chassis dynamics, and advanced technology.
E70 Key Updates For 2009:
Introduction of the Active Ventilated Seats option, enhanced iDrive system, and potentially minor package/feature adjustments.
Manufacturing Locations:
Primarily produced at BMW's Spartanburg, South Carolina, USA plant.
