🏷️ Basic Information

Make:

Kia

Model:

Sportage

Year:

2009

Engine Code:

G4GC (2.0L DOHC)

Generation:

Second Generation (JE/KM)

👋 Introduction

Market Position:

The 2009 Kia Sportage positioned itself as a value-oriented compact SUV, competing with models like the Honda CR-V, Toyota RAV4, and Ford Escape. It offered a practical and affordable option in a popular segment.

Competitive Analysis:

Competed on price point and feature set. The 2.0L engine offered decent fuel economy for its class, while the available AWD provided versatility. The manual service manual provides in-depth support for owners and independent repair shops aiming to maintain this specific generation.

Key Features:

Body-on-frame construction (until 2010 models of this generation), available all-wheel drive, relatively spacious interior for its class, and Kia's improving reputation for quality and value.

📋 Manual Details

Coverage Areas:

All versions of the 2009 Kia Sportage with the 2.0L DOHC 4-cylinder engine.

Page Count:

Not specified, but described as 'comprehensive' covering 'bumper to bumper'.

Manual Type:

OEM Factory Shop Service Repair Manual (FSM)

Language:

English (Implied by typical OEM manuals and description)

Format:

PDF (Single File)

📖 Manual Coverage

Systems Covered:

Engine, Transmission (Manual & Automatic), Drivetrain, Suspension, Steering, Brakes (ABS, EBD), HVAC, Fuel System, Cooling System, Exhaust System, Electrical System (Wiring Diagrams, ECU, Sensors), Body & Chassis, Interior Components, Safety Systems (Airbags, Seatbelts).

Procedures Included:

Routine Maintenance (Tune-ups, Fluid Changes, Filter Replacement), Brake Service, Engine Repair (Diagnosis, Overhaul, Component Replacement), Transmission Service & Repair, Drivetrain Component Service, Suspension & Steering Alignment & Repair, Electrical System Troubleshooting & Repair, HVAC System Diagnosis & Repair, Body Panel Repair & Replacement, Interior Trim & Component Service, Diagnostic Procedures, Component Specifications, Torque Specifications, Wiring Diagrams.

Technical Depth:

Expert Level: Suitable for professional technicians and experienced DIY enthusiasts. Covers detailed diagnostic procedures, component disassembly and reassembly, repair instructions, and technical specifications.

📊 Manual Specifications

File Format:

PDF

Searchability:

Searchable Text within PDF

Internet Access Required:

No (Self-contained PDF)

Software Dependency:

No (Does not require proprietary software or installation)

Compatibility:

Universal (Windows 95-11, macOS, Linux, iOS, Android via PDF reader)

Print Quality:

High-resolution digital reproduction of original factory documentation.

Binding Type:

Digital (PDF file)

Paper Type:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Family:

Kia Beta II / Hyundai Alpha II

Engine Type:

Inline 4-cylinder, DOHC (Dual Overhead Camshaft), 16 Valves

Displacement:

1998 cc (2.0 Liters)

Bore X Stroke:

86.0 mm x 86.0 mm

Compression Ratio:

9.5:1

Horsepower:

Approx. 139 hp @ 6000 rpm (Varies slightly by region/specification)

Torque:

Approx. 134 lb-ft @ 4500 rpm (Varies slightly by region/specification)

Fuel Delivery:

Electronic Fuel Injection (MPI - Multi-Point Injection)

Fuel Type:

Unleaded Gasoline

Fuel Tank Capacity:

Approx. 58 Liters (15.3 US Gallons)

🔧 Transmission

Standard Transmission:

5-Speed Manual

Optional Transmission:

4-Speed Automatic with Overdrive

Transmission Fluid Spec Manual:

GL-4 gear oil (e.g., SAE 75W-90, check manual for specific Kia/Hyundai spec)

Transmission Fluid Spec Automatic:

Kia Genuine ATF SP-III or equivalent (e.g., Dexron III/Mercon compatible, check manual for specific spec)

📐 Dimensions

Length:

Approx. 4350 mm (171.3 in)

Width:

Approx. 1800 mm (70.9 in)

Height:

Approx. 1700 mm (66.9 in)

Wheelbase:

Approx. 2630 mm (103.5 in)

Curb Weight:

Approx. 1450-1550 kg (3197-3417 lbs) depending on configuration (FWD/AWD, transmission).

Gross Vehicle Weight Rating Gvwr:

Not specified in product info, typically available in FSM.

Cargo Volume Behind Rear Seats:

Approx. 340 Liters (12.0 cu ft)

Cargo Volume With Rear Seats Folded:

Approx. 1380 Liters (48.7 cu ft)

🛡️ Safety Features

NHTSA Front Impact Driver:

4 Stars (for MY 2005-2008, specific 2009 may vary)

NHTSA Front Impact Passenger:

4 Stars (for MY 2005-2008, specific 2009 may vary)

IIHS Front Offset Crash Rating:

Good (for MY 2005-2008, specific 2009 may vary)

Active Safety Features:

Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Traction Control System (TCS) (often standard or optional).

Passive Safety Features:

Front Airbags (Driver & Passenger), Side-Impact Airbags (Front), Side Curtain Airbags (Front & Rear), Pretensioner Seatbelts.

💡 Technology Features

Infotainment System:

Base models likely featured a single-disc CD player with AM/FM radio and auxiliary input. Higher trims might have offered an upgraded audio system, and potentially a basic display for trip information or climate control. Apple CarPlay/Android Auto were not standard.

Driver Assistance Features:

Limited compared to modern vehicles. Primarily relied on ABS, EBD, and optional TCS. No advanced electronic driver-assistance systems (ADAS) like adaptive cruise control or lane-keeping assist.

Connectivity Options:

Auxiliary audio input jack was common. Bluetooth for hands-free calling was a possibility on higher trims or as an aftermarket addition. USB connectivity was generally absent.

🔧 Maintenance

Oil Change Interval:

Typically 7,500 miles (12,000 km) or 6 months, whichever comes first. Check manual for specific conditions (severe vs. normal).

Air Filter Replacement:

Every 30,000 miles (48,000 km) or as needed based on inspection.

Spark Plug Replacement:

Typically iridium spark plugs with intervals around 100,000 miles (160,000 km). Check manual for exact type and interval.

Timing Belt Or Chain:

This 2.0L engine (G4GC) typically uses a timing chain, which generally does not require replacement unless there are signs of wear or malfunction. The manual will detail any chain tensioner or guide inspection intervals.

Engine Oil Capacity:

Approx. 4.5 Liters (4.8 US Quarts) with filter change. Requires API SN/SM or ILSAC GF-5, SAE 5W-30 or 5W-40 depending on climate (verify with manual).

Coolant Type:

Ethylene Glycol-based coolant (e.g., Asian vehicle specific coolant, typically OAT or HOAT. Check manual for Kia specification).

Brake Fluid Type:

DOT 3 or DOT 4 (Verify with manual for precise specification).

Power Steering Fluid Type:

Refer to manual for specific type, often Dexron III compatible ATF or dedicated power steering fluid.

Known Issues:

Potential for oil leaks from valve cover gasket and oil pan gasket, occasional issues with ABS sensors, suspension component wear (bushings, ball joints), and HVAC blower motor resistor failure. Catalytic converter issues can also occur with age and mileage. The manual provides specific diagnostic procedures for these.

📚 Vehicle History

Brand Heritage:

Kia Motors Corporation, founded in 1944, is South Korea's oldest manufacturer of motor vehicles. Known for its steady growth and expansion into global markets, emphasizing value and reliability.

Model Evolution:

The Sportage (JE/KM generation) was introduced in 2004. It marked a shift for Kia towards more car-like SUV characteristics compared to the first generation. The 2009 model year represents a late-stage iteration of this generation, often receiving minor updates.

Production Years Generation:

2004-2009 (JE/KM)

Manufacturing Locations:

Primarily South Korea (Gwangmyeong plant), with some production potentially in other global facilities depending on market.

🏆 Awards & Recognition

Recognitions:

While specific awards for the 2009 model are less prominent, Kia as a brand received increasing recognition for quality and value during this period, often appearing in J.D. Power and Associates' dependability studies.
