🏷️ Basic Information

Make:

Ford

Model:

Mustang Shelby GT500

Model Years Covered:

2010, 2011, 2012

Internal Project Codes:

S197 Generation (Second Facelift)

👋 Introduction

Segment:

American muscle car, high-performance coupe

Gt500 Role:

Top-tier performance variant of the Mustang, focused on track capability and brute force.

Competitors:

Chevrolet Camaro SS, Dodge Challenger SRT8, Cadillac CTS-V (depending on specific performance benchmarks).

Engine:

Supercharged 5.4L V8 ('Cobra Jet' derived)

Transmission:

Tremec TR-6060 6-speed manual

Brakes:

Brembo front and rear brake system

Aerodynamics:

Unique Shelby GT500 styling, enhanced aerodynamics for high-speed stability.

📋 Manual Details

General Coverage:

Complete workshop service and repair

Specific Systems Coverage:

Engine, Drivetrain, Chassis, Body, Electrical, HVAC, Braking System, Suspension, Steering, Fuel System, Exhaust System, Climate Control, Safety Systems, Powertrain Control Module (PCM), Body Control Module (BCM), Infotainment, Diagnostics

Estimated Page Count:

Detailed information indicates comprehensive coverage, typically exceeding 1000 pages for full workshop manuals of this era and complexity. Actual page count not specified, but implied to be extensive.

Type:

Workshop Service Repair Manual

Language:

English

Digital Format:

Downloadable PDF (requires Adobe Reader)

📖 Manual Coverage

Engine Mechanical:

Detailed procedures for engine assembly, disassembly, component inspection, repair, and troubleshooting for the 5.4L Supercharged V8.

Engine Performance:

Includes tuning, diagnostics, and service related to engine performance, ignition system, and fuel delivery.

Transmission:

Comprehensive coverage for the Tremec TR-6060 6-speed manual transmission, including clutch, gearbox, and driveline components.

Brakes:

Service and repair procedures for the high-performance Brembo braking system, including front and rear calipers, rotors, pads, and ABS system.

Suspension Steering:

Detailed information on front and rear suspension components, alignment, steering system diagnostics, and repair.

Electrical System:

Extensive coverage of wiring diagrams, component locations, diagnostics for all electrical systems, including lighting, power accessories, ignition, and ECUs.

Body Exterior:

Procedures for body panel repair, alignment, cosmetic restoration, and associated hardware.

Interior Trim:

Details on interior trim removal, installation, and repair for seats, dashboard, door panels, and console.

HVAC:

Service and repair of the heating, ventilation, and air conditioning system, including refrigerant handling and component replacement.

Fuel System:

Diagnosis and repair of the fuel tank, pump, lines, injectors, and supercharger fuel system components.

Exhaust System:

Service procedures for the performance exhaust system, including catalytic converters, mufflers, and piping.

Routine Maintenance:

Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection and replacement.

Troubleshooting Diagnostics:

Step-by-step diagnostic procedures, fault code interpretation, and troubleshooting guides for all major vehicle systems.

Component Replacement:

Detailed instructions for replacing all major and minor components, from engine parts to body trim.

Rebuild Procedures:

Comprehensive rebuild procedures for major components like the engine, transmission, and differential.

Wiring Diagrams:

High-quality, detailed electrical schematics for all vehicle systems.

Torque Specifications:

Precise torque values for all fasteners and critical assembly points.

Special Tools Required:

Identification and usage instructions for any specialized tools needed for specific repairs.

Calibration Procedures:

Procedures for calibrating various sensors and control modules after component replacement.

Depth:

Professional-grade, covering everything from basic maintenance to complete engine and transmission overhauls, including advanced diagnostics.

📊 Manual Specifications

Primary Format:

PDF

Searchability:

Likely contains searchable text for efficient information retrieval.

Quality:

High quality, designed for clear printing of instructions and diagrams.

Illustrations:

Includes numerous step-by-step illustrations, diagrams, and photographs to aid understanding.

Binding:

N/A (Downloadable format)

Paper Type:

N/A (Downloadable format)

⚙️ Engine Specifications

Engine Code:

TR3650 (typically, or variant thereof for GT500)

Displacement:

5.4 Liters (330 cubic inches)

Configuration:

V8 (90-degree block)

Aspiration:

Supercharged (Roots-type, intercooled)

Horsepower 2010 2011:

500 hp @ 6000 rpm

Horsepower 2012:

550 hp @ 6200 rpm

Torque 2010 2011:

480 lb-ft @ 4500 rpm

Torque 2012:

510 lb-ft @ 4250 rpm

Fuel Delivery:

Sequential Electronic Fuel Injection (SEFI) with high-flow injectors and upgraded fuel pump for supercharged application.

Fuel Type:

Premium Unleaded (91 Octane or higher recommended)

Supercharger Cooling:

Air-to-liquid intercooler system.

🔧 Transmission

Transmission Type:

Tremec TR-6060 6-speed manual transmission

Optional Transmissions:

None offered for GT500 variant.

Gear Ratios:

Specific gear ratios available in manual, typically geared for performance. Exact ratios for each gear are detailed within the manual.

Clutch System:

Heavy-duty, performance-oriented clutch assembly.

Transmission Fluid:

Manual Transmission Fluid (MTF) - specific Ford specification, e.g., Motorcraft XYZ-1904-A, or equivalent DOT 4 brake fluid for hydraulic clutch system. Exact specifications detailed in manual.

📐 Dimensions

Length:

Approximately 189.2 inches (4806 mm)

Width:

Approximately 73.9 inches (1877 mm)

Height:

Approximately 54.1 inches (1374 mm)

Wheelbase:

Approximately 107.1 inches (2720 mm)

Curb Weight:

Approximately 3800 - 3900 lbs (1724 - 1769 kg), varies by year and options.

Trunk Volume:

Approximately 13.4 cubic feet (379 liters)

🛡️ Safety Features

NHTSA Front Impact:

Likely 4-star rating (based on Mustang platform for similar years).

IIHS Front Overlap:

Good (based on Mustang platform for similar years).

ABS:

Anti-lock Braking System (ABS) with Electronic Brake Force Distribution (EBD)

Traction Control:

Electronic Traction Control System (TCS)

Stability Control:

Electronic Stability Control (ESC) - often with performance modes.

Airbags:

Front airbags, front side-impact airbags.

Seatbelts:

3-point active belts with pretensioners and load limiters.

Body Structure:

High-strength steel safety cage construction.

💡 Technology Features

Shaker Audio:

Optional Shaker audio systems (Shaker 500, Shaker 1000) with CD player, AM/FM radio, and auxiliary input. Later models may offer SiriusXM compatibility.

Navigation:

Optional factory navigation system available on some trims/packages.

Parking Sensors:

Rear parking sensors were an optional feature.

Sync System:

Ford SYNC voice-recognition communication and entertainment system available on select models, offering Bluetooth connectivity and media control.

🔧 Maintenance

Oil Change Interval:

Typically every 5,000 - 7,500 miles or 6 months, depending on driving conditions. Manual will specify exact interval.

Tire Rotation:

Every 5,000 - 7,500 miles (aligned with oil changes).

Spark Plugs:

Dependent on plug type, typically at higher mileage intervals (e.g., 60,000 - 100,000 miles for iridium plugs). Manual will provide specifics.

Engine Oil:

SAE 5W-50, meeting Ford WSS-M2C153-H specification or equivalent (e.g., Motorcraft 5W-50 Full Synthetic). Consult manual for exact specification.

Coolant:

Ford Premium Engine Coolant (Yellow) - Motorcraft VC-7B or equivalent, 50/50 mix with distilled water.

Brake Fluid:

DOT 4 Motorcraft High Performance DOT 3 & 4 Motor Vehicle Brake Fluid (or equivalent) for clutch and brakes.

Clutch Wear:

High-torque supercharged engine can lead to accelerated clutch wear with aggressive driving.

Supercharger Belt:

Serpentine belt for supercharger and accessories requires periodic inspection and potential replacement due to load.

Brake Maintenance:

Brembo brakes are high-performance but require regular pad and rotor inspection and replacement, especially under hard use.

📚 Vehicle History

Ford Performance:

Ford's long history of performance vehicles and iconic muscle cars.

S197 Generation:

This generation of Mustang (S197) was a significant redesign, returning to a retro-inspired aesthetic. The GT500 represents the pinnacle of its performance capabilities during this era.

Shelby Legacy:

Carries the legendary Shelby name, signifying a more powerful, track-focused version of the Mustang.

Manufacturing Plant:

Flat Rock Assembly Plant, Michigan, USA

🏆 Awards & Recognition

Performance Accolades:

Consistently lauded by automotive press for its raw power and track-day capabilities, often featured in 'best performance car' lists.
