Model:
400 TRV, 500 FIS, 550 TRV, 650 FIS, 700 FIS, 700 TBX, 700 TRV, 1000 Thundercat TRV Cruiser
Chassis Code:
Varies by model (e.g., TRV, FIS, TBX)
Positioning:
Comprehensive service solution for a range of popular 2010 Arctic Cat ATV models, targeting owners seeking to perform their own maintenance and repairs.
Advantage:
Provides detailed, model-specific information often missing in generic ATV repair guides. Offers a cost-effective alternative to dealership service.
Features:
Instant download, high-quality diagrams, step-by-step instructions, comprehensive coverage across multiple models, printable pages.
Models Covered:
2010 Arctic Cat 400 TRV, 2010 Arctic Cat 500 FIS, 2010 Arctic Cat 550 TRV, 2010 Arctic Cat 650 FIS, 2010 Arctic Cat 700 FIS, 2010 Arctic Cat 700 TBX, 2010 Arctic Cat 700 TRV, 2010 Arctic Cat 1000 Thundercat TRV Cruiser
Type:
Workshop Service Repair Manual
Engine:
Complete engine overhaul, disassembly, assembly, diagnosis, and tuning.
Transmission:
Service and repair of automatic transmissions, including lubrication and component replacement.
Fuel System:
Fuel injection system diagnosis and repair, fuel pump, injectors, and related components.
Cooling System:
Radiator, fan, coolant hoses, thermostat, and water pump service.
Electrical System:
Wiring diagrams, battery, charging system (stator, regulator/rectifier), ignition system, lighting, and accessories.
Drive System:
Front and rear differentials, drive shafts, CV joints, and four-wheel drive (4WD) engagement mechanisms.
Suspension:
Front and rear suspension components, shocks, springs, A-arms, bushings, and alignment procedures.
Steering System:
Handlebar, tie rods, steering rack/box, and associated linkages.
Frame And Bodywork:
Chassis inspection, body panel removal and installation, and general structural components.
Brakes:
Hydraulic brake system diagnosis, caliper service, rotor replacement, and brake fluid bleeding.
Controls And Indicators:
Throttle, brake levers, gear selector, dashboard indicators, and switches.
Maintenance:
Routine maintenance tasks, tune-ups, fluid changes, filter replacements, and lubrication.
Diagnostics:
Step-by-step diagnostic procedures for troubleshooting common and complex issues.
Repair:
Detailed repair instructions for all major components and systems.
Rebuilds:
Comprehensive procedures for engine, transmission, and differential rebuilds.
Wiring Diagrams:
High-quality, detailed electrical wiring diagrams for accurate troubleshooting.
Depth:
Extensive coverage from basic maintenance to in-depth mechanical and electrical repair, suitable for DIY enthusiasts and professional technicians.
Engine Variants:
The manual covers multiple engine displacements including approximately 375cc, 475cc, 545cc, 650cc, 695cc, and 951cc (Thundercat).
Power Delivery:
Focuses on engine tuning, fuel delivery optimization, and ensuring peak performance for each specific engine configuration.
Type:
Electronic Fuel Injection (EFI) systems are extensively covered, including diagnosis and component calibration.
General:
While no specific crash ratings exist for ATVs in the same way as passenger cars, the manual covers brake system integrity, suspension stability, and safe operating procedures.
Features:
Emphasis on proper maintenance of braking systems, steering components, and 4WD engagement for safe operation in various terrains.
Features:
Covers inspection of frame integrity, seating, and controls to ensure driver and passenger safety.
Features:
ATVs of this era typically do not feature extensive infotainment systems; focus is on functional instrumentation and controls.
Features:
While lacking advanced driver assistance systems, the manual details the operation and maintenance of the 4WD system and engine braking, which are key technological features for off-road control.
Features:
No electronic connectivity features are typically found on these models.
Tune Up:
The manual details recommended service intervals for tasks such as spark plug replacement, air filter cleaning/replacement, oil changes, and valve adjustments, typically outlined in hours of operation or mileage.
Belt Replacement:
Specific recommendations for CVT belt inspection and replacement based on wear and mileage.
Engine Oil:
Specifies recommended SAE viscosity grades (e.g., 0W-40, 10W-40, 20W-50) and API service classifications based on operating temperature and model.
Gear Lube:
Details required gear oil specifications for front and rear differentials and the transmission.
Coolant:
Specifies the type of antifreeze/coolant (e.g., ethylene glycol-based) and the correct mixture ratio.
Brake Fluid:
Recommends DOT 3 or DOT 4 brake fluid for hydraulic systems.
Common Problems:
While the manual focuses on repair, it implicitly addresses common wear items and potential failure points, such as suspension bushings, drive belts, and electrical connectors, through detailed inspection and replacement procedures.
Service Part Numbers:
Although not a parts catalog, the manual often refers to specific part numbers for critical components during repair procedures.
Brand:
Arctic Cat is known for its off-road vehicles, particularly snowmobiles and ATVs, with a history of performance and innovation.
Development:
The TRV (Traction, Ride, Versatility) and FIS (Four-Inch Suspension) designations indicate evolving chassis and suspension designs aimed at improving rider comfort and off-road capability.
Origin:
Arctic Cat ATVs are primarily manufactured in Thief River Falls, Minnesota, USA.
