Kawasaki KLX250 D-TRACKER X 2010 Full Service Repair Manual

常规价格
$16.99
促销价
$16.99
常规价格
The Kawasaki KLX250 D-TRACKER X is a versatile dual-sport motorcycle designed for riders who appreciate agility and a capable platform for both on-road and light off-road adventures. This 2010 model,...
27 people are viewing this right now
类型: Motorcycle
厂商:
斯库: 99446
Kawasaki KLX250 D-TRACKER X 2010 Full Service Repair Manual
The Kawasaki KLX250 D-TRACKER X is a versatile dual-sport motorcycle designed for riders who appreciate agility and a capable platform for both on-road and light off-road adventures. This 2010 model, often favored for its supermoto configuration with 17-inch wheels, offers a lightweight and responsive riding experience. Its compact chassis, upright riding position, and torquey 249cc liquid-cooled engine make it suitable for urban commuting, trail exploration, and spirited riding. Kawasaki's legacy of producing reliable motorcycles is evident in the KLX line, which has evolved to meet the demands of riders seeking a practical yet engaging machine. This comprehensive service repair manual provides detailed guidance for the maintenance, repair, and rebuilding of the 2010 Kawasaki KLX250 D-TRACKER X. It covers all major systems, including engine overhaul, fuel and ignition systems, cooling, transmission, suspension, brakes, wheels, tires, and the electrical and bodywork components. The manual includes routine maintenance schedules, troubleshooting procedures, disassembly and reassembly instructions, and detailed wiring diagrams. This resource is designed to assist owners, mechanics, and technicians in keeping the motorcycle in optimal condition and performing accurate repairs.
